Parts for Force 85 HP (1988) Motor Leg

Revise Search: All Models > 85 HP (1988) > 858S8A ( ) > Motor Leg

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#	F631133	MOTOR LEG (25 INCH MODELS) (1 required per assembly)
		F631133 - LEG-MOTOR [ More info ] Unavailable
		1500-F631133-1 - LEG-MOTOR [ More info ] Unavailable
		1500-819433A 1 - LEG KIT-25 INCH [ More info ] Unavailable
		1500-819433A 2 - Housing Kit-25 I,NLA [ More info ] Unavailable
#	F500615	ROD, GEAR SHIFT UPPER (25 INCH MODELS) (1 required per assembly)
		F500615 - F5006152 [ More info ] Unavailable
		F500615-2 - Shift Rod -25 Inc, NLA [ More info ] Unavailable
#1	F85660-1	EXHAUST TUBE (1 required per assembly)
		F85660-1 - Exhaust Tube, NLA [ More info ] Unavailable
#2	F8083	SPRING LOCKWASHER (4 required per assembly)
		F8083 - LockWasher SS [ More info ] Unavailable
		13-26992 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#3	F1864	HEX SLOT HD. SCREW, 1/4 -20 X 3/4 (4 required per assembly)
		10-F1864 - Screw SS [ More info ] Unavailable
		10-28636 - Screw - Priced Individually [ More info ] $1.80 10+ In Stock.
#4	F85258	INSERT (1 required per assembly)
		F85258 - Idle Exhaust Boot Insert [ More info ] Unavailable
		816513 - Idle Exhaust Boot Insert [ More info ] Unavailable
#5	F85130	BOOT, IDLE EXHAUST (1 required per assembly)
		F85130 - Exhaust Boot [ More info ] Unavailable
		895012 - BOOT-EXHAUST [ More info ] Unavailable
		895012A01 - Exhaust Boot Kit [ More info ] $26.03 2 In Stock.
#6	F85380	SPRING (1 required per assembly)
		24-F85380 - Spring, Idle Exhaust Boot [ More info ] $5.09 1 In Stock.
#7	F85772	CLAMP (1 required per assembly)
		54-F85772 - Clamp [ More info ] $5.98 3 In Stock.
#8	F1729	PLUG (2 required per assembly)
		19-F1729 - Plug, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#9	F178145-4	COVER, MOTOR LEG REAR (1 required per assembly)
		F178145-4 - Motor Leg Cover [ More info ] Unavailable
		817931A 6 - Cover [ More info ] Unavailable
		817931A 7 - COVER KIT-LEG,NLA [ More info ] Unavailable
#10	F1664	SPRING PIN (2 required per assembly)
		17-F1664 - Spring, Pin [ More info ] $2.40 $2.03 9 In Stock.
#11	F1263	HEX SOCKET HD. CAP SCREW, 5/16 - 18 X 9/16 (2 required per assembly)
		10-F1263 - Screw -ss [ More info ] $15.00 10+ In Stock.
#12	F438962	MOUNT, LOWER REAR SHOCK (2 required per assembly)
		F438962 - Shock Mount, NLA [ More info ] $16.00 $13.55 2 In Stock.
#13	F178323	SEAL (1 required per assembly)
		F178323 - Motor Leg Seal, NLA [ More info ] Unavailable
#14	F523133-2	MOTOR LEG (20 INCH MODELS) (1 required per assembly)
		F523133-2 - Housing - Leg [ More info ] Unavailable
		1500-817983A 2 - Housing Kit, 20 Inch [ More info ] Unavailable
		1500-819432A 1 - Housing Kit-20 IN [ More info ] Unavailable
		1500-819432A 2 - Housing Kit-20 I,NLA [ More info ] Unavailable
#15	F2093	STOP NUT, 3/8 - 24 (2 required per assembly)
		11-F2093 - Nut, (.375-24) [ More info ] Unavailable
		11-34863 - Nut (3/8-24) [ More info ] Unavailable
		11-826709113 - Nut, (.375-24) Stainless Steel [ More info ] Unavailable
		11-8M0042636 - Nut - Brass , Priced Individually [ More info ] Unavailable
		118M0204726 - NUT-BRASS Note: Priced Individually [ More info ] $1.80 10 In Stock.
#16	F5H094	STEERING LINK KIT (1 required per assembly)
		F5H094 - Steering Link Kit [ More info ] $78.27 $66.30 10+ In Stock.
#17	F8038	WASHER (2 required per assembly)
		12-F8038 - Washer [ More info ] Unavailable
		12-37828 - Washer, (.390 X .625 X .062) Stainless Steel [ More info ] $0.80 2 In Stock.
#18	F523300-1	SPRING (1 required per assembly)
		24-F523300-1 - Spring-Steering Link,NLA [ More info ] $8.61 10+ In Stock.
#19	F1280	PAN HD. SCREW, 8 - 32 X 1/4 (1 required per assembly)
		10-F1280 - Screw -ss [ More info ] $0.55 $0.46 10+ In Stock.
		108M0129582 - Screw [ More info ] $0.61 Available to Order: Shipping delay up to 10 days.
#20	F8080	SPRING LOCKWASHER (1 required per assembly)
		F8080 - Lock Washer - Priced Individually [ More info ] Unavailable
		13-26995 - Lock Washer - Priced Individually [ More info ] Unavailable
#21	F523930	RETAINER (1 required per assembly)
		F523930 - Retainer, NLA [ More info ] Unavailable
#22	F523273	STUD (1 required per assembly)
		F523273 - Steering Ball Stud [ More info ] $6.52 $5.53 10+ In Stock.
#23	F1696	HEX BOLT, 5/16 - 18 X 1 (8 required per assembly)
		10-F1696 - Screw SS [ More info ] $1.29 10+ In Stock.
		10-69267 - Screw [ More info ] $1.90 $0.38 10+ In Stock.
#24	F2030	HEX HD. SCREW, 1/4 - 20 X 1-1/4 (6 required per assembly)
		10-F2030 - Screw -ss [ More info ] $3.39 10+ In Stock.
#25	F686660	STAND TUBE (2 required per assembly)
		F686660 - Standtube, NLA [ More info ] Unavailable
		816515 - Standtube, NLA [ More info ] $18.31 10+ In Stock.
#26	F1871	HEX HD. SCREW, 3/8 - 16 X 3/4 (4 required per assembly)
		F1871 - Screw [ More info ] Unavailable
		10-98261 - Screw [ More info ] $1.20 5 In Stock.
#27	F2014	WASHER (2 required per assembly)
		F2014 - Washer [ More info ] $0.49 3 In Stock.
		12-34931 - Washer, (.406 X .734 X .063 - Stainless Steel) [ More info ] $2.59 10+ In Stock.
#28	FA85355-1	WASHER SET (2 required per assembly)
		FA85355-1 - WASHER KIT,NLA [ More info ] Unavailable
#29	F2018	LOCKNUT (2 required per assembly)
		11-F2018 - Nut -ss, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#30	F1987	WASHER (1 required per assembly)
		F1987 - Washer - Priced Individually [ More info ] $0.25 10+ In Stock.
		12-34437 - Washer (5/16 In. I.d.) [ More info ] $2.89 Available to Order: Shipping delay up to 10 days.
#31	F85965	MOUNT, UPPER SHOCK (2 required per assembly)
		F85965 - Shock Mount [ More info ] $89.99 $76.21 1 In Stock.
#32	F1703	SPRING, LOCKWASHER (2 required per assembly)
		F1703 - LockWasher - Priced Individually [ More info ] $0.30 3 In Stock.
		13-35048 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#34	F85615-1	ROD, GEAR SHIFT UPPER (20 INCH MODELS) (1 required per assembly)
		F85615-1 - Shift Rod, NLA [ More info ] Unavailable
#35	F438346	MOUNT, LOWER SHOCK (1 required per assembly)
		F438346 - Lower Shock Mount [ More info ] $73.32 9 In Stock.
		803714T - Shock Mount [ More info ] $73.32 $62.11 10+ In Stock.
#36	F85704	COUPLER, GEAR SHIFT ROD (1 required per assembly)
		F85704 - Gear Shift Rod Coupler [ More info ] Unavailable
#37	F8096	SPRING LOCKWASHER (4 required per assembly)
		F8096 - LockWasher - Priced Individually [ More info ] Unavailable
		13-53166 - LockWasher - Priced Individually [ More info ] $1.80 10+ In Stock.
#38	F1822	HEX BOLT, 5/16 - 18 X 7/8 (4 required per assembly)
		10-F1822 - Screw -ss [ More info ] Unavailable
		10-28782 - Screw - Priced Individually [ More info ] $2.99 10+ In Stock.
#39	FA85135-4	COVER, FRONT LEG (1 required per assembly)
		FA85135-4 - FK719135, NLA [ More info ] Unavailable
		FK719135 - FK719135, NLA [ More info ] Unavailable
		FK719135F - COVER KIT-LEG,NLA [ More info ] Unavailable
#40	F85606	CAP, KING PIN (20 INCH MODELS) (1 required per assembly)
		F85606 - FK85606, NLA [ More info ] Unavailable
		FK85606 - Kingpin Cap Kit, NLA [ More info ] Unavailable
#41	F631606	CAP, KING PIN (25 INCH MODELS) (1 required per assembly)
		F631606 - FK631606, NLA [ More info ] Unavailable
		FK631606 - CAP KT-KINGPIN-2,NLA [ More info ] Unavailable
#42	F631707	COVER, STOCK MOUNT LOWER (25 INCH MODELS) (1 required per assembly)
		F631707 - F631707F, NLA [ More info ] Unavailable
		F631707F - COVER-SHOCK MT-2 [ More info ] Unavailable
#43	F1515	HEX NUT, 5/16 - 18 (4 required per assembly)
		F1515 - Hex Hut, 5/16 - 18 [ More info ] $0.30 10+ In Stock.
		11-68292 - Nut (5/16 Inch) [ More info ] $1.50 10+ In Stock.
		11-8M0204668 - NUT @5 [ More info ] Unavailable
#45	F1912	HED HD. SCREW, 10 - 24 X 1/2 (4 required per assembly)
		10-F1912 - Screw, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#46	F85779-1	BAFFLE, AIR INTAKE (1 required per assembly)
		F85779-1 - FK692779, NLA [ More info ] Unavailable
		FK692779 - Baffle Assembly, NLA [ More info ] Unavailable
#47	F598387	DECAL, POWER FLOW (1 required per assembly)
		37-F598387 - DECAL,NLA [ More info ] Unavailable
