Parts for Force 50 HP (1995) Shift Throttle Linkage
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| # | 800-818152A19 | COMPONENT OF POWERHEAD ASS'Y (- required per assembly) |
  |
|
800-818152A19 - Powerhead KIT,NLA [ More info ] Unavailable |
| #1 | 16-826389 | STUD (1/4-20 X 1-1/4") (1 required per assembly) WITH DRY LOC, THROTTLE CAM |
  |
16-826389 - 16F4332091 [ More info ] Unavailable |
|
  |
|
16-F433209-1 - Stud [ More info ]
|
| #2 | 11-68219 | NUT (10-32) (2 required per assembly) |
  |
|
11-68219 - Nut (#10-32) [ More info ]
|
| #3 | 11-40063 3 | NUT (M5 X 0.8) (3 required per assembly) |
  |
11-40063 3 - NUT [ More info ] Unavailable |
|
  |
|
11-40138 5 - Nut [ More info ] Unavailable |
| #4 | 11-72008 | NUT (1/4-20) (1 required per assembly) |
  |
11-72008 - Nut (1/4-20) [ More info ] Unavailable |
|
  |
|
11-826708 8 - Nut [ More info ]
|
| #5 | 23-F269319 | BEARING, THROTTLE CAM (2 required per assembly) |
  |
|
23-F269319 - Bushing, NLA [ More info ]
|
| #6 | 819552 | CAM, THROTTLE (ALL MODELS) (1 required per assembly) |
  |
|
819552 - Throttle Cam, NLA [ More info ]
|
| #7 | 823569 | BALL , THREADED (3 required per assembly) |
  |
823569 - Ball - Threaded [ More info ] Unavailable |
|
  |
|
823569 5 - Ball - Threaded [ More info ]
|
| #8 | 16-F718502 | LINK, THROTTLE (ALL MODELS) (1 required per assembly) |
  |
|
16-F718502 - Throttle Link, NLA [ More info ]
|
| #9 | 17-F1727 | RIVET (1 required per assembly) |
  |
|
17-F1727 - Rivet, NLA [ More info ]
|
| #10 | 816957 | BEARING, TOWERSHAFT (4 required per assembly) |
  |
|
816957 - Towershaft Bearing, NLA [ More info ]
|
| #11 | 826284 | TOWERSHAFT (1 required per assembly) |
  |
|
826284 - TowerShaft [ More info ]
|
| #12 | 10-19926100 | SCREW (10-24 X 1") WITH DRI LOC (4 required per assembly) |
  |
|
10-19926100 - Screw - Priced Individually [ More info ]
|
| #13 | 10-F1504 | SCREW (1/4-20 X 1") (1 required per assembly) |
  |
|
10-F1504 - Screw -ss [ More info ]
|
| #14 | 11-64015 | NUT (1/4-20) (1 required per assembly) |
  |
|
11-64015 - Nut (1 /4-20) [ More info ]
|
| #15 | 819208 | BEARING, SPARK CONTROL (LH) (BLACK) (1 required per assembly) |
  |
|
819208 - Spark Control Bearing [ More info ] Unavailable |
| #16 | 10-819625 | SCREW, SHOULDER (2 required per assembly) |
  |
|
10-819625 - Screw, NLA [ More info ]
|
| #17 | 819521 | LINK, SPARK CONTROL (1 required per assembly) |
  |
819521 - Link, NLA [ More info ] Unavailable |
|
  |
|
819521 1 - Link, NLA [ More info ] Unavailable |
| #18 | 11-79989 | NUT (10-24) (1 required per assembly) |
  |
|
11-79989 - Nut (10 - 24) [ More info ]
|
| #19 | 816514 | BEARING, SPARK CONTROL (RH) (RED) (1 required per assembly) |
  |
|
816514 - Bearing - Black [ More info ] Unavailable |
| #20 | 11-F7009 | NUT (10-24) (1 required per assembly) |
  |
|
11-F7009 - Nut, (#10-24) [ More info ] Unavailable |
| #21 | 16-827425 | STUD (5/16-18 X 1-1/2") WITH DRI LOC (1 required per assembly) |
  |
|
16-827425 - Stud, NLA [ More info ] Unavailable |
| #22 | 12-34437 | WASHER (1 required per assembly) |
  |
|
12-34437 - Washer (5/16 In. I.d.) [ More info ]
|
| #23 | 11-45592 | NUT (5/16-24) (1 required per assembly) |
  |
|
11-45592 - Nut (5/16-24) [ More info ]
|
  |
|
11-826709111 - Nut, (.312-24) Stainless Steel [ More info ]
|
  |
|
18-3723-9 - Lock Nut, 11-45592, 5PK [ More info ]
|
| #24 | 826286 | LEVER ASSEMBLY, TOWERSHAFT (1 required per assembly) |
  |
826286 - LEVER ASSY [ More info ] Unavailable |
|
  |
|
826286 1 - Lever Assembly [ More info ] Unavailable |
| #25 | 19385 29 | LINK ASSEMBLY, TOWERSHAFT LEVER (1 required per assembly) |
  |
|
19385 29 - Link Assembly, NLA [ More info ]
|
| #26 | 817428 | SOCKET, BALL (2 required per assembly) |
  |
|
|
| #27 | 11-826833 6 | NUT (M6) (1 required per assembly) |
  |
11-826833 6 - Nut , Priced Individually [ More info ] Unavailable |
|
  |
11-40144 - NUT Note: Priced Individually [ More info ] Unavailable |
|
  |
|
11-40138 6 - Nut - Priced Individually [ More info ]
|
