Parts for Mariner 15C Carburetor / Fuel Pump

Revise Search: All Models > 15C > M-684-000101 & Up > Carburetor / Fuel Pump

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#	84473M	CARBURETOR REPAIR KIT (1 required per assembly)
		84473M - Carburetor Repair Kit [ More info ] Unavailable
		84473T - Carburetor Repair Kit [ More info ] $69.46 1 In Stock.
#0-1	1383-8516M	CARBURETOR(684-53/54) (1 required per assembly)
		1383-8516M - Carburetor [ More info ] Unavailable
#0-1	1383-7148M	CARB(684-50) (1 required per assembly)
		1383-7148M - Carburetor [ More info ] Unavailable
#1	82600M	PILOT JET (#46) (AR required per assembly)
		82600M - JET,NLA [ More info ] Unavailable
#1	94561M	PILOT JET (#48) (AR required per assembly)
		94561M - JET,NLA [ More info ] Unavailable
#2	84376M	MAIN NOZZLE (684-50/53/54) (1 required per assembly)
		84376M - Main Nozzle,NLA [ More info ] Unavailable
#2	84251M	MAIN NOZZLE (684-51/52) (1 required per assembly)
		84251M - Main Nozzle, NLA [ More info ] Unavailable
#3	80447M	VALVE SEAT (1 required per assembly)
		80447M - Valve Seat [ More info ] $44.58 1 In Stock.
#4	12-80261M	WASHER (1 required per assembly)
		12-80261M - Washer, Valve Seat, NLA [ More info ] $1.67 $1.42 10+ In Stock.
#5	80202M	FLOAT ARM (1 required per assembly)
		80202M - Float Arm, NLA [ More info ] $7.78 $6.59 10+ In Stock.
#6	80450M	FLOAT (1 required per assembly)
		80450M - Float, NLA [ More info ] $26.66 $22.58 10+ In Stock.
#7	17-80201M	PIN (1 required per assembly)
		17-80201M - Pin, Float [ More info ] Unavailable
		17-80451M - Pin, NLA [ More info ] Unavailable
#8	27-43115M	GASKET (1 required per assembly)
		27-43115M - Float Chamber Gasket [ More info ] Unavailable
#9	84252M	FLOAT BOWL (1 required per assembly)
		84252M - Float Bowl, NLA [ More info ] $10.76 2 In Stock.
#10	84377M	MAIN JET (1 required per assembly)
		84377M - Jet, NLA [ More info ] $5.99 $5.07 6 In Stock.
#11	27-80267M	GASKET (1 required per assembly)
		27-80267M - Plug Gasket [ More info ] Unavailable
		27-80267 - Plug Gasket [ More info ] Unavailable
#12	10-80573M	IDLE MIXTURE SCREW (1 required per assembly)
		10-80573M - Screw, NLA [ More info ] Unavailable
#13	24-814460M	SPRING (1 required per assembly)
		24-814460M - Spring, NLA [ More info ] $6.00 $5.08 6 In Stock.
#14	10-814463M	IDLE SPEED SCREW - 684-53/54 (1 required per assembly)
		10-814463M - Screw-IDLE [ More info ] Unavailable
		10-83509M - Screw, NLA [ More info ] $1.79 10+ In Stock.
#14	10-80738M	IDLE SPEED SCREW - 684-50/51/52 (1 required per assembly)
		10-80738M - Screw, NLA [ More info ] $3.00 $2.54 5 In Stock.
#15	24-80966M	SPRING - 684-50/51/52 (1 required per assembly)
		24-80966M - SPRING,NLA [ More info ] Unavailable
#16	10-80434M	SCREW (2 required per assembly)
		10-80434M - Screw, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#17	84254M	THROTTLE ARM ASSEMBLY (1 required per assembly)
		84254M - Throttle Arm, NLA [ More info ] Unavailable
#18	10-80091M	SCREW (1 required per assembly)
		10-80091M - SCREW,NLA [ More info ] Unavailable
#19	84255M	COLLAR (1 required per assembly)
		84255M - COLLAR,NLA [ More info ] $3.50 1 In Stock.
#20	83300M	RETAINER (1 required per assembly)
		83300M - End, NLA [ More info ] Unavailable
#21	84256M	THROTTLE ROD (1 required per assembly)
		84256M - Throttle Rod, NLA [ More info ] Unavailable
#22	16333	RETAINER (1 required per assembly)
		16333 - Rod Snap [ More info ] Unavailable
#23	98992M	PLATE - 684-53/54 (1 required per assembly)
		98992M - Plate [ More info ] Unavailable
#24	27-98993M	GASKET - 684-53/54 (1 required per assembly)
		27-98993M - Gasket [ More info ] Unavailable
		27-98993T - Gasket [ More info ] $13.79 Available to Order: Shipping delay up to 10 days.
#25	10-82513M	SCREW - 684-53/54 (2 required per assembly)
		10-82513M - SCREW Note: Priced Individually [ More info ] Unavailable
		10-82500M - Screw, NLA [ More info ] $1.79 10+ In Stock.
#23	84258M	PLATE - 684-50/51/52 (1 required per assembly)
		84258M - PLATE,NLA [ More info ] Unavailable
#24	27-84259M	GASKET - 684-50/51/52 (1 required per assembly)
		27-84259M - Plate Gasket [ More info ] $8.61 10+ In Stock.
#25	10-83509M	SCREW - 684-50/51/52 (2 required per assembly)
#26	27-84261M	GASKET (1 required per assembly)
		27-84261M - Pump Gasket [ More info ] Unavailable
		27-815009M - Fuel Pump Gasket [ More info ] Unavailable
		27-815009 - Fuel Pump Gasket [ More info ] $18.09 2 In Stock.
#27	84262M	DIAPHRAGM (1 required per assembly)
		84262M - Diaphragm [ More info ] $38.49 Available to Order: Shipping delay up to 10 days.
#28	21-84650M	CHECK VALVE (684-50/51/52) (2 required per assembly)
		21-84650M - Check Valve, NLA [ More info ] $11.72 10+ In Stock.
#28	21-41888M	CHECK VALVE (684-53/54) (2 required per assembly)
		21-41888M - Check Valve [ More info ] $21.51 2 In Stock.
#29	97657M	BODY (684-53/54) (1 required per assembly)
		97657M - BODY [ More info ] Unavailable
		84263M - Body [ More info ] $36.99 Available to Order: Shipping delay up to 10 days.
#29	84263M	BODY (684-50/51/52) (1 required per assembly)
#30	27-84264M	GASKET (1 required per assembly)
		27-84264M - Cover Gasket [ More info ] Unavailable
		27-84264 - Fuel Pump Gasket [ More info ] $13.79 1 In Stock.
#31	84265M	DIAPHRAGM (1 required per assembly)
		84265M - Diaphragm [ More info ] $19.19 3 In Stock.
		18-7838 - Diaphragm, 84265M [ More info ] $9.99 $9.93 1 In Stock.
#32	84266M	COVER (1 required per assembly)
		84266M - Cover [ More info ] $12.00 $10.16 6 In Stock.
#33	10-80954M	SCREW (4 required per assembly)
		10-80954M - Screw, NLA [ More info ] $1.67 $1.42 10+ In Stock.
#34	10-94801M	SCREW - 684-53/54 (2 required per assembly)
		10-94801M - SCREW [ More info ] Unavailable
		10-813484M - Screw, NLA [ More info ] $1.25 $1.06 3 In Stock.
#35	11-82537M	NUT - 684-53/54 (2 required per assembly)
		11-82537M - Nut, NLA [ More info ] $1.63 $1.39 10+ In Stock.
