Parts for Mariner 15A HP Gear Shift Linkage
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 80893M | HANDLE, GEAR SHIFT (1 required per assembly) |
  |
|
80893M - Handle, NLA [ More info ]
|
| #2 | 17-82158M | PIN, SHIFT HANDLE (1 required per assembly) |
  |
|
17-82158M - Pin -roll, NLA [ More info ]
|
| #3 | 12-81856M | WASHER, SHIFT HANDLE (1 required per assembly) |
  |
|
12-81856M - Washer, Shift Handle, NLA [ More info ]
|
| #4 | 80894M | CAM, SHIFT (1 required per assembly) |
  |
|
80894M - CAM,NLA [ More info ] Unavailable |
| #5 | 23-80228M | RETAINER, SHIFT DETENT (1 required per assembly) |
  |
|
23-80228M - Bushing, NLA [ More info ]
|
| #6 | 24-82082M | SPRING, SHIFT DETENT (1 required per assembly) |
  |
|
24-82082M - Spring, Shift Detent,NLA [ More info ] Unavailable |
| #7 | 82347M | BALL, SHIFT DETENT (1 required per assembly) |
  |
|
82347M - Ball, NLA [ More info ] Unavailable |
| #8 | 25-82264M | O-RING, SHIFT CAM (1 required per assembly) |
  |
|
25-82264M - O-ring, Shift Cam,NLA [ More info ]
|
| #9 | 23-81934M | BUSHING, SHIFT CAM (2 required per assembly) |
  |
|
23-81934M - Bushing, NLA [ More info ] Unavailable |
| #10 | 17-82366M | PIN, DOWEL-SHIFT CAM STOP (1 required per assembly) |
  |
|
17-82366M - DOWEL PIN,NLA [ More info ] Unavailable |
| #11 | 80892M | SHIFT ROD ASS'Y (1 required per assembly) |
  |
|
80892M - Shift Rod,NLA [ More info ] Unavailable |
| #12 | 82589M | BRACKET, SHIFT SHAFT (1 required per assembly) SERIAL 00000000-00009770 |
  |
|
82589M - Bracket, NLA [ More info ] Unavailable |
| #13 | 80896M | BRACKET, SHIFT SHAFT (1 required per assembly) SERIAL 00009771-09999999 |
  |
|
80896M - Bracket, NLA [ More info ] Unavailable |
| #14 | 13-81867M | WASHER, BRACKET (2 required per assembly) SERIAL 00000000-00009770 |
  |
|
13-81867M - Wave Washer, NLA [ More info ] Unavailable |
| #15 | 12-82217M | WASHER (1 required per assembly) |
  |
|
12-82217M - Washer, NLA [ More info ]
|
| #16 | 18-82736M | PIN, SHIFT CAM (1 required per assembly) SERIAL 00000000-00009770 |
  |
18-82736M - COTTER PIN Note: Priced Individually [ More info ] Unavailable |
|
  |
18-82126M - COTTER PIN Note: Priced Individually [ More info ] Unavailable |
|
  |
|
18-43089M - PIN-COTTER,NLA [ More info ] Unavailable |
| #16 | 18-82129M | PIN, SHIFT CAM (1 required per assembly) SERIAL 00009771-00012755 |
  |
18-82129M - Pin, Cotter [ More info ] Unavailable |
|
  |
|
18-84301M - Cotter Pin, NLA [ More info ]
|
| #16 | 18-82752M | PIN, SHIFT CAM (1 required per assembly) SERIAL 00012756-09999999 |
  |
18-82752M - Pin, Cotter [ More info ] Unavailable |
|
  |
|
18-82128M - Cotter Pin, NLA [ More info ]
|
| #17 | 23-82720M | COLLAR (1 required per assembly) SERIAL 00000000-00009770 |
  |
|
23-82720M - SPACER,NLA [ More info ] Unavailable |
| #18 | 17-81886M | PIN, W/HOLE (1 required per assembly) SERIAL 00009771-09999999 |
  |
|
17-81886M - Pin, NLA [ More info ] Unavailable |
| #19 | 13-81865M | WASHER, WAVE-SHIFT CAM (1 required per assembly) |
  |
|
13-81865M - Wave Washer - Priced Individually [ More info ]
|
| #20 | 12-82194M | WASHER, SHIFT CAM (1 required per assembly) |
  |
12-82194M - WASHER Note: Priced Individually [ More info ] Unavailable |
|
  |
|
12-82209M - Washer, NLA [ More info ]
|
| #22 | 10-82422M | BOLT, BRACKET ATTACHING (2 required per assembly) |
  |
10-82422M - SCREW Note: Priced Individually [ More info ] Unavailable |
|
  |
10-84247M - BOLT Note: Priced Individually [ More info ] Unavailable |
|
  |
10-91725M - BOLT [ More info ] Unavailable |
|
  |
|
10-826957M - Bolt, NLA [ More info ]
|
| #23 | 13-82197M | LOCK WASHER, BRACKET BOLT (2 required per assembly) |
  |
13-82197M - LockWasher - Priced Individually [ More info ] Unavailable |
|
  |
|
13-82212M - LockWasher - Priced Individually [ More info ]
|
| #24 | 11-82390M | NUT, JAM (1 required per assembly) |
  |
|
11-82390M - Nut, (M6) [ More info ]
|
| #25 | 11-81763M | CONNECTOR (1 required per assembly) |
  |
|
11-81763M - Nut, NLA [ More info ]
|
