Parts for Force 60 HP (1984) Engine Cover & Support Plate

Revise Search: All Models > 60 HP (1984) > 608H4C ( ) > Engine Cover & Support Plate

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#	FA474499	HANDLE, COVER LATCH STARBOARD ASSY. (1 required per assembly)
		FA474499 - Handle Kit, NLA [ More info ] Unavailable
#	FA589396	DECAL, STARBOARD (1 required per assembly) W/LITERATURE 606 H4A, 608 H4C
		FA589396 - DECAL - Starboard,NLA [ More info ] Unavailable
#	F2C590712	ENGINE COVER COMPLETE.ORDER NUMERAL SEPARATE.606H4A, 608 H4C (1 required per assembly)
		F2C590712 - COVER ASSY NLA [ More info ] Unavailable
#	F474378	LEVER, COVER LATCH STARBOARD (NOT SHOWN) (1 required per assembly)
		F474378 - Lever [ More info ] $1.50 $1.28 2 In Stock.
#	FA474780	CAM, STARBOARD LATCH ASSY. (NOT SHOWN) (1 required per assembly)
		FA474780 - Cam Assembly, NLA [ More info ] $8.00 $6.78 1 In Stock.
#	F474487	GUIDE, COVER LATCH PORT (NOT SHOWN) (1 required per assembly)
		F474487 - GUIDE,NLA [ More info ] Unavailable
#	FA571396	DECAL, STARBOARD (1 required per assembly) W/LITERATURE 608 F5A
		FA571396 - DECAL - Starboard,NLA [ More info ] Unavailable
#	FA571397	DECAL, PORT (1 required per assembly) W/LITERATURE 608 F5A
		FA571397 - DECAL-PORT,NLA [ More info ] Unavailable
#	F2C571712	ENGINE COVER COMPLETE. 608F5A (1 required per assembly)
		F2C571712 - COVER ASSY NLA [ More info ] Unavailable
#1	100-818016A 2	ENGINE COVER (1 required per assembly) W/ILLUS. 10, 11, 44, 45 AND 46 ORIGINAL FORCE P/N S 547712-2
		100-818016A 2 - COVER KIT,NLA [ More info ] Unavailable
#2	F524269	TILT HANDLE (1 required per assembly)
		F524269 - HANDLE,NLA [ More info ] Unavailable
#3	F2025	PAN HD SCREW, #10 X 5/8 (1 required per assembly)
		10-F2025 - Screw -ss, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#4	F2066	PAN HD SCREW, #10 - 7/16 (4 required per assembly)
		F2066 - Screw SS, NLA [ More info ] $1.50 $1.28 10+ In Stock.
#5	F463864	RETAINER, TILT HANDLE (2 required per assembly)
		F463864 - Retainer, NLA [ More info ] $1.50 $1.28 9 In Stock.
#6	F1854	HEX CAP SCREW, 1/4 - 20 X 5/8 (4 required per assembly)
		F1854 - Screw SS [ More info ] Unavailable
		10-28635 - Screw - Priced Individually [ More info ] $1.80 10+ In Stock.
#7	F8083	LOCKWASHER (4 required per assembly)
		F8083 - LockWasher SS [ More info ] Unavailable
		13-26992 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#8	F8094	PLAIN WASHER (4 required per assembly)
		F8094 - Washer SS [ More info ] $1.29 5 In Stock.
		12-40023 16 - Washer - Priced Individually [ More info ] $1.17 2 In Stock.
		128M0214930 - WASHER Note: Must be ordered in multiples of 5 [ More info ] $1.00 1 In Stock.
#9	F474864	RETAINER, COVER LATCH (2 required per assembly)
		F474864 - Retainer,NLA [ More info ] Unavailable
#10	F1979	PAN HD SCREW, 10 - 24 X 1/2 (8 required per assembly)
		F1979 - SCREW,NLA [ More info ] Unavailable
		10-41772 - Screw, NLA [ More info ] $1.80 $1.52 10+ In Stock.
#11	FA474774	BRACKET, COVER LATCH (2 required per assembly) W/ILLUS. 10 AND 12
		FA474774 - Bracket Kit,NLA [ More info ] Unavailable
#12	F7011	STOP NUT (8 required per assembly)
		11-F7011 - 11F7009 [ More info ] Unavailable
		11-F7009 - Nut, (#10-24) [ More info ] Unavailable
#13	FA589397	DECAL, PORT (1 required per assembly) W/LITERATURE 606 H4A, 608 H4C
		FA589397 - DECAL-PORT,NLA [ More info ] Unavailable
#14	FA596386	DECAL, NUMERAL (2 required per assembly) W/LITERATURE 606 H4A, 608 H4C
		FA596386 - DECAL-60,NLA [ More info ] Unavailable
#15	F577156	COVER, SUPPORT PLATE REAR (1 required per assembly)
		100-F577156 - Cover, NLA [ More info ] Unavailable
#16	F474991	GROMMET (1 required per assembly)
		25-F474991 - Grommet, NLA [ More info ] Unavailable
#17	F2072	OVAL COUNTERSUNK HD M. SCREW 10 - 24 X 3/8 (2 required per assembly)
		10-F2072 - Screw -ss, NLA [ More info ] $1.88 $1.59 1 In Stock.
#18	F2017	PAN HD SCREW W/ PLAIN WASHER, 10 - 24 X 3/8 (3 required per assembly)
		10-F2017 - Screw, NLA [ More info ] $1.88 $1.59 3 In Stock.
#19	F474817	RETAINER, SUPPORT PLATE (2 required per assembly)
		F474817 - Retainer,NLA [ More info ] Unavailable
#20	F1689	HEX CAP SCREW, 1/4 - 20 X 1/2 (4 required per assembly)
		F1689 - Screw SS [ More info ] Unavailable
		10-73286 - Screw [ More info ] $1.80 Available to Order: Shipping delay up to 10 days.
#21	FA474038	SUPPORT PLATE PORT W/ LOWER PACKING (1 required per assembly)
		100-FA474038 - PLATE-PORT,NLA [ More info ] Unavailable
#22	F2075	SLOTTED HD SCREW, S.S., 1/4 - 20 X 2 1/2 (1 required per assembly)
		10-F2075 - Screw -ss, NLA [ More info ] $1.25 $1.06 1 In Stock.
#23	FA474469	HANDLE, COVER LATCH PORT ASSY. (1 required per assembly)
		FA474469 - Handle Kit, NLA [ More info ] Unavailable
#24	F390689	BEARING, LATCH SHAFT (2 required per assembly)
		23-F390689 - Bearing [ More info ] Unavailable
		23-26954 - Bushing [ More info ] $5.89 Available to Order: Shipping delay up to 10 days.
#25	F549189	BUSHING, ELECTRIC CABLE ENTRY (1 required per assembly)
		F549189 - F5491891 [ More info ] Unavailable
		F549189-1 - 23F5491892 [ More info ] Unavailable
		23-F549189-2 - Bushing [ More info ] Unavailable
		23-828763 - Bushing, NLA [ More info ] $9.17 $7.76 10+ In Stock.
#26	F1733	PAN HD SCREW, 10 - 24 X 9/16 (3 required per assembly)
		10-F1733 - Screw, SS [ More info ] $1.29 2 In Stock.
		10-852453 - Screw [ More info ] $1.50 Available to Order: Shipping delay up to 10 days.
#27	F474315	PACKING, SUPPORT PLATE LOWER (2 required per assembly)
		F474315 - Packing, NLA [ More info ] $6.00 $5.08 10+ In Stock.
#28	F269052	BEARING, LATCH CAM (2 required per assembly)
		23-F269052 - Bushing, NLA [ More info ] $3.90 10+ In Stock.
#29	FA474777	CAM, PORT LATCH ASSY. (1 required per assembly)
		FA474777 - Cam Assembly, NLA [ More info ] $9.00 $7.62 1 In Stock.
#30	F474377	LEVER, COVER LATCH PORT (1 required per assembly)
		F474377 - Lever [ More info ] Unavailable
#31	F7025	LOCKNUT, 3/8 - 16 (2 required per assembly)
		F7025 - Lock Nut 3/8 - 16 (Stainless Steel) [ More info ] Unavailable
		11-68411 - Nut (3/8-16) [ More info ] $6.66 10+ In Stock.
		11-826709 12 - Nut, (.375-16) Stainless Steel [ More info ] $6.79 $3.81 10+ In Stock.
#33	F474897	GUIDE, COVER LATCH STARBOARD (1 required per assembly)
		F474897 - GUIDE,NLA [ More info ] Unavailable
#34	FA475913	GROMMET (2 PER SET) (1 required per assembly)
		FA475913 - Grommet SET,NLA [ More info ] Unavailable
#35	F474163	COVER, SUPPORT PLATE FRONT (1 required per assembly)
		F474163 - Cover, NLA [ More info ] Unavailable
#37	FA474088	SUPPORT PLATE STARBOARD W/ LOWER PACKING (1 required per assembly)
		100-FA474088 - PLATE-STARBOARD,NLA [ More info ] Unavailable
#38	F545189	BUSHING, CABLE ENTRY (1 required per assembly)
		F545189 - Bushing-ENTRY [ More info ] Unavailable
		23-819006 - Entry Bushing [ More info ] Unavailable
		23-819006 1 - Bushing-ENTRY [ More info ] Unavailable
		23-819006 2 - Entry Bushing, NLA [ More info ] $16.15 10+ In Stock.
#39	F474756	PACKING, SUPPORT PLATE FRONT (1 required per assembly)
		F474756 - PACKING,NLA [ More info ] Unavailable
#40	FA606892	DECAL, FRONT (1 required per assembly) W/LITERATURE 606 H4A, 608 H4C
		FA606892 - DECAL NLA [ More info ] Unavailable
#41	FK606711	FRONT PLATE (1 required per assembly) W/ILLUS. 42, 43, 48 AND LITERATURE
		FK606711 - Plate Kit [ More info ] $10.87 $9.21 7 In Stock.
#42	F85735-1	SEAL (2 required per assembly)
		26-F85735-1 - Seal, NLA [ More info ] $1.99 $1.68 10+ In Stock.
#43	F1753	FASTENER (2 required per assembly)
		F1753 - Fastener, NLA [ More info ] $1.99 $1.68 10+ In Stock.
#44	F474985	BLANKET, SILENCER, SIDE (NOT SHOWN) (2 required per assembly)
		F474985 - Blanket,NLA [ More info ] Unavailable
#45	F474984	BLANKET, SILENCER, TOP (NOT SHOWN) (1 required per assembly)
		F474984 - Blanket, NLA [ More info ] Unavailable
#46	F474992	BLANKET, SILENCER, FRONT (NOT SHOWN) (1 required per assembly)
		F474992 - Blanket,NLA [ More info ] Unavailable
#47	FA606528	DECAL, ENGINE COVER REAR 606 H4C, 608 H4C (1 required per assembly)
		FA606528 - DECAL,NLA [ More info ] Unavailable
#48	F2128	RIVET, TRIM PLATE FRONT (NOT SHOWN) (2 required per assembly)
		16-F2128 - 16F2165 [ More info ] Unavailable
		16-F2165 - Stud, NLA [ More info ] $1.50 $1.28 10+ In Stock.
