Parts for Mariner 15K HP Crankshaft & Piston
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| # | 27-811233M | POWERHEAD GASKET SET (1 required per assembly) |
  |
|
27-811233M - GASKET SET NLA [ More info ] Unavailable |
| # | 811230M | POWERHEAD (1 required per assembly) |
  |
|
811230M - POWERHEAD NLA [ More info ] Unavailable |
| #1 | 463-9579M | CRANKSHAFT (1 required per assembly) (CYLINDRICAL UNION CRANK) |
  |
|
463-9579M - CrankShaft, NLA [ More info ] Unavailable |
| #2 | 30-82303M | BEARING (2 required per assembly) |
  |
30-82303M - Ball Bearing [ More info ] Unavailable |
|
  |
|
30-82303T - Ball Bearing [ More info ]
|
| #3 | 812491M | CRANK (1 required per assembly) SPLINDED UNION CRANK |
  |
|
812491M - 812491M - CRANK [ More info ] Unavailable Replaced by -827192M |
  |
|
827192M - Crank [ More info ] Unavailable |
| #4 | 19262M | CRANK (1 required per assembly) SPLINDED UNION CRANK |
  |
|
19262M - Crank, NLA [ More info ] Unavailable |
| #5 | 19263M | CRANK (1 required per assembly) SPLINDED UNION CRANK |
  |
|
19263M - CRANK NLA [ More info ] Unavailable |
| #6 | 812492M | CRANK (1 required per assembly) SPLINDED UNION CRANK |
  |
|
812492M - CRANK NLA [ More info ] Unavailable |
| #7 | 30-84626M | BEARING (1 required per assembly) SPLINDED UNION CRANK |
  |
|
30-84626M - 30-84626M - BALL BEARING [ More info ] Unavailable Replaced by 30-84626T |
  |
|
30-84626T - Ball Bearing, NLA [ More info ]
|
| #8 | 94556M | SEAL (1 required per assembly) SPLINDED UNION CRANK |
  |
|
94556M - Seal, NLA [ More info ] Unavailable |
| #3 | 827192M | CRANK (1 required per assembly) CYLINDRICAL UNION CRANK |
| #4 | 827197M | CRANK (1 required per assembly) CYLINDRICAL UNION CRANK |
  |
|
827197M - 827197M - CRANK [ More info ] Unavailable Replaced by -852799 |
  |
|
852799 - CRANK NLA [ More info ] Unavailable |
| #5 | 827198M | CRANK (1 required per assembly) CYLINDRICAL UNION CRANK |
  |
|
827198M - 827198M - CRANK [ More info ] Unavailable Replaced by -8527991 |
  |
|
8527991 - CRANK NLA [ More info ] Unavailable |
| #6 | 827199M | CRANK (1 required per assembly) CYLINDRICAL UNION CRANK |
  |
|
827199M - 827199M - CRANK [ More info ] Unavailable Replaced by -812492M |
| #8 | 827435M | SEAL (1 required per assembly) CYLINDRICAL UNION CRANK |
  |
|
827435M - SEAL NLA [ More info ] Unavailable |
| #9 | 17-812493M | PIN (1 required per assembly) |
  |
|
17-812493M - Pin, NLA [ More info ] Unavailable |
| #10 | 53-94555M | CIRCLlP (1 required per assembly) |
  |
|
53-94555M - Snap Ring, NLA [ More info ]
|
| #11 | 17-84625M | PIN (2 required per assembly) |
  |
|
17-84625M - Pin, NLA [ More info ] Unavailable |
| #12 | 629-812494M | CONNECTING ROD (2 required per assembly) |
  |
|
629-812494M - Connecting Rod Assembly [ More info ] Unavailable |
| #13 | 31-812495M | BEARING (2 required per assembly) |
  |
|
31-812495M - Bearing, NLA [ More info ]
|
| #14 | 12-84636M | WASHER (4 required per assembly) |
  |
|
12-84636M - Washer, NLA [ More info ] Unavailable |
| #15 | 761-9580M | PISTON (STANDARD) (2 required per assembly) |
  |
|
761-9580M - 761-9580M - PISTON [ More info ] Unavailable Replaced by 761-9580T |
  |
|
761-9580T - PISTON NLA [ More info ] Unavailable |
| #15 | 761-9581M | PISTON (1st. O.S. 0.25MM) (AR required per assembly) |
  |
|
761-9581M - Piston, NLA [ More info ] Unavailable |
| #15 | 761-9582M | PISTON (2nd. O.S. 0.50MM) (AR required per assembly) |
  |
|
761-9582M - Piston, NLA [ More info ]
|
| #16 | 39-15320M | PISTON RING SET (STANDARD) (2 required per assembly) |
  |
39-15320M - Piston Ring Set [ More info ] Unavailable |
|
  |
|
39-15320T - Piston Rings [ More info ]
|
| #16 | 39-18939M | PISTON RING SET (1st. O.S. 0.25MM) (AR required per assembly) |
  |
39-18939M - Piston Ring Set [ More info ] Unavailable |
|
  |
|
39-18939T - Rings, NLA [ More info ]
|
| #16 | 39-15322M | PISTON RING SET (2nd. O.S. 0.50MM) (AR required per assembly) |
  |
39-15322M - Piston Ring Set [ More info ] Unavailable |
|
  |
|
39-15322T - Rings, NLA [ More info ] Unavailable |
| #17 | 41-80272M | PISTON PIN (2 required per assembly) |
  |
|
41-80272M - Piston Pin, NLA [ More info ]
|
| #18 | 29-82349M | BEARING (50 required per assembly) |
  |
|
29-82349M - Needle Bearing [ More info ]
|
| #19 | 12-81823M | WASHER (4 required per assembly) |
  |
|
12-81823M - Washer, Piston Pin, NLA [ More info ]
|
| #20 | 53-82343M | SNAP RING (4 required per assembly) |
  |
|
53-82343M - Ring -snap - Priced Individually [ More info ]
|
| #21 | 26-83936M | OIL SEAL (1 required per assembly) |
  |
|
26-83936M - Seal, NLA [ More info ]
|
| #22 | 23-84243M | SPACER (1 required per assembly) |
  |
|
23-84243M - SPACER,NLA [ More info ] Unavailable |
| #23 | 12-15323M | WASHER (1 required per assembly) |
  |
|
12-15323M - WASHER @2 NLA [ More info ] Unavailable |
| #24 | 18940M | HOUSING (1 required per assembly) |
  |
|
18940M - Housing, NLA [ More info ]
|
| #25 | 26-18843M | OIL SEAL (1 required per assembly) |
  |
|
26-18843M - Seal [ More info ]
|
| #26 | 25-83930M | O-RING (1 required per assembly) |
  |
|
25-83930M - O-ring,NLA [ More info ]
|
| #27 | 26-96606M | OIL SEAL (2 required per assembly) |
  |
|
26-96606M - Seal [ More info ]
|
| #28 | 10-826957M | BOLT (3 required per assembly) |
  |
|
10-826957M - Bolt, NLA [ More info ]
|
| #29 | 12-82214M | WASHER (3 required per assembly) |
  |
|
12-82214M - Washer - Priced Individually [ More info ]
|
| #30 | 28-81914M | WOODRUFF KEY (1 required per assembly) |
  |
|
28-81914M - Key - Priced Individually [ More info ]
|
  |
|
288M0057164 - Key , Priced Individually [ More info ]
|
