Parts for Mariner 15A HP Steering Handle
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 80775M | GRIP, STEERING HANDLE (1 required per assembly) |
  |
|
80775M - GRIP,NLA [ More info ] Unavailable |
| #2 | 80773M | HANDLE, THROTTLE (1 required per assembly) |
  |
|
80773M - STEERING HANDLE,NLA [ More info ] Unavailable |
| #3 | 80776M | INDICATOR, THROTTLE (1 required per assembly) |
  |
|
80776M - INDICATOR,NLA [ More info ] Unavailable |
| #4 | 17-81907M | RIVET, INDICATOR (1 required per assembly) |
  |
|
17-81907M - Rivet, NLA [ More info ]
|
| #5 | 17-81890M | PIN, THROTTLE HANDLE (1 required per assembly) |
  |
|
17-81890M - PIN,NLA [ More info ] Unavailable |
| #6 | 12-82933M | WASHER, THROTTLE HANDLE PIN (1 required per assembly) |
  |
|
12-82933M - Washer, Throttle Handle Pin, NLA [ More info ]
|
| #7 | 18-82050M | PIN, THROTTLE HANDLE PIN (1 required per assembly) |
  |
|
18-82050M - Cotter Pin, NLA [ More info ]
|
| #8 | 24-82094M | SPRING, THROTTLE SHAFT (1 required per assembly) |
  |
|
24-82094M - SPRING,NLA [ More info ] Unavailable |
| #9 | 12-81833M | WASHER, THROTTLE SHAFT (1 required per assembly) |
  |
|
12-81833M - WASHER,NLA [ More info ] Unavailable |
| #10 | 23-81954M | BUSHING, THROTTLE SHAFT (1 required per assembly) |
  |
|
23-81954M - Bushing,NLA [ More info ] Unavailable |
| #11 | 80772M | ARM, STEERING (S-11005 L-43620) (1 required per assembly) |
  |
80772M - Steering Arm [ More info ] Unavailable |
|
  |
|
83118M - ARM,NLA [ More info ] Unavailable |
| #12 | 80033M | HOLDER, SHEAR PIN (1 required per assembly) |
  |
|
80033M - Holder, NLA [ More info ]
|
| #13 | 10-81719M | SCREW, THROTTLE STOP (1 required per assembly) |
  |
|
10-81719M - SCREW-SET,NLA [ More info ] Unavailable |
| #14 | 11-82390M | NUT (1 required per assembly) |
  |
|
11-82390M - Nut, (M6) [ More info ]
|
| #15 | 80774M | SHAFT, THROTTLE (1 required per assembly) |
  |
|
80774M - SHAFT,NLA [ More info ] Unavailable |
| #16 | 80224M | GUIDE, THROTTLE SHAFT (1 required per assembly) |
  |
|
80224M - GUIDE,NLA [ More info ] Unavailable |
| #17 | 10-82498M | SCREW, SHAFT GUIDE ATTACHING (2 required per assembly) |
  |
|
10-82498M - SCREW,NLA [ More info ] Unavailable |
| #18 | 13-82208M | LOCK WASHER, GUIDE SCREW (2 required per assembly) |
  |
13-82208M - LOCKWASHER Note: Priced Individually [ More info ] Unavailable |
|
  |
|
13-82186M - LockWasher, NLA [ More info ]
|
| #19 | 23-81945M | BUSHING, STEERING ARM (1 required per assembly) |
  |
|
23-81945M - Bushing, NLA [ More info ]
|
| #20 | 43-82587M | CAM, THROTTLE SHAFT (1 required per assembly) SERIAL 00000000-00009770 |
  |
|
43-82587M - Gear, NLA [ More info ] Unavailable |
| #20 | 43-80778M | GEAR (1 required per assembly) SERIAL 00009771-09999999 |
  |
|
43-80778M - Gear, Pinion, NLA [ More info ]
|
| #21 | 17-82151M | PIN, THROTTLE SHAFT CAM (1 required per assembly) |
  |
|
17-82151M - Pin -roll [ More info ]
|
| #22 | 43-82586M | CAM, THROTTLE (1 required per assembly) SERIAL 00000000-00009770 |
  |
|
43-82586M - Gear, NLA [ More info ] Unavailable |
| #22 | 43-80777M | PINION (1 required per assembly) SERIAL 00000000-00009771 |
  |
|
43-80777M - Pinion Gear [ More info ] Unavailable |
| #23 | 10-82167M | SCREW, THROTTLE CAM ATTACHING (1 required per assembly) |
  |
10-82167M - SCREW Note: Priced Individually [ More info ] Unavailable |
|
  |
|
10-95209M - Screw, NLA [ More info ]
|
| #23 | 10-82168M | SCREW (1 required per assembly) SERIAL 00000000-00009771 |
  |
|
10-82168M - Screw, NLA [ More info ]
|
| #24 | 23-82717M | SPACER, CAM SCREW ( ) (1 required per assembly) SERIAL 00000000-00009770 |
  |
|
23-82717M - SPACER,NLA [ More info ] Unavailable |
| #24 | 23-81974M | SPACERS () (4 required per assembly) SERIAL 00009771-09999999 |
  |
|
23-81974M - Spacer, NLA [ More info ]
|
| #25 | 13-82212M | LOCK WASHER (1 required per assembly) |
  |
|
13-82212M - LockWasher - Priced Individually [ More info ]
|
| #26 | 80758M | CABLE, THROTTLE (2 required per assembly) |
  |
|
80758M - Wire, NLA [ More info ] Unavailable |
| #27 | 80779M | BRACKET, STEERING (1 required per assembly) |
  |
|
80779M - Bracket, NLA [ More info ] Unavailable |
| #28 | 10-82471M | BOLT, STEERING ARM ATTACHING (1 required per assembly) |
  |
|
10-82471M - BOLT,NLA [ More info ] Unavailable |
| #29 | 13-82215M | LOCK WASHER, STEERING ARM BOLT (1 required per assembly) |
  |
|
13-82215M - LockWasher - Priced Individually [ More info ]
|
| #30 | 13-81799M | WASHER, STEERING ARM BOLT (1 required per assembly) |
  |
|
13-81799M - LockWasher, NLA [ More info ] Unavailable |
| #31 | 23-81977M | COLLAR, STEERING ARM BOLT (1 required per assembly) |
  |
|
23-81977M - SPACER,NLA [ More info ] Unavailable |
| #32 | 12-80223M | SPACER, STEERING ARM (2 required per assembly) |
  |
|
12-80223M - WASHER,NLA [ More info ] Unavailable |
| #33 | 80226M | STOP, STEERING ARM (1 required per assembly) |
  |
|
80226M - STOP,NLA [ More info ] Unavailable |
| #34 | 10-82453M | BOLT, BRACKET ATTACHING (4 required per assembly) |
  |
10-82453M - Bolt - Priced Individually [ More info ] Unavailable |
|
  |
|
10-82405M - Screw, NLA [ More info ]
|
| #35 | 83118M | ARM, STEERING (1 required per assembly) SERIAL 00011006-00012755 |
| #36 | 82895M | PIECE, FRICTION (1 required per assembly) SERIAL 00011006-00012755 |
  |
|
82895M - Guide, NLA [ More info ]
|
| #37 | 10-82452M | BOLT (1 required per assembly) SERIAL 00011006-00012755 |
  |
|
10-82452M - Bolt - Priced Individually [ More info ]
|
  |
|
10-84058M - Bolt [ More info ]
|
| #38 | 11-83056M | NUT (1 required per assembly) SERIAL 00011006-00012755 |
  |
|
11-83056M - Nut, Nylon, NLA [ More info ]
|
| #39 | 11-82399M | NUT (1 required per assembly) |
  |
11-82399M - NUT Note: Priced Individually [ More info ] Unavailable |
|
| #40 | 80759M | ADJUSTER, CABLE (2 required per assembly) |
  |
|
80759M - Adjuster, NLA [ More info ] Unavailable |
| #41 | 11-81777M | NUT, CABLE GUIDE (2 required per assembly) |
  |
|
11-81777M - Nut, Cable Guide,NLA [ More info ] Unavailable |
