Parts for Mariner 250 HP Verado (4-Stroke) (6 Cylinder) Electrical Box Components

Revise Search: All Models > 250 HP Verado (4-Stroke) (6 Cylinder) > 0P520553 & Up (Belgium) > Electrical Box Components

« Previous

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#	NSS	NOT SOLD SEPARATE, Electrical Box-Complete (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#1	885560T03	BASE, Electrical Box (1 required per assembly)
		885560T03 - Base [ More info ] $254.49 Available to Order: Shipping delay up to 10 days.
#2	885561T	COVER, Fuse Box (1 required per assembly)
		885561T - Cover [ More info ] $206.99 Available to Order: Shipping delay up to 10 days.
#3	888491	COVER, Fuse (1 required per assembly)
		888491 - Fuse Cover [ More info ] Unavailable
		88-8M0167280 - Fuse Cover [ More info ] $9.49 Available to Order: Shipping delay up to 10 days.
#4	25-885583	SEAL (1 required per assembly)
		25-885583 - Seal [ More info ] $3.09 Available to Order: Shipping delay up to 10 days.
#5	889531	STRAP (2 required per assembly)
		889531 - Strap [ More info ] $2.59 Available to Order: Shipping delay up to 10 days.
#6	885584	PIN, Hinge (2 required per assembly)
		885584 - Hinge Pin [ More info ] $5.49 Available to Order: Shipping delay up to 10 days.
#7	25-833155	GROMMET (1 required per assembly)
		25-833155 - Grommet [ More info ] $4.49 Available to Order: Shipping delay up to 10 days.
#8	23-850234 1	BUSHING (1 required per assembly)
		23-850234 1 - Bushing [ More info ] $3.09 Available to Order: Shipping delay up to 10 days.
#9	88-832969 20	FUSE, Mini - Yellow - 20 Ampere (7 required per assembly)
		88-832969 20 - Fuse-Yellow-20AMP [ More info ] Unavailable
		88-832969T20 - Fuse - Yellow - 20 Amp [ More info ] $7.09 10+ In Stock.
#10	11-40021 3	NUT, (M8) Stainless Steel (1 required per assembly)
		11-40021 3 - Nut - Priced Individually [ More info ] $2.89 Available to Order: Shipping delay up to 10 days.
#11	895099	EXTRACTOR, Fuse (1 required per assembly)
		895099 - Fuse Extractor [ More info ] $1.80 Available to Order: Shipping delay up to 10 days.
#12	32-828547753	CONDUIT, (.750 Inside Diameter x 3.00 Feet Bulk) (1 required per assembly)
		32-828547753 - Conduit (.750 Inside Di [ More info ] $9.39 Available to Order: Shipping delay up to 10 days.
#13	10-40011146	SCREW, (M8 x 13) Stainless Steel (2 required per assembly)
		10-40011146 - Screw - Priced Individually [ More info ] $2.59 2 In Stock.
#14	12-843108	WASHER, (.330 x .560 x .060) Stainless Steel (1 required per assembly)
		12-843108 - Washer, (.330 X .560 X .060) Stainless Steel [ More info ] $0.69 Available to Order: Shipping delay up to 10 days.
#15	12-817274	WASHER, (.344 x 1.00 x .063) Stainless Steel (1 required per assembly)
		12-817274 - Washer, (.344 X 1.00 X .063) Stainless Steel [ More info ] $1.40 2 In Stock.
#16	892244	STRAP, Cover (1 required per assembly)
		892244 - Strap [ More info ] $2.59 Available to Order: Shipping delay up to 10 days.
#17	54-879962	CLIP (4 required per assembly)
		54-879962 - Clip [ More info ] $1.99 4 In Stock.
#18	89790740T	PCM, Propulsion Control Module (1 required per assembly) (200)
		89790740T - PCM Propulsion Control [ More info ] Unavailable
#18	89790741T	PCM, Propulsion Control Module (1 required per assembly) (225)
		89790741T - PCM Propulsion Control [ More info ] Unavailable
#18	89790742T	PCM, Propulsion Control Module (1 required per assembly) (250)
		89790742T - PCM Propulsion Control [ More info ] Unavailable
#18	89790744T	PCM, Propulsion Control Module (1 required per assembly) (275)
		89790744T - PCM Propulsion Control [ More info ] Unavailable
#18	89790746T	PCM, Propulsion Control Module (1 required per assembly) (300)
		89790746T - PCM Propulsion Control [ More info ] Unavailable
#19	84-880616T07	HARNESS ASSEMBLY, Engine (1 required per assembly)
		84-880616T07 - Harness Assembly [ More info ] Unavailable
		84-8M0077446 - 84-8M0077446 - HARNESS-ENGINE [ More info ] Unavailable Replaced by 84-8M0082643
		848M0082643 - Engine Harness [ More info ] $1,207.99 Available to Order: Shipping delay up to 10 days.
#20	882751A04	RELAY ASSEMBLY (4 required per assembly)
		882751A04 - Relay Assembly [ More info ] $23.99 $23.49 In Stock
		18-5850 - Relay, 882751A04 [ More info ] $28.43 6 In Stock.
#22	889532	BRACKET (1 required per assembly)
		889532 - Bracket [ More info ] $18.49 Available to Order: Shipping delay up to 10 days.
#23	10-40007103	SCREW, (M5 x 6) (2 required per assembly)
		10-40007103 - Screw - Priced Individually [ More info ] $2.29 Available to Order: Shipping delay up to 10 days.
#24	84-93388A17	CABLE ASSEMBLY, (8.50 Inches) (1 required per assembly)
		84-93388A17 - Starter Cable [ More info ] $22.09 Available to Order: Shipping delay up to 10 days.
#25	84-819514A20	HARNESS ASSEMBLY, Trim (1 required per assembly)
		84-819514A20 - HARNESS ASSY-TRIM [ More info ] Unavailable
		84-879345T34 - Trim Harness [ More info ] $68.99 Available to Order: Shipping delay up to 10 days.
#26	84-892137A02	HARNESS ASSEMBLY, Fuse (1 required per assembly)
		84-892137A02 - Harness Assembly [ More info ] $143.99 Available to Order: Shipping delay up to 10 days.
#27	830796A03	CONNECTOR ASSEMBLY, Weather Cap - 2 Pin Male (1 required per assembly)
		830796A03 - Connector [ More info ] $5.92 2 In Stock.
#28	54-850181	TIE STRAP, (11.750 Inches) (6 required per assembly)
		54-850181 - Cable Tie [ More info ] $0.60 $0.48 7 In Stock.
#28	54-816311T	TIE STRAP, (8.00 Inches) (AR required per assembly)
		54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ] $0.60 8 In Stock.
#29	10-821291 14	SCREW, (M6 x 14) (1 required per assembly)
		10-821291 14 - Screw [ More info ] $2.49 Available to Order: Shipping delay up to 10 days.
#30	877613A02	CONNECTOR ASSEMBLY, Weather Cap 6 Pin (1 required per assembly)
		877613A02 - Connector [ More info ] $8.19 Available to Order: Shipping delay up to 10 days.
#32	84-888416T03	HARNESS ASSEMBLY (1 required per assembly)
		84-888416T03 - HARNES ASY-14 FT [ More info ] Unavailable
		84-888416T04 - Harness Assembly [ More info ] Unavailable
		848M0113732 - Harness, Clean Power [ More info ] $105.85 Available to Order: Shipping delay up to 10 days.
#33	862646	FUSE, Tan - 5 Ampere (1 required per assembly)
		862646 - Fuse, Tan, 5 Amp [ More info ] $4.09 Available to Order: Shipping delay up to 10 days.
#34	84-88439A25	CABLE ASSEMBLY, Battery - Positive (1 required per assembly) (Long)
		84-88439A25 - Cable Assembly -pos [ More info ] $61.36 1 In Stock.
#35	11-40138 8	NUT, (M8) Stainless Steel (5 required per assembly)
		11-40138 8 - Nut - Priced Individually [ More info ] $3.11 3 In Stock.
#36	11-86226	NUT, (.375-16), Battery Cable-Positive (1 required per assembly)
		11-86226 - Nut (3/8-16) [ More info ] $2.21 10 In Stock.
		11-8M0204671 - NUT [ More info ] Unavailable
#37	10-885526 35	SCREW, (M8 x 35) (1 required per assembly)
		10-885526 35 - Screw - Priced Individually [ More info ] Unavailable
#39	84-88439A26	CABLE ASSEMBLY, Battery - Negative (1 required per assembly) (Long)
		84-88439A26 - Cable Assembly -neg [ More info ] $70.99 Available to Order: Shipping delay up to 10 days.
#40	11-68292	NUT, (.312-18), Battery Cable-Negative (1 required per assembly)
		11-68292 - Nut (5/16 Inch) [ More info ] $1.50 10+ In Stock.
		11-8M0204668 - NUT @5 [ More info ] Unavailable
#41	54-891520001	CLIP (1 required per assembly)
		54-891520001 - Clip [ More info ] $5.39 Available to Order: Shipping delay up to 10 days.
