Parts for Force 85 HP (1987) Electrical Components

Revise Search: All Models > 85 HP (1987) > 0C856F7A ( ) > Electrical Components

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#	817929 1	KEY IGNITION - STAMPED E
		817929 1 - Key Set - Stamped E [ More info ] $5.28 8 In Stock.
#	F1877	TY-RAP (NOT SHOWN) (1 required per assembly)
		F1877 - TY RAP [ More info ] Unavailable
		54-816311 - TIE STRAP Note: Priced Individually [ More info ] Unavailable
		54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ] $0.60 10+ In Stock.
#	817891 1	KEY IGNITION - STAMPED C
		817891 1 - Key Set - Stamped C [ More info ] $5.43 10+ In Stock.
#	FA27232	EMERGENCY STARTER ROPE (NOT SHOWN) (1 required per assembly)
		FA27232 - ROPE W/HANDLE [ More info ] Unavailable
		50-12066A 9 - Starter Rope , Priced Individually [ More info ] Unavailable
		50-12066Q 9 - Starter Rope , Priced Individually [ More info ] Unavailable
		50-12066Q10 - Starter Rope - Priced Individually [ More info ] $13.59 6 In Stock.
		18-4915 - Pull Rope, 50-12066Q9 [ More info ] $4.79 $4.45 Available to Order: Shipping delay up to 10 days.
		50-12066K10 - Starter Rope - Priced Individually [ More info ] $14.99 4 In Stock.
#	817928 1	KEY IGNITION - STAMPED D
		817928 1 - Key Set - Stamped D [ More info ] $6.23 3 In Stock.
#	817883 1	KEY IGNITION - STAMPED B
		817883 1 - Key Set - Stamped B [ More info ] $5.28 3 In Stock.
#1	F2016	SLOTTED FILL HD. SCREW, 6 - 32 X 7/8 (2 required per assembly)
		10-F2016 - Screw -ss, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#2	F8088	PLAIN WASHER (2 required per assembly)
		12-F8088 - Washer - Priced Individually [ More info ] Unavailable
		12-27882 - Washer - Priced Individually [ More info ] $1.27 10+ In Stock.
#3	F84449	NEUTRAL INTERLOCK SWITCH (1 required per assembly)
		87-F84449 - Switch [ More info ] Unavailable
#4	F1704	INTERNAL TOOTH LOCKWASHER (6 required per assembly)
		13-F1704 - LockWasher [ More info ] $0.70 $0.60 10 In Stock.
#5	F1645	HD. SCREW, 6 - 32 X 1/4 (8 required per assembly)
		F1645 - Screw [ More info ] Unavailable
		10-69080 - Screw [ More info ] Unavailable
#6	F629449	THERMOSWITCH (1 required per assembly)
		F629449 - F6294492, NLA [ More info ] Unavailable
		F629449-2 - ThermoSwitch [ More info ] $86.96 2 In Stock.
#7	F8056	SPRING LOCKWASHER (2 required per assembly)
		13-F8056 - LockWasher [ More info ] $0.98 $0.83 10+ In Stock.
#8	F1647	HEX NUT, 8 - 32 (2 required per assembly)
		11-F1647 - Nut, (#8-32)(Stainless Steel) NLA [ More info ] Unavailable
#9	F650450	RECTIFIER (1 required per assembly) W/ILLUS. 4, 5, 70 AND LITERATURE
		87-F650450 - Rectifier [ More info ] $43.99 2 In Stock.
		FK650450 - Rectifier Kit [ More info ] Unavailable
		18-99429 - Uinversal Recifier 2, 3 & 4 Cylinder FK650450, 152-9209 [ More info ] $70.19 In Stock
#10	FA438493	BRACKET, TERMINAL BLOCK (1 required per assembly) W/ILLUS. 12 & 66
		FA438493 - Bracket-3 CYL [ More info ] Unavailable
		F438493 - Bracket -3 Cylinder, NLA [ More info ] $7.00 $5.93 5 In Stock.
#11	F289446-1	CLAMP, REMOTE ELEC. CABLE TO BRACKET (1 required per assembly)
		54-F289446-1 - CLAMP,NLA [ More info ] Unavailable
#12	F1734	FILL HD. SCREW, 1/4 - 20 X 1/2 (2 required per assembly)
		F1734 - Screw w/ Lw, NLA [ More info ] Unavailable
		10-34939 - Screw w/ Lw, NLA [ More info ] $1.96 10+ In Stock.
#13	FA616497	TERMINAL BLOCK (1 required per assembly) W/ILLUS. 17 & 20
		FA616497 - Terminal Block Kit, NLA [ More info ] Unavailable
#14	F653744	WIRING HARNESS (1 required per assembly)
		F653744 - 84F6537441 [ More info ] Unavailable
		84-F653744-1 - Harness Assembly, NLA [ More info ] $57.49 10+ In Stock.
#15	F1280	SLOTTED PAN HD. SCREW, 8 - 32 X 1/4 (6 required per assembly)
		10-F1280 - Screw -ss [ More info ] $0.55 $0.46 10+ In Stock.
		108M0129582 - Screw [ More info ] $0.61 Available to Order: Shipping delay up to 10 days.
#16	F5H078	SWITCH, IGNITION LONG BARREL W/KEYS AND SCREWS (1 required per assembly) (ACCESSORY ITEM)
		F5H078 - Ignition Switch Kit - Long [ More info ] $124.50 1 In Stock.
		MP39090 - Ignition Switch [ More info ] $55.19 $54.04 7 In Stock.
#17	F307317	CLIP, TERMINAL BLOCK GROUND (2 required per assembly)
		54-F307317 - Clip [ More info ] $0.75 $0.63 10+ In Stock.
#18	F1975	LOCKWASHER (6 required per assembly)
		13-F1975 - LockWasher - Priced Individually [ More info ] Unavailable
		13-26996 - LockWasher - Priced Individually [ More info ] $1.20 3 In Stock.
#19	817782 1	KEY IGNITION - NO LETTER OR STAMPED A
		817782 1 - Key Set, No Letter or Stamped A [ More info ] $5.43 8 In Stock.
#20	F1648	PAN HD. SCREW, 10 - 24 X 3/4 (2 required per assembly)
		F1648 - Screw [ More info ] Unavailable
		10-41069 - Screw [ More info ] Unavailable
#21	F1934	FLAT HD. SCREW, 6 X 1/2 (4 required per assembly)
		10-F1934 - Screw -ss, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#22	F5H038	IGNITION SWITCH MOUNTING KIT (ACCESSORY ITEM) (1 required per assembly)
		F5H038 - Ignition Switch Mount Kit, NLA [ More info ] $12.07 $10.23 5 In Stock.
#23	FK460917	STARTER RELAY (1 required per assembly) W/ILLUS. 63, 68 AND LITERATURE
		FK460917 - RELAY KIT [ More info ] Unavailable
		89-817109A 3 - Solenoid Kit [ More info ] $82.99 $81.82 Available to Order: Shipping delay up to 10 days.
		18-5835 - Solenoid, 89-817109A3 - 4 Post [ More info ] $54.99 $52.26 2 In Stock.
		SW295 - Solenoid [ More info ] $39.75 $36.18 In Stock
		SW109 - Solenoid [ More info ] $41.40 $37.24 2 In Stock.
#24	F8096	SPRING LOCKWASHER (2 required per assembly)
		F8096 - LockWasher - Priced Individually [ More info ] Unavailable
		13-53166 - LockWasher - Priced Individually [ More info ] $1.80 10+ In Stock.
#25	F1515	HEX NUT, S.S., 5/16 - 18 (2 required per assembly)
		F1515 - Hex Hut, 5/16 - 18 [ More info ] Unavailable
		11-68292 - Nut (5/16 Inch) [ More info ] $1.50 10+ In Stock.
		11-8M0204668 - NUT @5 [ More info ] Unavailable
#26	F1513	HEX NUT, 10 - 32 (6 required per assembly)
		F1513 - Hex Nut 10 - 32 [ More info ] $0.86 10+ In Stock.
		11-68219 - Nut (#10-32) [ More info ] $2.99 10+ In Stock.
#28	F8090	PLAIN WASHER (3 required per assembly)
		12-F8090 - Washer, NLA [ More info ] Unavailable
#30	FS663358	BRACKET (C.D. - COIL) (1 required per assembly)
		FS663358 - Bracket -3 Cylinder, NLA [ More info ] $25.00 $21.18 10+ In Stock.
#31	F8124	EXTERNAL TOOTH LOCKWASHER (6 required per assembly)
		13-F8124 - LockWasher, NLA [ More info ] $1.51 $1.28 10+ In Stock.
#32	F215962	MOUNT (SHOCK - C.D. UNIT) (3 required per assembly)
		F215962 - Shock Mount [ More info ] Unavailable
		819869 - Shock Mount, NLA [ More info ] $69.28 2 In Stock.
#33	F407446	CLAMP (1 required per assembly)
		54-F407446 - Clamp [ More info ] $3.00 $2.54 10+ In Stock.
#34	F381896-4	BATTERY CABLE (1 required per assembly)
		84-F381896-4 - Battery Cable [ More info ] Unavailable
		84-855844A 1 - Battery Cable Assembly [ More info ] Unavailable
		84-88439A50 - Battery Cable Kit [ More info ] Unavailable
		84-8M0210761 - CABLE KIT-BATTERY Q=T [ More info ] In Stock
#35	F85843-1	ELECTRIC CONTROL CABLE, 18 FEET (1 required per assembly)
		84-F85843-1 - Cable - 18 Feet, NLA [ More info ] Unavailable
#36	F654924	CHOKE SOLENOID (1 required per assembly)
		F654924 - 89F6549241 [ More info ] Unavailable
		89-F654924-1 - Solenoid [ More info ] Unavailable
		89-803629T - Solenoid, NLA [ More info ] Unavailable
		89-889273 - Choke Solenoid [ More info ] Unavailable
#37	F510374-1	DECAL, CIRCUIT BREAKER (1 required per assembly)
		37-F510374-1 - Decal -Breaker, NLA [ More info ] Unavailable
#38	F510460	CIRCUIT BREAKER (1 required per assembly)
		88-F510460 - Circuit Breaker [ More info ] Unavailable
#39	F8011	PLAIN WASHER (2 required per assembly)
		F8011 - Washer SS [ More info ] Unavailable
		12-89302 - Washer (.203 X .406 X .040) [ More info ] $1.80 10+ In Stock.
#40	F1760	SLOTTED PAN HD. SCREW, 10 - 24 X 3/8 (2 required per assembly)
		10-F1760 - Screw -ss, NLA [ More info ] $1.50 $1.28 10+ In Stock.
#41	F91446-1	CIRCUIT BREAKER BRACKET (1 required per assembly)
		F91446-1 - F914462 [ More info ] Unavailable
		F91446-2 - Bracket, NLA [ More info ] $6.56 $5.56 10+ In Stock.
#42	F475504	GROMMET (4 required per assembly)
		25-F475504 - Grommet, Cd Mounting,NLA [ More info ] $5.21 $4.42 10+ In Stock.
#43	F8028	PLAIN WASHER (4 required per assembly)
		F8028 - 12F8008 [ More info ] Unavailable
		12-F8008 - Washer [ More info ] Unavailable
		12-35044 - Washer, (.281 X .625 X .065) Stainless Steel [ More info ] $2.49 10+ In Stock.
#44	F2008	HEX HD. M. SC., 1/4 - 20 X 7/8 (4 required per assembly)
		10-F2008 - Screw -ss, NLA [ More info ] $3.22 10+ In Stock.
#45	F653301-1	MODULE (2 required per assembly)
		F653301-1 - CD Module Assembly [ More info ] Unavailable
		300-817974A 1 - CD Module Kit [ More info ] $682.99 1 In Stock.
		18-99266 - Force CD Module Black Case NO PLUG 300-817974A, 116-3301 [ More info ] $637.57 1 In Stock.
#46	F615475	IGNITION COIL (3 required per assembly)
		F615475 - Coil [ More info ] Unavailable
		300-888791 - Ignition Coil, See notes on Detail Page [ More info ] $186.49 Available to Order: Shipping delay up to 10 days.
		18-99174 - Coil, Bracket, and Wire Force Chyrsler F684475, F615475, 182-4475R [ More info ] $166.62 In Stock
#48	F5H041	BATTERY TERMINAL KIT (ACCESSORY ITEM) (1 required per assembly)
		F5H041 - TERMINAL KIT,NLA [ More info ] Unavailable
#49	F1741	PAN HD. SCREW, 8 X 3/4 (2 required per assembly)
		10-F1741 - Screw -ss [ More info ] Unavailable
#50	F5H043	BUZZER, HEAT INDICATOR (ACCESSORY ITEM) (1 required per assembly)
		F5H043 - Buzzer Kit [ More info ] Unavailable
#51	F345683	WIRE, GROUND (RECTIFIER TO STARTER BOLT) (1 required per assembly)
		84-F345683 - Wire, NLA [ More info ] $5.43 $4.60 10+ In Stock.
#52	F404841	CABLE, HEAT INDICATOR (1 required per assembly)
		84-F404841 - Cable [ More info ] Unavailable
		84-65017A24 - Harness Assembly [ More info ] Unavailable
#53	F1341	NUT, 1/4 - 20 (6 required per assembly)
		F1341 - Hex Nut 1/4 - 20 [ More info ] Unavailable
		11-64015 - Nut (1 /4-20) [ More info ] $2.79 10+ In Stock.
#54	FK1123	SPARKIE KIT (3 required per assembly)
		FK1123 - Boot Kit [ More info ] Unavailable
		85-63709A 1 - Boot Kit - Black - Priced Individually [ More info ] $8.19 10+ In Stock.
#55	F2106	LOCKWASHER (2 required per assembly)
		F2106 - LockWasher - Priced Individually [ More info ] Unavailable
		13-78968 - LockWasher - Priced Individually [ More info ] $1.80 10+ In Stock.
#56	F319908	WIRE, GROUND (C.D. - COIL BRACKET) (1 required per assembly)
		84-F319908 - Wire Assembly, NLA [ More info ] $5.39 10+ In Stock.
#57	F1832	NUT, LOCK 1/4 - 20 (4 required per assembly)
		11-F1832 - Nut (1 /4-20)(Stainless Steel) [ More info ] Unavailable
		11-814101 - Nut (1/4-20) [ More info ] Unavailable
		118M0207776 - NUT [ More info ] $7.09 Available to Order: Shipping delay up to 10 days.
#58	F653029	TRIGGER ASSY. (1 required per assembly)
		F653029 - TRIGGER ASSY [ More info ] Unavailable
		300-F653029-1 - Trigger Assembly [ More info ] $244.43 5 In Stock.
		300-888796 - Trigger Assembly [ More info ] $630.99 $494.37 1 In Stock.
		18-99470 - Trigger, Chrysler, Force, [ More info ] $523.29 1 In Stock.
#59	F663095	ALTERNATOR STATOR (1 required per assembly)
		F663095 - F6630951 [ More info ] Unavailable
		F663095-1 - F6630952, NLA [ More info ] Unavailable
		F663095-2 - F6630953, NLA [ More info ] Unavailable
		F663095-3 - Stator Assembly [ More info ] Unavailable
		300-F663095-4 - Stator [ More info ] Unavailable
		300-F722095 - Stator [ More info ] Unavailable
		300-888793 - Stator Assembly [ More info ] $656.99 Available to Order: Shipping delay up to 10 days.
		18-99217 - Stator With Ring Connetors 300-888793, 176-3095 [ More info ] $458.84 In Stock
#60	F1550	SLOTTED PAN HD. SCREW #12 - 24 X 1 (4 required per assembly)
		F1550 - 10F2200 [ More info ] Unavailable
		10-F2200 - Screw, NLA [ More info ] $1.59 $1.34 5 In Stock.
#61	200-817865A 1	FLYWHEEL (1 required per assembly) W/ILLUS. 67 ORIGINAL FORCE P/N A 615097-1
		200-817865A 1 - FA694097 [ More info ] Unavailable
		FA694097 - Flywheel Kit, NLA [ More info ] Unavailable
#62	F1968	HEX NUT, 3/4 X 16 (1 required per assembly)
		11-F1968 - Nut (3/4-16) [ More info ] $19.69 10+ In Stock.
#63	F8083	SPRING LOCKWASHER (1 required per assembly)
		F8083 - LockWasher SS [ More info ] Unavailable
		13-26992 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#66	F438668	RETAINER (1 required per assembly)
		54-F438668 - Retainer, NLA [ More info ] $1.80 $1.52 10+ In Stock.
#67	FA609853	DECAL, WARNING (1 required per assembly) W/LITERATURE
		FA609853 - Decal Kit [ More info ] Unavailable
		37-825149A 1 - Decal Kit [ More info ] Unavailable
#68	F1705	HEX HD. SCREW, 1/4 - 20 X 3/4 (3 required per assembly)
		F1705 - Screw - Priced Individually [ More info ] Unavailable
		10-28636 - Screw - Priced Individually [ More info ] $1.80 10+ In Stock.
#70	F1303	PAN HD. SCREW, 8 - 32 X 3/4 (1 required per assembly)
		10-F1303 - Screw [ More info ] $0.40 $0.34 2 In Stock.
#71	F653398-1	DECAL, 3 CYL WIRING (1 required per assembly)
		F653398-1 - DECAL NLA [ More info ] Unavailable
#72	F664497	TERMINAL BLOCK (12 POSITION) (1 required per assembly)
		86-F664497 - Terminal Block -12POS, NLA [ More info ] Unavailable
#74	F428096	RETAINER, THERMOSWITCH (1 required per assembly)
		53-F428096 - Retainer [ More info ] $0.78 $0.66 10+ In Stock.
#75	F664384	CLIP, TERMINAL BLOCK COVER (2 required per assembly)
		54-F664384 - Clip, NLA [ More info ] $2.99 10+ In Stock.
#76	F664672	COVER, TERMINAL BLOCK COVER (1 required per assembly)
		F664672 - Terminal Block Cover [ More info ] $5.99 10+ In Stock.
