Parts for Mariner 25C (Thru Prop. Exhaust) C.d.i. Magneto

Revise Search: All Models > 25C (Thru Prop. Exhaust) > 695-253862 & Up (E) > C.d.i. Magneto

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	253-8371M	C.D.I. MAGNETO ASS'Y (MANUAL START) (1 required per assembly)
		253-8371M - Flywheel, NLA [ More info ] Unavailable
#1	253-8370M	C.D.I. MAGNETO ASS'Y (ELECTRIC START) (1 required per assembly)
		253-8370M - Flywheel, NLA [ More info ] Unavailable
#2	253-8372M	FLYWHEEL ASS'Y (MANUAL START) (1 required per assembly)
		253-8372M - Flywheel, NLA [ More info ] Unavailable
#2	253-9514M	FLYWHEEL ASS'Y (ELECTRIC START) (1 required per assembly)
		253-9514M - Flywheel, NLA [ More info ] Unavailable
#3	96342M	BASE ASS'Y (1 required per assembly)
		96342M - Base, NLA [ More info ] Unavailable
#4	96343M	BASE, MAGNETO (1 required per assembly)
		96343M - Base, NLA [ More info ] Unavailable
#5	96344M	CHARGE COIL ASS'Y (1 required per assembly)
		96344M - Coil, NLA [ More info ] Unavailable
#6	96345M	PULSER COIL ASS'Y (1 required per assembly)
		96345M - Coil, NLA [ More info ] Unavailable
#7	10-96346M	SCREW, W/WASHER (2 required per assembly)
		10-96346M - SCREW,NLA [ More info ] Unavailable
#8	10-91691M	SCREW, W/WASHER (1 required per assembly)
		10-91691M - Screw, NLA Z [ More info ] $1.25 $1.06 8 In Stock.
#9	94804M	LIGHTING COIL ASS'Y (1 required per assembly)
		94804M - Lighting Coil, NLA [ More info ] Unavailable
#10	10-97803M	SCREW, W/WASHER (2 required per assembly)
		10-97803M - Screw, NLA [ More info ] Unavailable
#11	10-91699M	SCREW, W/ WASHER (MANUAL START) (1 required per assembly)
		10-91699M - Screw, NLA [ More info ] $1.50 $1.28 10+ In Stock.
#12	10-91693M	SCREW, W/WASHER (ELECTRIC START) (1 required per assembly)
		10-91693M - Screw, NLA [ More info ] $1.88 $1.59 6 In Stock.
#13	80688M	COVER (1 required per assembly)
		80688M - Cover [ More info ] Unavailable
#14	10-84303M	BOLT (3 required per assembly)
		10-84303M - Screw , Priced Individually [ More info ] $0.72 1 In Stock.
		10-813477M - BOLT [ More info ] Unavailable
		10-91772M - Bolt [ More info ] $5.42 $4.59 10+ In Stock.
#15	12-82213M	WASHER (3 required per assembly)
		12-82213M - Washer - Priced Individually [ More info ] $1.50 $1.28 10+ In Stock.
#16	11-95508M	NUT (1 required per assembly)
		11-95508M - Nut, NLA [ More info ] Unavailable
#17	12-95557M	WASHER (1 required per assembly)
		12-95557M - Washer [ More info ] $1.25 $1.06 1 In Stock.
#18	99951M	STOP, MAGNETO BASE (1 required per assembly)
		99951M - Bracket, NLA [ More info ] Unavailable
#21	92591M	CAM (1 required per assembly)
		92591M - Throttle Cam, NLA [ More info ] Unavailable
#22	10-82417M	BOLT (2 required per assembly)
		10-82417M - Bolt, NLA [ More info ] $1.88 $1.59 10+ In Stock.
#23	12-82211M	WASHER (2 required per assembly)
		12-82211M - Washer - Priced Individually [ More info ] $1.70 $0.96 10+ In Stock.
#24	54-96348M	CLAMP (1 required per assembly)
		54-96348M - Clamp [ More info ] $2.50 $2.13 10+ In Stock.
#25	10-84315M	BOLT (1 required per assembly)
		10-84315M - BOLT [ More info ] Unavailable
		10-84088M - Bolt [ More info ] $3.40 5 In Stock.
#26	96349M	BRACKET (1 required per assembly)
		96349M - Bracket, NLA [ More info ] $14.00 $11.86 7 In Stock.
#27	84869M	DAMPER (1 required per assembly)
		84869M - Damper,NLA [ More info ] Unavailable
#28	25-93114M	DAMPER (3 required per assembly) SERIAL 00031675-09999999
		25-93114M - O RING [ More info ] Unavailable
		25-881304 - Damper [ More info ] $5.99 Available to Order: Shipping delay up to 10 days.
#28	81523M	DAMPER (3 required per assembly) SERIAL 00000000-00031674
		81523M - Mount, NLA [ More info ] Unavailable
#29	23-82851M	COLLAR (3 required per assembly)
		23-82851M - Bushing [ More info ] Unavailable
		23-804344003 - Collar [ More info ] $2.29 1 In Stock.
#30	10-82405M	BOLT (3 required per assembly)
		10-82405M - Screw, NLA [ More info ] $10.86 $9.19 10+ In Stock.
#31	12-82979M	WASHER (3 required per assembly)
		12-82979M - Washer, Bracket [ More info ] Unavailable
		12-83769M - Washer, NLA [ More info ] $1.50 $1.28 10+ In Stock.
#32	16-84870M	STUD (1 required per assembly)
		16-84870M - Stud, NLA [ More info ] Unavailable
#33	11-82380M	NUT (2 required per assembly)
		11-82380M - NUT - Priced Individually [ More info ] $0.48 6 In Stock.
		11-82389M - Nut, NLA [ More info ] Unavailable
#34	12-82212M	LOCKWASHER (4 required per assembly)
		13-82212M - LockWasher - Priced Individually [ More info ] $1.10 10+ In Stock.
#35	84-84871M	WIRE, GROUND (1 required per assembly)
		84-84871M - Ground Cable, NLA [ More info ] Unavailable
#38	43077M	C.D.I. UNIT ASS'Y (1 required per assembly)
		43077M - Switch Box [ More info ] Unavailable
		43077T - Switch Box [ More info ] Unavailable
		18-5131 - CDI Ignition Switch Box Yamaha Mercury Mariner [ More info ] $252.84 $245.88 Available to Order: Shipping delay up to 10 days.
#39	84873M	BRACKET (1 required per assembly)
		84873M - Holder, NLA [ More info ] Unavailable
#41	12-82214M	WASHER (2 required per assembly)
		12-82214M - Washer - Priced Individually [ More info ] $5.28 10+ In Stock.
#42	95188M	IGNITION COIL ASS'Y (1 required per assembly)
		95188M - Ignition Coil [ More info ] Unavailable
		95188T - Igition Coil [ More info ] Unavailable
#43	25-82069M	GROMMET (2 required per assembly)
		25-82069M - Grommet, Plug Wire,NLA [ More info ] $3.00 6 In Stock.
#45	80935M	PLUG CAP ASS'Y (NOISE SUPPRESSOR)(STD) (2 required per assembly)
		80935M - Protector [ More info ] Unavailable
		814991M - Plug Cap [ More info ] Unavailable
		85-815119M - Protector [ More info ] Unavailable
#45	82788M	PLUG CAP ASS'Y (OPT) (2 required per assembly)
		82788M - Protector - Priced Individually [ More info ] $5.21 4 In Stock.
		85-63709A 1 - Boot Kit - Black - Priced Individually [ More info ] $8.19 8 In Stock.
#46	54-96352M	CLAMP (1 required per assembly)
		54-96352M - Clamp [ More info ] $2.50 $2.13 10 In Stock.
#47	25-84876M	GROMMET (1 required per assembly)
		25-84876M - Grommet, NLA [ More info ] Unavailable
#48	54-96353M	CLAMP (1 required per assembly)
		54-96353M - CLAMP,NLA [ More info ] Unavailable
#49	99952M	CLAMP (1 required per assembly)
		99952M - Cap, NLA [ More info ] Unavailable
