Parts for Force 75 HP (1996) Driveshaft & Lower Shift Components
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| # | 1600-819123A 5 | GEAR HOUSING ASSEMBLY (BASIC) (1 required per assembly) |
  |
1600-819123A 5 - Basic Gear Housing Assembly [ More info ] Unavailable |
|
  |
1600-819123A 7 - Basic Gear Housing Assembly [ More info ] Unavailable |
|
  |
|
1600-819123T 7 - Gear Housing [ More info ] Unavailable |
| # | 1600-819123A 6 | GEAR HOUSING ASSEMBLY (COMPLETE) (1 required per assembly) |
  |
1600-819123A 6 - Gear Housing Assembly [ More info ] Unavailable |
|
  |
1600-819123A 8 - Gear Housing Assembly [ More info ] Unavailable |
|
  |
|
1600-819123T 8 - GC COMP 75,NLA [ More info ] Unavailable |
| # | 26-814669A 2 | SEAL KIT-Gear Housing (1 required per assembly) |
  |
|
26-814669A 2 - Gear Housing Seal Kit [ More info ]
|
  |
|
18-2635 - Seal Kit, 26-814669A2 [ More info ]
|
| #1 | 45-819051A 1 | DRIVESHAFT ASSEMBLY (1 required per assembly) |
  |
|
45-819051A 1 - Drive Shaft Assembly [ More info ] Unavailable |
| #2 | 31-77420A 1 | BEARING SET (Cone & Cup) (1 required per assembly) |
  |
|
31-77420A 1 - Tapered Roller Bearing [ More info ] Unavailable |
| #3 | 43-813694 | GEAR-Pinion (1 required per assembly) |
  |
43-813694 - Gear, Pinion (14 Teeth) [ More info ] Unavailable |
|
  |
|
43-813694T - Gear, Pinion (14 Teeth) [ More info ]
|
| #4 | 11-55910 | NUT-Special (.437-20) (1 required per assembly) TORQUE 50 LB. FT. 115 N-M |
  |
|
11-55910 - Nut, Special (7/16-20) [ More info ]
|
| #5 | 15-812770A 1 | SHIM SET-Driveshaft (1 required per assembly) |
  |
|
15-812770A 1 - Shim SET [ More info ] Unavailable |
| #6 | F749271 | RETAINER-Driveshaft Spline Seal (1 required per assembly) |
  |
|
F749271 - Retainer, NLA [ More info ] Unavailable |
| #7 | 11-812820 | NUT (Special)-Driveshaft (1 required per assembly) |
  |
11-812820 - Nut, Driveshaft [ More info ] Unavailable |
|
  |
|
11-812820 1 - Nut [ More info ]
|
| #8 | 25-819427 | SEAL-Driveshaft Spline (1 required per assembly) |
  |
|
25-819427 - Seal [ More info ]
|
| #9 | 31-812768 | BEARING-Needle Roller (1 required per assembly) |
  |
|
31-812768 - Roller Bearing [ More info ]
|
| #10 | 17-43044 | PIN-Dowel (1 required per assembly) |
  |
|
17-43044 - Pin -Dowel-solid [ More info ]
|
| #11 | 17-43043 | PIN-Dowel (1 required per assembly) |
  |
|
17-43043 - Pin, Dowel [ More info ]
|
  |
|
178M0084244 - Pin - Dowel [ More info ]
|
| #12 | 26-817472 | SEAL-Gear Shift Rod Lower (1 required per assembly) |
  |
|
26-817472 - Seal [ More info ]
|
  |
|
18-0500 - Seal, 26-817472 [ More info ]
|
| #13 | 23-817473 1 | BUSHING-Shift Rod Seal (1 required per assembly) |
  |
|
23-817473 1 - Bushing, NLA [ More info ] Unavailable |
| #14 | 25-45258 | O RING-Shift Rod (1 required per assembly) |
  |
|
25-45258 - O Ring, Shift Rod [ More info ]
|
| #15 | 17-F85372 | PIN-Gear Shift Rod Lower (1 required per assembly) |
  |
|
17-F85372 - Gear Shift Rod Lower Pin [ More info ]
|
| #16 | 18-F1015 | PIN-Cotter (1 required per assembly) |
  |
|
18-F1015 - Cotter Pin - Priced Individually [ More info ]
|
| #17 | 817471 | ROD-Gear Shift (1 required per assembly) |
  |
|
817471 - Gear Shift Rod [ More info ]
|
| #18 | 817475 | ARM ASSEMBLY-Lower Shift Rod (1 required per assembly) |
  |
|
817475 - Arm Assembly, NLA [ More info ]
|
| #19 | 10-79953A 2 | SCREW KIT-Special (.375-16 x .250) (2 required per assembly) |
  |
10-79953A 2 - Drain Screw Kit [ More info ] Unavailable |
|
  |
10-79953Q 2 - Screw Kit - Priced Individually [ More info ] Unavailable |
|
  |
|
10-79953Q04 - Screw Kit - Priced Individually [ More info ]
|
  |
|
18-2244 - Plug Kit, 10-79953A2 [ More info ]
|
  |
|
10-79953K04 - Drain Screw - Priced Individually [ More info ]
|
| #20 | 12-19183 | WASHER-Sealing (2 required per assembly) |
  |
12-19183 - Washer (3/8 Inch Screw) [ More info ] Unavailable |
|
  |
12-19183 2 - Washer - Priced Individually [ More info ] Unavailable |
|
  |
12-19183 3 - Seal -Blue - Priced Individually [ More info ] Unavailable |
|
  |
|
12-8M0187157 - SEAL-BLUE, Sold Individually [ More info ]
|
  |
|
18-2945-9 - Gasket 12-19183 2-Pack [ More info ]
|
  |
|
12-19183Q02 - Seals, Pack of 4 (yes this is actually a pack of 4) [ More info ]
|
  |
|
12-19183K02 - Seal, Pack of 4 [ More info ]
|
  |
|
12-02108-1 - Drain Gasket (1 piece) [ More info ]
|
| #21 | 826374 | PIN-Shift Pivot-With Dri Lok (1 required per assembly) |
  |
|
826374 - Pin - Retainer [ More info ] Unavailable |
| #22 | 25-25007 | O RING (1 required per assembly) |
  |
|
25-25007 - O-ring, Gear Shift Arm Pin [ More info ]
|
  |
|
18-7120 - O-Ring 322598 [ More info ]
|
| #23 | 22-67892A 1 | PLUG KIT-Oil Drain (Magnetic) (1 required per assembly) |
  |
22-67892A 1 - Drain Plug [ More info ] Unavailable |
|
  |
22-67892A05 - Drain Plug Kit [ More info ] Unavailable |
|
  |
22-67892A06 - Drain Plug Kit [ More info ] Unavailable |
|
  |
|
22-8M0058389 - Screw Kit - Priced Individually [ More info ]
|
  |
|
18-23751-9 - Drain Screw , Package of 50 [ More info ]
|
  |
|
18-2375 - Plug, 22-67892A1 [ More info ]
|
  |
|
10-02683 - Drain Screw [ More info ]
|
| #25 | 22-56800 | PLUG-Pipe (1 required per assembly) |
  |
|
22-56800 - Pipe Plug [ More info ]
|
