Parts for Mariner 15A HP Fuel Pump
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #0-1 | 81328M | FUEL PUMP ASS'Y (1 required per assembly) |
  |
81328M - Fuel Pump [ More info ] Unavailable |
|
  |
94799M - Fuel Pump [ More info ] Unavailable |
|
  |
43113M - Fuel Pump [ More info ] Unavailable |
|
  |
|
43113T - Fuel Pump [ More info ]
|
| #1 | 80606M | DIAPHRAGM, FUEL PUMP (2 required per assembly) |
  |
|
80606M - Fuel Pump Diaphragm [ More info ]
|
  |
|
18-7839 - Fuel Pump Diaphragm, 80606M, & Yamaha [ More info ]
|
| #2 | 80611M | PLATE, SPRING GUIDE (2 required per assembly) |
  |
|
|
| #3 | 24-80610M | SPRING, FUEL PUMP DIAPHRAGM (1 required per assembly) |
  |
|
24-80610M - Spring, Fuel Pump Diahragm,NLA [ More info ]
|
| #4 | 27-80613M | GASKET, BODY TO BASE (2 required per assembly) |
  |
|
27-80613M - Body To Base Gasket [ More info ]
|
  |
|
27-80613 - Body To Base Gasket [ More info ]
|
| #5 | 21-80608M | CHECK VALVE, FUEL PUMP (2 required per assembly) |
  |
|
21-80608M - Check Valve, NLA [ More info ] Unavailable |
| #6 | 27-80612M | GASKET, CHECK VALVE (2 required per assembly) |
  |
|
27-80612M - Check Valve Gasket [ More info ]
|
| #7 | 80609M | RETAINER, CHECK VALVE (2 required per assembly) |
  |
|
80609M - Retainer,NLA [ More info ] Unavailable |
| #8 | 10-82511M | SCREW, RETAINER ATTACHING (2 required per assembly) |
  |
|
10-82511M - Screw, NLA [ More info ]
|
| #9 | 11-82373M | NUT, RETAINER SCREW (2 required per assembly) |
  |
11-82373M - Nut, Retainer Screw [ More info ] Unavailable |
|
  |
|
11-82537M - Nut, NLA [ More info ]
|
| #10 | 24-80615M | SPRING, FUEL PUMP DIAPHRAGM (1 required per assembly) |
  |
|
24-80615M - Spring, Fuel Pump Diaphragm,NLA [ More info ] Unavailable |
| #11 | 27-80614M | GASKET, BODY TO COVER (1 required per assembly) |
  |
|
27-80614M - Cover To Body Gasket [ More info ]
|
  |
|
27-80614 - Body To Cover Gasket [ More info ]
|
| #12 | 80607M | COVER, FUEL PUMP (1 required per assembly) |
  |
|
80607M - Cover [ More info ] Unavailable |
| #13 | 10-82523M | SCREW, COVER ATTACHING (3 required per assembly) |
  |
10-82523M - SCREW Note: Priced Individually [ More info ] Unavailable |
|
  |
|
10-82522M - Screw, NLA [ More info ] Unavailable |
| #14 | 13-82208M | LOCK WASHER, COVER SCREW (3 required per assembly) |
  |
13-82208M - LOCKWASHER Note: Priced Individually [ More info ] Unavailable |
|
  |
|
13-82186M - LockWasher, NLA [ More info ]
|
| #15 | 27-80757M | GASKET, FUEL PUMP TO CRANKCASE (1 required per assembly) |
  |
|
27-80757M - Fuel Pump To Crankcase Gasket [ More info ]
|
  |
|
27-80757 - Fuel Pump Mounting Gasket [ More info ]
|
| #16 | 10-82428M | BOLT, FUEL PUMP ATTACHING (2 required per assembly) |
  |
10-82428M - SCREW Note: Priced Individually [ More info ] Unavailable |
|
  |
|
10-827043M - Bolt, NLA [ More info ]
|
| #17 | 13-82197M | LOCK WASHER, PUMP BOLT (2 required per assembly) |
  |
13-82197M - LockWasher - Priced Individually [ More info ] Unavailable |
|
  |
|
13-82212M - LockWasher - Priced Individually [ More info ]
|
