Parts for Mariner 28 HP Intake Manifold
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 81562M | COVER, AIR INTAKE (1 required per assembly) |
  |
|
81562M - Cover, NLA [ More info ] Unavailable |
| #2 | 35-80594M | AIR FILTER (1 required per assembly) SERIAL 00000000-00004605 |
  |
|
35-80594M - Filter, NLA [ More info ] Unavailable |
| #3 | 80595M | BASE, AIR FILTER . (1 required per assembly) SERIAL 00000000-00004605 |
  |
|
80595M - Base, NLA [ More info ] Unavailable |
| #4 | 23-81972M | SPACER, INTAKE COVER TO BASE (2 required per assembly) |
  |
|
23-81972M - SPACER,NLA [ More info ] Unavailable |
| #5 | 10-82493M | SCREW, COVER ATTACHING (2 required per assembly) |
  |
|
10-82493M - SCREW,NLA [ More info ] Unavailable |
| #6 | 12-82195M | WASHER, COVER BOLT (2 required per assembly) |
  |
|
12-82195M - WASHER,NLA [ More info ] Unavailable |
| #7 | 80570M | MANIFOLD, INTAKE (1 required per assembly) |
  |
80570M - Intake Manifold [ More info ] Unavailable |
|
  |
|
80570002 - MANIFOLD Intake NLA [ More info ] Unavailable |
| #8 | 16-81733M | STUD, MANIFOLD ATTACHING (1 required per assembly) |
  |
|
16-81733M - STUD,NLA [ More info ] Unavailable |
| #9 | 16-81728M | STUD, CARBURETOR ATTACHING (2 required per assembly) |
  |
16-81728M - STUD [ More info ] Unavailable |
|
  |
|
16-811028M - Stud, NLA [ More info ] Unavailable |
| #10 | 27-80569M | GASKET, INTAKE MANIFOLD (1 required per assembly) |
  |
|
27-80569M - Intake Manifold Gasket [ More info ]
|
| #11 | 27-80571M | GSKET, REED VALVE (1 required per assembly) |
  |
|
27-80571M - Intake Manifold Gasket [ More info ] Unavailable |
| #12 | 10-82425M | BOLT, MANIFOLD ATTACHING (2 required per assembly) |
  |
10-82425M - SCREW Note: Priced Individually [ More info ] Unavailable |
|
  |
|
10-82405M - Screw, NLA [ More info ]
|
| #13 | 10-82427M | BOLT, MANIFOLD ATTACHING (6 required per assembly) |
  |
10-82427M - BOLT Note: Priced Individually [ More info ] Unavailable |
|
  |
|
10-83285M - Screw - Priced Individually [ More info ]
|
| #14 | 13-82197M | LOCK WASHER, MANIFOLD BOLT (8 required per assembly) |
  |
13-82197M - LockWasher - Priced Individually [ More info ] Unavailable |
|
  |
|
13-82212M - LockWasher - Priced Individually [ More info ]
|
| #15 | 11-82380M | NUT, MANIFOLD ATTACHING (1 required per assembly) |
  |
|
11-82380M - NUT - Priced Individually [ More info ]
|
  |
|
11-82389M - Nut, NLA [ More info ] Unavailable |
| #16 | 12-82198M | WASHER, MANIFOLD ATTACHING STUD (1 required per assembly) |
  |
12-82198M - WASHER Note: Priced Individually [ More info ] Unavailable |
|
  |
|
12-82213M - Washer - Priced Individually [ More info ]
|
| #17 | 80568M | REED VALVE (1 required per assembly) |
  |
80568M - Reed Valve [ More info ] Unavailable |
|
  |
84758M - Reed Valve [ More info ] Unavailable |
|
  |
|
811027M - Reed Valve [ More info ]
|
| #18 | 27-80572M | GASKET, CARBURETOR MANIFOLD (1 required per assembly) |
  |
|
27-80572M - Carburetor Manifold Gasket [ More info ]
|
  |
|
27-80572 - Carburetor Manifold Gasket [ More info ]
|
| #20 | 13-82199M | WASHER, CARBURETOR ATTACHING STUD (2 required per assembly) |
  |
13-82199M - LockWasher - Priced Individually [ More info ] Unavailable |
|
  |
|
12-82214M - Washer - Priced Individually [ More info ]
|
| #21 | 81578M | KNOB, CHOKE (1 required per assembly) |
  |
|
81578M - KNOB,NLA [ More info ] Unavailable |
| #22 | 82063M | GROMMET, CHOKE KNOB (1 required per assembly) |
  |
|
82063M - Retainer, NLA [ More info ] Unavailable |
| #23 | 81576M | LIVER, CHOKE (1 required per assembly) |
  |
|
81576M - Lever [ More info ] Unavailable |
| #24 | 17-82155M | PIN, ROLL-CHOKE LEVER (2 required per assembly) |
  |
|
17-82155M - Pin -roll, NLA [ More info ]
|
| #25 | 81191M | SWIVEL, LINK ROD (2 required per assembly) |
  |
81191M - Connector [ More info ] Unavailable |
|
  |
|
16333 - Rod Snap [ More info ] Unavailable |
| #26 | 81577M | LINK ROD, CHOKE LEVER (1 required per assembly) |
  |
|
81577M - Link Rod [ More info ] Unavailable |
| #27 | 17-81880M | PIN, CLEVIS-CHOKE LEVER (1 required per assembly) |
  |
|
17-81880M - PIN,NLA [ More info ] Unavailable |
| #28 | 12-81790M | WASHER, CLEVIS PIN (1 required per assembly) |
  |
|
12-81790M - Washer, Clevis Pin, NLA [ More info ]
|
| #29 | 18-82051M | PIN, CLEVIS (1 required per assembly) |
  |
|
18-82051M - Cotter Pin - Priced Individually [ More info ]
|
| #30 | 54-82034M | CLAMP, WIRE HARNESS (1 required per assembly) |
  |
54-82034M - CLAMP [ More info ] Unavailable |
|
  |
54-97561M - Clamp [ More info ] Unavailable |
|
  |
|
54-96348M - Clamp [ More info ]
|
| #31 | 13-81865M | WASHER, WAVE-CLEVIS PIN (1 required per assembly) |
  |
|
13-81865M - Wave Washer - Priced Individually [ More info ]
|
