Parts for Force 90 HP (1991-1992) Ignition Components (Ser.# E039024, E093699)

Revise Search: All Models > 90 HP (1991-1992) > 1991E - 1992C ( ) > Ignition Components (Ser.# E039024, E093699)

« Previous

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#	800-817608A17	POWERHEAD ASSEMBLY
		800-817608A17 - Powerhead [ More info ] Unavailable
		800-817608A20 - Powerhead [ More info ] Unavailable
		800-817608A22 - Powerhead KIT,NLA [ More info ] Unavailable
#	56762	CABLE TIE (4") (3 required per assembly)
		56762 - Tie Strap - Priced Individually [ More info ] $0.50 3 In Stock.
#	800-817608A 6	POWERHEAD ASSEMBLY
		800-817608A 6 - Powerhead [ More info ] Unavailable
#1	11-F1968	NUT (3/4-16) (1 required per assembly)
		11-F1968 - Nut (3/4-16) [ More info ] $19.69 10+ In Stock.
#2	200-817494A 2	FLYWHEEL ASSEMBLY (1 required per assembly)
		200-817494A 2 - Flywheel [ More info ] Unavailable
		200-859241T 4 - Flywheel [ More info ] Unavailable
		200-859241T 8 - Flywheel [ More info ] Unavailable
		200-859241T10 - Flywheel [ More info ] $745.99 Available to Order: Shipping delay up to 10 days.
#3	FA609853	DECAL KIT, SHIFT TO NEUTRAL (1 required per assembly)
		FA609853 - Decal Kit [ More info ] Unavailable
		37-825149A 1 - Decal Kit [ More info ] Unavailable
#4	817029A 9	TRIGGERASSEMBLY (1 required per assembly)
		817029A 9 - Trigger Assembly -3 Cylinder [ More info ] $176.49 Available to Order: Shipping delay up to 10 days.
		18-99419 - Trigger, 3 Cylinder, 817029A3, A9, 134-7029-3 [ More info ] $144.79 $140.92 1 In Stock.
#5	13-F2442	WASHER, WAVE (1 required per assembly)
		13-F2442 - Wave Washer, NLA [ More info ] $9.12 10+ In Stock.
#6	819111	GUARD, IGNITION HARNESS (1 required per assembly)
		819111 - Guard, NLA [ More info ] $6.00 $5.08 3 In Stock.
#7	84-817441A 3	HARNESS ASSEMBLY, GROUND (1 required per assembly)
		84-817441A 3 - Harness Assembly, NLA [ More info ] Unavailable
#8	54-816311	CABLE TIE (8") (4 required per assembly)
		54-816311 - TIE STRAP Note: Priced Individually [ More info ] Unavailable
		54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ] $0.60 10+ In Stock.
#9	88-19637	SOCKET ASSEMBLY, FUSE (1 required per assembly)
		88-19637 - Socket [ More info ] $39.08 Available to Order: Shipping delay up to 10 days.
#10	16-826393	STUD (5/16-18 X 2-1/4")W/DL (4 required per assembly) SERIAL 0E039024-0E065371
		16-826393 - Stud, NLA [ More info ] Unavailable
#11	23-F722932	SPACER, ELECTRICAL BRACKET (4 required per assembly) SERIAL 0E039024-0E065371
		23-F722932 - Spacer, NLA [ More info ] $5.39 7 In Stock.
#12	817268 5	PLATE, IGNITION MOUNTING (1 required per assembly)
		817268 5 - PLATE-IGN-3 CYL [ More info ] Unavailable
		817268 6 - Ignition Mount Plate, NLA [ More info ] $34.50 7 In Stock.
#13	18495A12	SWITCHBOX ASSEMBLY (1 required per assembly)
		18495A12 - Switch Box Assembly [ More info ] Unavailable
		18495A19 - Switch Box [ More info ] Unavailable
		18495A26 - Switch Box Assembly [ More info ] $442.49 Available to Order: Shipping delay up to 10 days.
		18-5790-1 - Switch Box, 3 cylinder, 18495A26 Mercury (CDI 114-4953) [ More info ] $404.92 1 In Stock.
		18-5790 - Switch Box Assembly 18495A2 [ More info ] $418.99 $407.62 5 In Stock.
#14	10-812987	SCREW (10-24 X 1-1/4") (3 required per assembly)
		10-812987 - Screw [ More info ] $1.00 $0.21 10+ In Stock.
#15	10-41805	SCREW (10-24 X 5/8") (1 required per assembly)
		10-41805 - SCREW [ More info ] Unavailable
		10-41805 1 - Screw [ More info ] $2.79 Available to Order: Shipping delay up to 10 days.
#16	84-88807A29	CABLE ASSEMBLY (BLACK) (1 required per assembly)
		84-88807A29 - Cable Assembly [ More info ] Unavailable
#17	10-76566	SCREW (10-24 X 1") (6 required per assembly) SERIAL 0E039024-0E065371
		10-76566 - Screw [ More info ] Unavailable
		10-19926100 - Screw - Priced Individually [ More info ] $4.99 Available to Order: Shipping delay up to 10 days.
#17	10-19926100	SCREW (10-24 X 1") W/DL (6 required per assembly) SERIAL 0E065372-0E093699
#18	13-26996	LOCKWASHER (#10) (6 required per assembly) SERIAL 0E039024-0E065371
		13-26996 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#19	12-31247	WASHER (1 required per assembly)
		12-31247 - Washer, NLA [ More info ] $1.96 10+ In Stock.
#20	43542	COVER, COIL (1 required per assembly)
		43542 - Coil Cover [ More info ] Unavailable
#21	10-817458	SCREW (10-24 X 2-1/4") (6 required per assembly)
		10-817458 - Screw, NLA [ More info ] $1.25 $1.06 7 In Stock.
#22	339-7370A23	COIL ASSEMBLY, IGNITION (3 required per assembly)
		339-7370A23 - COIL ASSY [ More info ] Unavailable
		339-832757A 3 - COIL ASSY [ More info ] Unavailable
		339-832757A 4 - Ignition Coil [ More info ] Unavailable
		8M0230859 - Ignition Coil [ More info ] $124.33 3 In Stock.
		18-5186 - Ignition Coil 339-7370A13 [ More info ] $61.99 $58.62 9 In Stock.
#23	11-45076	NUT (10-24) (6 required per assembly)
		11-45076 - Nut (#10-32) (brass) [ More info ] $1.80 10+ In Stock.
#24	11-F7006	NUT (5/16-18) (3 required per assembly)
		11-F7006 - Nut (5/16-18) [ More info ] Unavailable
		11-26484 - Nut (5/16-18) [ More info ] $3.32 10+ In Stock.
		11-8M0204646 - NUT @5 [ More info ] Unavailable
#25	25-64872	GROMMET (1 required per assembly)
		25-64872 - Grommet, Poppet Relief Valve [ More info ] $3.59 10+ In Stock.
#26	84-821945A28	CABLE ASSEMBLY, HIGH TENSION (3 required per assembly)
		84-821945A28 - Cable Assembly [ More info ] Unavailable
		84-821945T28 - Cable Assembly [ More info ] $15.09 6 In Stock.
#27	33-827C	SPARK PLUG (CHAMPION # L-76V) (3 required per assembly)
		33-827C - SP #L76V Note: Priced Individually [ More info ] Unavailable
		33-896329827 - Spark Plug - L76V - Priced Individually [ More info ] Unavailable
		L76V - Champion Spark Plug ( #827M) [ More info ] $15.33 10+ In Stock.
#27	33-898	SPARK PLUG (RFI) (CHAMPION # QL-76V) (OPT. required per assembly)
		33898 - Rod, NLA [ More info ] Unavailable
		33-896329898 - Spark Plug - QL76V - Priced Individually [ More info ] Unavailable
		QL76V - Champion Spark Plug ( #898M) [ More info ] $23.44 10+ In Stock.
#28	817411 1	RECTIFIER/REGULATOR (1 required per assembly) SERIAL 0E039024-0E065371
		817411 1 - RECT/REG-(BULLET) [ More info ] Unavailable
		815279T 4 - REG KIT-VOLT-BULL [ More info ] Unavailable
		815279T 5 - Voltage Regulator [ More info ] Unavailable
		830179A 1 - Voltage Regulator [ More info ] Unavailable
		854514A 1 - Voltage Regulator [ More info ] Unavailable
		883071A 1 - Voltage Regulator [ More info ] $372.49 Available to Order: Shipping delay up to 10 days.
		18-5743-1 - Voltage Regulator, Mercury [ More info ] $199.66 $184.76 Available to Order: Shipping delay up to 10 days.
#28	815279T 4	VOLTAGE REGULATOR (1 required per assembly) SERIAL 0E065372-0E093699
#29	88-812619	FUSE (20 AMP) (1 required per assembly)
		88-812619 - Fuse - Yellow - 20 Amp [ More info ] $4.69 10+ In Stock.
#30	10-817505	SCREW (1/4-20 X 5/8") (2 required per assembly) SERIAL 0E039024-E0654371
		10-817505 - Screw [ More info ] $2.89 Available to Order: Shipping delay up to 10 days.
#30	10-817504	SCREW (1/4-20 X 1-1/2") (2 required per assembly) SERIAL 0E065372-0E093699
		10-817504 - Screw [ More info ] $4.79 2 In Stock.
#31	398-8778A29	STATOR ASSEMBLY (1 required per assembly)
		398-8778A29 - REF PARTSBU,NLA [ More info ] Unavailable
#32	37-819526	DECAL, THROTTLE CABLE ADJUSTMENT (1 required per assembly)
		37-819526 - Decal - Cable Adj, NLA [ More info ] Unavailable
