Parts for Mariner 20 HP (2 Cylinder) Gear Housing (Propeller Shaft)

Revise Search: All Models > 20 HP (2 Cylinder) > 0A730007 & Up (Canada) > Gear Housing (Propeller Shaft)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

LOOKING FOR A PROP?
• Try our prop finder.

COMPLETE GEARCASE?
• Aftermarket gearcase may be available for less than $900 USD. 70 HP+ only. Please call.

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#	1665-8669A23	GEAR HOUSING (SHORT) (TRACKER) (1 required per assembly)
		1665-8669A23 - TR-S/GEAR HOUSIN,NLA [ More info ] Unavailable
#	1665-8669A15	GEAR HOUSING (SHORT) (GRAY) (1 required per assembly)
		1665-8669A15 - Gear Housing Assembly [ More info ] Unavailable
		1665-8669T15 - Gear Housing COMP [ More info ] Unavailable
		1665-8669T13 - Gear Housing Sh- Black [ More info ] Unavailable
#	26-85090A 2	SEAL KIT (1 required per assembly)
		26-85090A 2 - Seal Kit [ More info ] $102.99 Available to Order: Shipping delay up to 10 days.
#	1665-8669A13	GEAR HOUSING (SHORT) (BLACK) (1 required per assembly)
		1665-8669A13 - Gear Housing Assembly [ More info ] Unavailable
#	1665-8669A24	GEAR HOUSING (LONG) (TRACKER) (1 required per assembly)
		1665-8669A24 - TR-L/GEAR HOUSIN,NLA [ More info ] Unavailable
#	1665-8669A16	GEAR HOUSING (LONG) (GRAY) (1 required per assembly)
		1665-8669A16 - Gear Housing Assembly [ More info ] Unavailable
		1665-8669T16 - Gear Housing COMP,NLA [ More info ] Unavailable
#	1665-8669A14	GEAR HOUSING (LONG) (BLACK) (1 required per assembly)
		1665-8669A14 - Gear Housing Assembly [ More info ] Unavailable
		1665-8669T14 - Gearcase 20/25 2S Lg [ More info ] Unavailable
#	27-41499A87	GASKET SET (1 required per assembly)
		27-41499A87 - Engine Gasket Set [ More info ] Unavailable
		27-41499A88 - Engine Gasket Set [ More info ] $154.49 Available to Order: Shipping delay up to 10 days.
#1	1665-8669A21	GEAR HOUSING ASSEMBLY, Basic (BLACK) (1 required per assembly)
		1665-8669A21 - Gear Housing Assembly [ More info ] Unavailable
		16008M0083538 - Gearcase Basic 25 2S [ More info ] $922.49 Available to Order: Shipping delay up to 10 days.
#1	1665-8669A22	GEAR HOUSING ASSEMBLY (GRAY) (1 required per assembly)
		1665-8669A22 - Ord 1665-8669A21, NLA [ More info ] Unavailable
#1	1665-8669A25	GEAR HOUSING ASSEMBLY (TRACKER) (1 required per assembly)
		1665-8669A25 - Gear Housing Assembly [ More info ] Unavailable
		1665-8669A39 - Gear Housing Assembly [ More info ] Unavailable
#39	98432 5	TRIM TAB (1 required per assembly)
		97-98432 5 - 97-98432 5 - TRIM TAB [ More info ] Unavailable Replaced by -98432T 5
		98432T 5 - Trim Tab Anode, Zinc [ More info ] Unavailable
		97-98432Q 6 - Trim Tab Anode, Zinc [ More info ] $25.49 8 In Stock.
		97-98432T 6 - Trim Tab Anode, Zinc [ More info ] $27.99 4 In Stock.
#40	10-40003 54	SCREW, (M8 x 30), TRIM TAB (1 required per assembly)
		10-40003 54 - Screw - Priced Individually [ More info ] $4.79 7 In Stock.
#41	12-70132	WASHER, (.323 x .563 x .063) Stainless Steel (1 required per assembly)
		12-70132 - Washer, (.323 X .563 X .063 - Stainless Steel) [ More info ] Unavailable
		12-8M0042642 - Washer - Priced Individually [ More info ] $1.80 6 In Stock.
#42	31-99328A 1	ROLLER BEARING ASSEMBLY (1 required per assembly)
		31-99328A 1 - Roller Bearing [ More info ] Unavailable
		31-8M0103470 - Bearing Assembly, Captive [ More info ] $45.99 In Stock
#43	43-44213A 1	FORWARD GEAR (1 required per assembly)
		43-44213A 1 - Forward Gear Assembly [ More info ] Unavailable
		43-44213T 1 - Forward Gear Assembly [ More info ] $175.00 Available to Order: Shipping delay up to 10 days.
#44	23-85557	BUSHING (1 required per assembly)
		23-85557 - Bushing [ More info ] $11.29 3 In Stock.
#45	85094	CAM FOLLOWER (1 required per assembly)
		85094 - Cam Follower [ More info ] $28.29 Available to Order: Shipping delay up to 10 days.
#46	24-38114	SPRING (1 required per assembly)
		24-38114 - Spring, Retaining - Cross Pin [ More info ] $4.49 Available to Order: Shipping delay up to 10 days.
#47	52-41040	CLUTCH (NO STAMPING) (1 required per assembly)
		52-41040 - Clutch [ More info ] Unavailable
		52-41040T - Clutch [ More info ] Unavailable
#47	52-41040 1	CLUTCH (STAMPED 52-41040--1) (1 required per assembly)
		52-41040 1 - Clutch [ More info ] Unavailable
		52-41040T 1 - Clutch [ More info ] $228.49 Available to Order: Shipping delay up to 10 days.
#48	44-816623	PROPELLER SHAFT (1 required per assembly)
		44-816623 - Propeller Shaft, New Take Off, See Detail Page [ More info ] Unavailable
		44-816623 1 - Propeller Shaft [ More info ] $473.33 1 In Stock.
#49	24-88680	SPRING (1 required per assembly)
		24-88680 - Spring, Compression - Propeller Shaft [ More info ] Unavailable
#50	17-85093	PIN (1 required per assembly)
		17-85093 - Cross Pin, Clutch To Propeller Shaft [ More info ] Unavailable
		17-8M0020999 - Pin Cross [ More info ] $8.69 Available to Order: Shipping delay up to 10 days.
#51	43-99542	REVERSE GEAR (1 required per assembly)
		43-99542 - Reverse Gear [ More info ] Unavailable
		43-99542T - Reverse Gear [ More info ] $305.92 $166.13 Available to Order: Shipping delay up to 10 days.
#52	99906A 1	BEARING CARRIER ASSEMBLY (1 required per assembly)
		99906A 1 - Carrier Assembly [ More info ] Unavailable
		99906T 1 - Carrier Assembly [ More info ] $350.71 1 In Stock.
#53	31-21739	ROLLER BEARING (1 required per assembly)
		31-21739 - Roller Bearing - Forward Gear [ More info ] $18.59 10+ In Stock.
#54	26-41132	OIL SEAL (INNER) (1 required per assembly)
		26-41132 - Seal [ More info ] $19.88 3 In Stock.
		18-0580 - Seal, 26-41132 [ More info ] $17.69 4 In Stock.
#55	26-41131	OIL SEAL (OUTER) (1 required per assembly)
		26-41131 - Seal [ More info ] Unavailable
		18-0579 - Seal, 26-41131 [ More info ] $19.18 4 In Stock.
#56	25-85549	O-RING (1 required per assembly)
		25-85549 - O-ring, Propeller Shaft Outer Oil Seal [ More info ] $5.09 10+ In Stock.
#57	87293	PLATE (1 required per assembly)
		87293 - Gear Housing Plate [ More info ] $7.79 Available to Order: Shipping delay up to 10 days.
#58	10-90883	SCREW, (M5 x 16) (3 required per assembly)
		10-90883 - Screw [ More info ] $1.80 Available to Order: Shipping delay up to 10 days.
#59	85128 1	THRUST HUB ASSEMBLY (1 required per assembly)
#60	48-19640A40	PROPELLER (1 required per assembly)
		48-19640A40 - Propeller, Black Max 10 3/8 X 13 RH, Aluminum, 3 Blade [ More info ] $201.19 1 In Stock.
		Solas Amita 3 Blade Aluminum 13P Mercury 1211-101-13 [ More info ] $85.51 10+ In Stock.
#60	48-19638A40	PROPELLER (SEA PRO/MARATHON 25/SUPER 15) (1 required per assembly)
		48-19638A40 - Propeller, Black Max 10 3/8R11 [ More info ] $201.19 Available to Order: Shipping delay up to 10 days.
		Solas Amita 3 Blade Aluminum 11P Mercury 1211-105-11 [ More info ] $85.51 6 In Stock.
#61	11-88228	PROPELLER NUT (1 required per assembly)
		11-88228 - Prop Nut - Priced Individually [ More info ] $3.05 7 In Stock.
		18-3703 - Nut, 11-88228 [ More info ] $6.28 Available to Order: Shipping delay up to 10 days.
#61	11-821280	NUT (SEA PRO/MARATHON 25/SUPER 15) (1 required per assembly)
		11-821280 - Nut (M12 X 1.75) [ More info ] Unavailable
		11-40138 12 - Nut, (M12) Stainless Steel [ More info ] $8.79 1 In Stock.
#62	10-40003 78	SCREW, (M10 x 35) SS (4 required per assembly)
		10-40003 78 - Screw [ More info ] Unavailable
#63	12-43328	WASHER (4 required per assembly)
		12-43328 - Washer, Gear Housing Screw [ More info ] $3.59 Available to Order: Shipping delay up to 10 days.
#64	23-41589	SPACER (USE WHERE APPLICABLE) (4 required per assembly)
		23-41589 - Spacer - Gear Housing Screw [ More info ] $4.35 $3.68 10 In Stock.
