Parts for Mariner 28 HP Recoil Starter
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #0-1 | 50-81104M | STARTER ASS'Y (1 required per assembly) SERIAL 00000000-00004605 |
  |
50-81104M - Starter Housing [ More info ] Unavailable |
|
  |
|
50-83211M - Starter, NLA [ More info ] Unavailable |
| #0-1 | 50-83211M | STARTER ASS'Y (1 required per assembly) SERIAL 00004606-09999999 |
| #1 | 2169-6791M | HOUSING, STARTER (1 required per assembly) SERIAL 00000000-00004605 |
  |
2169-6791M - Starter Housing [ More info ] Unavailable |
|
  |
|
2169-6960M - Starter Housing,NLA [ More info ] Unavailable |
| #1 | 2169-6960M | HOUSING, STARTER (1 required per assembly) SERIAL 00004606-09999999 |
| #2 | 19-80604M | PLUG, STARTER HOUSING (6 required per assembly) |
  |
|
19-80604M - Plug, NLA [ More info ] Unavailable |
| #3 | 24-82115M | SPRING, STARTER (1 required per assembly) |
  |
|
24-82115M - Spring, NLA [ More info ] Unavailable |
| #4 | 17-82157M | PIN, STARTER SPRING (2 required per assembly) |
  |
|
17-82157M - Pin -roll, NLA [ More info ]
|
| #5 | 50-81105M | STARTER SHEAVE (1 required per assembly) |
  |
|
50-81105M - Starter Sheave, NLA [ More info ] Unavailable |
| #6 | 80599M | PAWL, STARTER (1 required per assembly) |
  |
|
80599M - Starter Pawl, NLA [ More info ]
|
| #7 | 53-82331M | CIRCLIP, STARTER PAWL (1 required per assembly) |
  |
|
53-82331M - E-Ring, NLA [ More info ]
|
| #8 | 24-81103M | SPRING, PAWL (1 required per assembly) |
  |
|
24-81103M - Spring, Pawl,NLA [ More info ]
|
| #9 | 80598M | SHAFT, SHEAVE (1 required per assembly) |
  |
|
80598M - Sheave Shaft, NLA [ More info ] Unavailable |
| #10 | 10-82440M | BOLT, SHEAVE SHAFT (1 required per assembly) |
  |
10-82440M - BOLT Note: Priced Individually [ More info ] Unavailable |
|
  |
|
10-84342M - Bolt, NLA [ More info ]
|
| #11 | 12-81801M | WASHER, SHEAVE SHAFT BOLT (1 required per assembly) |
  |
|
12-81801M - Washer, NLA [ More info ]
|
| #12 | 11-82382M | NUT, SHEAVE SHAFT BOLT (1 required per assembly) |
  |
|
11-82382M - Nut - Priced Individually [ More info ]
|
| #13 | 80600M | GUIDE, STARTER ROPE (1 required per assembly) |
  |
|
80600M - Guide, NLA [ More info ] Unavailable |
| #14 | 10-82422M | BOLT, GUIDE ATTACHING (2 required per assembly) |
  |
10-82422M - SCREW Note: Priced Individually [ More info ] Unavailable |
|
  |
10-84247M - BOLT Note: Priced Individually [ More info ] Unavailable |
|
  |
10-91725M - BOLT [ More info ] Unavailable |
|
  |
|
10-826957M - Bolt, NLA [ More info ]
|
| #15 | 13-82197M | LOCK WASHER (2 required per assembly) |
  |
13-82197M - LockWasher - Priced Individually [ More info ] Unavailable |
|
  |
|
13-82212M - LockWasher - Priced Individually [ More info ]
|
| #16 | 80063M | HANDLE, STARTER (1 required per assembly) |
  |
80063M - Starter Handle [ More info ] Unavailable |
|
  |
|
814491A 1 - Handle Kit, NLA [ More info ]
|
| #17 | 79629A 1 | STARTER ROPE (1 required per assembly) |
  |
79629A 1 - Starter Rope Note: Priced Individually [ More info ] Unavailable |
|
  |
50-28985A 2 - Starter Rope Assembly [ More info ] Unavailable |
|
  |
50-12066A 9 - Starter Rope , Priced Individually [ More info ] Unavailable |
|
  |
50-12066Q 9 - Starter Rope , Priced Individually [ More info ] Unavailable |
|
  |
|
50-12066Q10 - Starter Rope - Priced Individually [ More info ]
|
  |
|
18-4915 - Pull Rope, 50-12066Q9 [ More info ]
|
  |
|
50-12066K10 - Starter Rope - Priced Individually [ More info ]
|
| #18 | 80602M | BRACKET, STARTER HSG. (STARBOARD) (1 required per assembly) |
  |
|
80602M - Bracket, NLA [ More info ] Unavailable |
| #19 | 80603M | BRACKET, STARTER HSG. (PORT MANUAL) (1 required per assembly) |
  |
|
80603M - Bracket, NLA [ More info ] Unavailable |
| #20 | 10-84237M | BOLT, BRACKET ATTACHING (4 required per assembly) |
  |
10-84237M - SCREW Note: Priced Individually [ More info ] Unavailable |
|
  |
|
10-83285M - Screw - Priced Individually [ More info ]
|
| #21 | 10-82428M | BOLT, BRACKET ATTACHING (1 required per assembly) |
  |
10-82428M - SCREW Note: Priced Individually [ More info ] Unavailable |
|
  |
|
10-827043M - Bolt, NLA [ More info ]
|
| #22 | 81109M | BRACKET, STARTER LOCKOUT (1 required per assembly) |
  |
|
81109M - Bracket, NLA [ More info ] Unavailable |
| #23 | 10-82424M | BOLT, HOUSING ATTACHING-FRONT (2 required per assembly) |
  |
10-82424M - BOLT Note: Priced Individually [ More info ] Unavailable |
|
  |
|
10-83539M - 10-83539M - BOLT (M6 x 20) [ More info ] Unavailable Replaced by 10-84058M |
  |
|
10-84058M - Bolt [ More info ]
|
| #25 | 10-82439M | BOLT, HOUSING ATTACHING-REAR (1 required per assembly) SERIAL 00000000-00001725 |
  |
|
10-82439M - Screw, NLA [ More info ]
|
| #26 | 13-82200M | LOCK WASHER, REAR HOUSING BOLT (1 required per assembly) |
  |
13-82200M - LOCKWASHER Note: Priced Individually [ More info ] Unavailable |
|
  |
|
13-82215M - LockWasher - Priced Individually [ More info ]
|
| #27 | 81106M | PLUNGER, STARTER LOCKOUT (1 required per assembly) |
  |
|
81106M - Plunger, NLA [ More info ]
|
| #28 | 24-82079M | SPRING, STARTER LOCKOUT (1 required per assembly) |
  |
|
24-82079M - Spring, Starter Lockout,NLA [ More info ]
|
| #29 | 81108M | CABLE, STARTER LOCKOUT (1 required per assembly) |
  |
|
81108M - Cable, NLA [ More info ] Unavailable |
| #30 | 10-81747M | BOLT, CABLE ADJUSTING (1 required per assembly) |
  |
10-81747M - Bolt [ More info ] Unavailable |
|
  |
|
10-815139M - Bolt, NLA [ More info ] Unavailable |
| #31 | 11-82380M | NUT, JAM-ADJUSTING BOLT (2 required per assembly) |
  |
|
11-82380M - NUT - Priced Individually [ More info ]
|
  |
|
11-82389M - Nut, NLA [ More info ] Unavailable |
| #32 | 81107M | LINK, STARTER LOCKOUT (1 required per assembly) |
  |
|
81107M - Link, NLA [ More info ] Unavailable |
| #33 | 12-82196M | WASHER, LINK (1 required per assembly) |
  |
12-82196M - WASHER Note: Priced Individually [ More info ] Unavailable |
|
  |
|
12-82211M - Washer - Priced Individually [ More info ]
|
| #34 | 13-81865M | WASHER, WAVE-LINK (1 required per assembly) |
  |
|
13-81865M - Wave Washer - Priced Individually [ More info ]
|
| #35 | 18-82124M | PIN, LINK (1 required per assembly) SERIAL 00000000-00004605 |
  |
18-82124M - COTTER PIN Note: Priced Individually [ More info ] Unavailable |
|
  |
|
18-16189 - Cotter Pin [ More info ]
|
| #35 | 18-82125M | PIN, LINK (1 required per assembly) SERIAL 00004606-09999999 |
  |
|
18-82125M - Cotter Pin, NLA [ More info ]
|
| #36 | 10-81712M | BOLT, LINK ATTACHING (1 required per assembly) SERIAL 00000000-00004605 |
  |
|
10-81712M - SCREW,NLA [ More info ] Unavailable |
| #37 | 13-82199M | WASHER, LINK BOLT (1 required per assembly) |
  |
13-82199M - LockWasher - Priced Individually [ More info ] Unavailable |
|
  |
|
12-82214M - Washer - Priced Individually [ More info ]
|
| #38 | 13-81867M | WASHER, WAVE-LINK BOLT (1 required per assembly) |
  |
|
13-81867M - Wave Washer, NLA [ More info ] Unavailable |
| #39 | 16-81741M | BOLT, STUD (1 required per assembly) SERIAL 26-04605-09999999 |
  |
|
16-81741M - STUD,NLA [ More info ] Unavailable |
| #39 | 16-83317M | BOLT, STUD (1 required per assembly) SERIAL 00004606-09999999 |
  |
|
16-83317M - STUD,NLA [ More info ] Unavailable |
| #41 | 12-82201M | WASHER (1 required per assembly) SERIAL 00001726-09999999 |
  |
12-82201M - WASHER Note: Priced Individually [ More info ] Unavailable |
|
  |
|
12-82216M - Washer, Lock, NLA [ More info ]
|
| #42 | 10-82421M | BOLT, BRACKET ATTACHING (1 required per assembly) |
  |
10-82421M - SCREW Note: Priced Individually [ More info ] Unavailable |
|
  |
|
10-84303M - Screw , Priced Individually [ More info ]
|
  |
10-813477M - BOLT [ More info ] Unavailable |
|
  |
|
10-91772M - Bolt [ More info ]
|
| #44 | 23-82929M | COLLAR (1 required per assembly) SERIAL 00004606-09999999 |
  |
|
23-82929M - Bushing [ More info ] Unavailable |
| #45 | 47341A 1 | EMERGENCY STARTER ROPE (1 required per assembly) |
  |
47341A 1 - Rope And Handle [ More info ] Unavailable |
|
  |
|
47341A11 - Manual Start Rope And Handle [ More info ]
|
