Parts for Mariner 2.5 HP Starter Assembly (Manual)
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 90906 | HOUSING, STARTER (1 required per assembly) |
  |
90906 - Housing [ More info ] Unavailable |
|
  |
42712A 1 - Starter Housing Kit [ More info ] Unavailable |
|
  |
42712A 2 - Starter Housing Kit [ More info ] Unavailable |
|
  |
42712A 3 - Starter Housing Kit [ More info ] Unavailable |
|
  |
86689A 4 - Starter Housing Kit [ More info ] Unavailable |
|
  |
|
86689A 5 - Starter Housing [ More info ] Unavailable |
| #2 | 86971 | COVER, STARTER HOUSING (1 required per assembly) |
  |
|
86971 - Cover, NLA [ More info ] Unavailable |
| #3 | 94019 | LEVER, LOCK (UPPER) (1 required per assembly) |
  |
94019 - Upper Lock Lever [ More info ] Unavailable |
|
  |
|
858925 - Upper Lock Lever [ More info ] Unavailable |
| #4 | 24-89542 | SPRING, UPPER LOCK LEVER (1 required per assembly) |
  |
24-89542 - Spring, Upper Lock Lever [ More info ] Unavailable |
|
  |
|
24-12734 - Spring, Upper Lock Lever,NLA [ More info ]
|
| #5 | 93876 | LEVER, LOCK (LOWER) (1 required per assembly) |
  |
93876 - LEVER [ More info ] Unavailable |
|
  |
93876 1 - LEVER [ More info ] Unavailable |
|
  |
93876 2 - Lever [ More info ] Unavailable |
|
  |
|
93876T02 - Lever [ More info ]
|
| #6 | 10-61802 | SCREW, LOWER LOCK LEVER (1 required per assembly) |
  |
|
10-61802 - Screw, NLA [ More info ]
|
| #7 | 17-38489 | ROLL PIN, LOCK LEVER (1 required per assembly) |
  |
|
17-38489 - Pin -roll [ More info ]
|
| #8 | 10-40001 74 | SCREW, STARTER HOUSING ATTACHING (20MM) (2 required per assembly) |
  |
10-40001 74 - Screw , Priced Individually [ More info ] Unavailable |
|
  |
|
10-40003 29 - Screw - Priced Individually [ More info ] Unavailable |
| #8 | 10-40001 83 | SCREW, STARTER HOUSING ATTACHING (35MM) (1 required per assembly) |
  |
|
10-40001 83 - Screw, NLA [ More info ]
|
| #9 | 90478 | PAD, FELT (1 required per assembly) |
  |
|
|
  |
833161 - PAD-FELT [ More info ] Unavailable |
|
  |
|
833161T - Felt Pad [ More info ]
|
| #10 | 24-86857 | SPRING, STARTER (1 required per assembly) |
  |
24-86857 - Spring, Starter [ More info ] Unavailable |
|
  |
24-86857 1 - Spring [ More info ] Unavailable |
|
  |
|
24-86857T01 - Spring [ More info ]
|
| #11 | 50-42566 | SHEAVE, STARTER (1 required per assembly) |
  |
50-42566 - SHEAVE [ More info ] Unavailable |
|
  |
50-825269 - SHEAVE [ More info ] Unavailable |
|
  |
50-825269 1 - SHEAVE [ More info ] Unavailable |
|
  |
50-825269A 1 - Sheave Assembly, NLA [ More info ] Unavailable |
|
  |
|
50-825269T01 - Starter Sheave [ More info ]
|
| #12 | 24-86851 | SPRING, CAM (2 required per assembly) |
  |
|
24-86851 - Spring, Cam [ More info ]
|
  |
24-86851 1 - SPRING Note: Priced Individually [ More info ] Unavailable |
|
  |
24-86851 2 - Spring - Priced Individually [ More info ] Unavailable |
|
  |
|
24-86851T02 - Spring - Priced Individually [ More info ]
|
| #13 | 86850 | CAM (2 required per assembly) |
  |
|
|
  |
|
86850 1 - Cam Dog [ More info ]
|
| #14 | 53-86849 | RETAINING RING, CAM (2 required per assembly) |
  |
53-86849 - Retaining Ring - Priced Individually [ More info ] Unavailable |
|
  |
53-86849 1 - RING Note: Priced Individually [ More info ] Unavailable |
|
  |
|
53-86849T01 - Ring - Priced Individually [ More info ]
|
| #15 | 50-86855 | ROPE, STARTER (1 required per assembly) |
  |
50-86855 - Starter Rope Note: Priced Individually [ More info ] Unavailable |
|
  |
50-28985A 2 - Starter Rope Assembly [ More info ] Unavailable |
|
  |
50-12066A 9 - Starter Rope , Priced Individually [ More info ] Unavailable |
|
  |
50-12066Q 9 - Starter Rope , Priced Individually [ More info ] Unavailable |
|
  |
|
50-12066Q10 - Starter Rope - Priced Individually [ More info ]
|
  |
|
18-4915 - Pull Rope, 50-12066Q9 [ More info ]
|
  |
|
50-12066K10 - Starter Rope - Priced Individually [ More info ]
|
| #16 | 85174A 1 | HANDLE ASSEMBLY, STARTER ROPE (1 required per assembly) |
  |
|
85174A 1 - Handle Assembly -start [ More info ]
|
| #17 | 24-86852 | SPRING, CAM (1 required per assembly) |
  |
24-86852 - Spring, Cam [ More info ] Unavailable |
|
  |
24-86852 1 - SPRING [ More info ] Unavailable |
|
  |
|
24-86852 3 - Spring [ More info ]
|
| #18 | 86853 | CAM (1 required per assembly) |
  |
86853 - Cam [ More info ] Unavailable |
|
  |
86853 1 - CAM [ More info ] Unavailable |
|
  |
|
|
| #19 | 10-97516 | SCREW, CAM TO STARTER SHEAVE (1 required per assembly) |
  |
10-97516 - Screw [ More info ] Unavailable |
|
  |
|
10-826253 - Screw [ More info ] Unavailable |
| #20 | 42626 | SUPPORT, STARTER HANDLE (1 required per assembly) |
  |
42626 - REST [ More info ] Unavailable |
|
  |
42626 1 - REST [ More info ] Unavailable |
|
  |
42626 2 - REST [ More info ] Unavailable |
|
  |
|
42626 4 - Rest - Starter Handle [ More info ] Unavailable |
| #21 | 10-40057111 | SCREW, SUPPORT TO STARTER HOUSING (35MM) (2 required per assembly) |
  |
10-40057111 - Screw Note: Priced Individually [ More info ] Unavailable |
|
  |
|
10-40019111 - Screw [ More info ]
|
| #22 | 12-40022 13 | WASHER, SUPPORT SCREW (4 required per assembly) |
  |
12-40022 13 - WASHER [ More info ] Unavailable |
|
  |
|
12-40023 13 - Washer, Rest Screw [ More info ]
|
| #23 | 23-30977 | SPACER, SUPPORT SCREW (4 required per assembly) |
  |
23-30977 - Spacer [ More info ] Unavailable |
|
  |
23-30977 1 - SPACER [ More info ] Unavailable |
|
  |
|
23-30977 2 - Spacer [ More info ]
|
| #24 | 11-40063 3 | NUT, SUPPORT SCREW (2 required per assembly) |
  |
11-40063 3 - NUT [ More info ] Unavailable |
|
  |
|
11-40138 5 - Nut [ More info ] Unavailable |
