Parts for Mariner 15K HP Steering Handle
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 810449 1 | HANDLE, Steering (1 required per assembly) |
  |
|
810449 1 - HANDLE Steering NLA [ More info ] Unavailable |
| #2 | 37-852834 | DECAL, Shift (1 required per assembly) |
  |
|
37-852834 - DECAL Shift NLA [ More info ] Unavailable |
| #3 | 18848M | BRACKET (1 required per assembly) |
  |
|
|
| #4 | 10-852787 5 | SCREW (2 required per assembly) |
  |
10-852787 5 - SCREW [ More info ] Unavailable |
|
  |
|
10-14232M - Screw, NLA [ More info ]
|
| #5 | 11558M | LEVER (1 required per assembly) |
  |
|
11558M - Lever [ More info ] Unavailable |
| #6 | 11556M | PIECE (1 required per assembly) |
  |
|
11556M - Friction Piece, NLA [ More info ]
|
| #7 | 95497 1 | HANDLE RUBBER (1 required per assembly) |
  |
95497 1 - Grip [ More info ] Unavailable |
|
  |
|
8M0080456 - Grip [ More info ]
|
| #8 | 81585M | GRIP (1 required per assembly) |
  |
|
81585M - Handle A [ More info ] Unavailable |
| #9 | 10-811916M | SCREW (1 required per assembly) |
  |
|
10-811916M - Screw, NLA [ More info ]
|
| #10 | 852832 | INDICATOR, Throttle (1 required per assembly) |
  |
|
852832 - Tube, Volvo [ More info ]
|
| #11 | 17-81907M | RIVET (1 required per assembly) |
  |
|
17-81907M - Rivet, NLA [ More info ]
|
| #12 | 12-82220M | WASHER (1 required per assembly) |
  |
|
12-82220M - Washer - Priced Individually [ More info ] Unavailable |
| #13 | 24-82095M | SPRING (1 required per assembly) |
  |
|
24-82095M - Spring, Throttle Shaft,NLA [ More info ]
|
| #14 | 23-81945M | BUSHING (1 required per assembly) |
  |
|
23-81945M - Bushing, NLA [ More info ]
|
| #15 | 10-17363M | BOLT (1 required per assembly) |
  |
|
10-17363M - BOLT,NLA [ More info ] Unavailable |
| #16 | 18-82125M | COTTER PIN (1 required per assembly) |
  |
|
18-82125M - Cotter Pin, NLA [ More info ]
|
| #17 | 23-852814 6 | BUSHING (1 required per assembly) |
  |
|
23-852814 6 - Bushing [ More info ]
|
| #18 | 13-852831 | WAVE WASHER (1 required per assembly) |
  |
|
13-852831 - Wave Washer [ More info ] Unavailable |
| #19 | 12-852803 5 | WASHER (1 required per assembly) |
  |
|
12-852803 5 - Washer [ More info ]
|
| #20 | 18-82053M | PIN, Hair (1 required per assembly) |
  |
|
18-82053M - Cotter Pin - Priced Individually [ More info ]
|
| #21 | 12-81844M | WASHER (1 required per assembly) |
  |
|
12-81844M - Washer - Priced Individually [ More info ] Unavailable |
| #22 | 852835 | SHIFT ROD LINK (1 required per assembly) |
  |
|
0852835 - L/P 26.58 [ More info ] Unavailable |
  |
|
3588770 - Anode Kit [ More info ]
|
| #23 | 804395 | GEAR SHIFT HANDLE (1 required per assembly) |
  |
|
804395 - GEAR SHIFT HANDLE NLA [ More info ] Unavailable |
| #24 | 10-852776 11 | BOLT (1 required per assembly) |
  |
|
10-852776 11 - BOLT NLA [ More info ] Unavailable |
| #25 | 13-852831 1 | WAVE WASHER (1 required per assembly) |
  |
|
13-852831 1 - WAVE WASHER NLA [ More info ] Unavailable |
| #26 | 23-852814 7 | BUSHING (1 required per assembly) |
  |
|
23-852814 7 - Bushing [ More info ] Unavailable |
| #27 | 11554M | COVER (1 required per assembly) |
  |
|
|
| #28 | 10-84058M | BOLT, (M6 x 20) (1 required per assembly) |
  |
|
10-84058M - Bolt [ More info ]
|
| #29 | 826985 1 | CABLE ASSEMBLY, Throttle (2 required per assembly) |
  |
|
826985 1 - Throttle Cable [ More info ] Unavailable |
| #30 | 87-97757M | SWITCH ASSEMBLY, Stop (1 required per assembly) |
  |
|
87-97757M - Switch Assembly, NLA [ More info ]
|
| #31 | 97756M | STOPPER (1 required per assembly) |
  |
|
97756M - Lanyard Stopper [ More info ]
|
| #32 | 19-852837 | CAP (1 required per assembly) |
  |
|
19-852837 - CAP NLA [ More info ] Unavailable |
