Parts for Force 40 HP (1992-1994) Reed Plate & Adapter Flange
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| # | 800-819445A14 | POWERHEAD ASSEMBLY |
  |
800-819445A14 - Powerhead [ More info ] Unavailable |
|
  |
800-819445A19 - Powerhead [ More info ] Unavailable |
|
  |
|
800-818152A19 - Powerhead KIT,NLA [ More info ] Unavailable |
| # | 16-826389 | STUD (1 required per assembly) (1/4-20 X 1-1/4") WITH DRI LOC, THROTTLE CAM (ALL 40 HP &50 HP) SERIAL 0E065372-0E093699 |
  |
16-826389 - 16F4332091 [ More info ] Unavailable |
|
  |
|
16-F433209-1 - Stud [ More info ]
|
| # | 27-820722A 1 | POWERHEAD GASKET SET |
  |
|
27-820722A 1 - Gasket Set [ More info ] Unavailable |
| # | 800-818152A 7 | POWERHEAD ASSEMBLY |
  |
800-818152A 7 - Powerhead-50 [ More info ] Unavailable |
|
  |
800-818152A15 - Powerhead [ More info ] Unavailable |
|
  |
800-818152A17 - Powerhead [ More info ] Unavailable |
|
| # | 27-820467A 1 | POWERHEAD GASKET SET |
  |
27-820467A 1 - Powerhead Gasket Set [ More info ] Unavailable |
|
  |
|
27-809746A 1 - Gasket Set [ More info ]
|
| # | 800-819445A 7 | POWERHEAD ASSEMBLY |
  |
800-819445A 7 - Powerhead-40 [ More info ] Unavailable |
|
| #1 | 10-28668 | SCREW (1/4-20 X 7/8") (6OR8 required per assembly) |
  |
|
10-28668 - Screw - Priced Individually [ More info ]
|
| #2 | 11-68292 | NUT (5/16-18) (ALL 40 HP &50 HP) (2 required per assembly) SERIAL 0E065372-0E093699 |
  |
|
11-68292 - Nut (5/16 Inch) [ More info ]
|
  |
|
11-8M0204668 - NUT @5 [ More info ] Unavailable |
| #3 | FA433167 | ADAPTER KIT, CARBURETOR FLANGE (ALL 40 HP &50 HP) (1 required per assembly) SERIAL 0E065372-0E093699 |
  |
|
FA433167 - Adapter Kit, NLA [ More info ] Unavailable |
| #4 | 16-826388 | STUD (5/16-18 X 1-1/4") W/DL (ALL 40 HP &50 HP) (2 required per assembly) SERIAL 0E065372-0E093699 |
  |
16-826388 - 16F40209 [ More info ] Unavailable |
|
  |
16-F40209 - STUD [ More info ] Unavailable |
|
  |
|
16-826388 1 - Stud, NLA [ More info ]
|
| #5 | 37-817792A 1 | DECAL, TIMING (ALL 40 HP &50 HP) (1 required per assembly) SERIAL 0E065372-0E093699 |
  |
|
37-817792A 1 - Decal Kit - Timing, NLA [ More info ] Unavailable |
| #2 | 11-86226 | NUT (3/6-16) (50 HP-92C) (2 required per assembly) SERIAL 0E000001-0E065371 |
  |
|
11-86226 - Nut (3/8-16) [ More info ]
|
  |
|
11-8M0204671 - NUT [ More info ] Unavailable |
| #3 | FA691167 | ADAPTER KIT, CARBURETOR FLANGE (50 HP-92C) (1 required per assembly) SERIAL 0E000001-0E065371 |
  |
FA691167 - Adapter Kit [ More info ] Unavailable |
|
  |
|
819410A 3 - Adapter Kit,NLA [ More info ] Unavailable |
| #4 | 16-826387 | STUD (3/8-16 X 1-5 /8") W/DL (50 HP-92C) (2 required per assembly) SERIAL 0E000001-0E065371 |
  |
16-826387 - STUD [ More info ] Unavailable |
|
  |
|
16-826387 1 - STUD [ More info ]
|
  |
|
16-826387 2 - Stud [ More info ]
|
| #6 | 27-F433168 | GASKET, CARBURETOR ADAPTER (1 required per assembly) |
  |
|
27-F433168 - Carburetor Adapter Gasket [ More info ]
|
| #7 | 819807 1 | PLATE, DEFLECTOR (1 required per assembly) |
  |
|
819807 1 - Deflector Plate, NLA [ More info ]
|
| #8 | 27-F433406 | GASKET, DEFLECTOR PLATE (1 required per assembly) |
  |
|
27-F433406 - Deflector Plate Gasket [ More info ]
|
| #9 | 10-826379 | SCREW (10-24 X 1/2") W/DL (4 required per assembly) |
  |
|
10-826379 - Screw, NLA [ More info ]
|
| #10 | FA658158 | PLATE ASSEMBLY, REED (2 required per assembly) |
  |
|
FA658158 - Reed Plate Assembly, NLA [ More info ] Unavailable |
| #11 | 34-F316160 | REED (4 PETAL) (4 required per assembly) |
  |
|
34-F316160 - Reed, 4 Petal, Sold as a Single Reed Only [ More info ]
|
| #12 | 34-F88161-4 | STOP, REED (4 required per assembly) |
  |
|
34-F88161-4 - Reed Stop, NLA [ More info ]
|
| #13 | 10-819074 | SCREW (6-32 X 5/16") (16 required per assembly) |
  |
|
10-819074 - Screw -w/Lw [ More info ]
|
| #14 | 819460A 1 | BRACKET ASSY, REMOTE CABLE (1 required per assembly) SERIAL 0E009500-0E093699 |
  |
|
819460A 1 - Bracket Assembly -40/50, NLA [ More info ] Unavailable |
| #15 | 10-86885 | SCREW (1/4-20 X 1-1/2") (1 required per assembly) SERIAL 0E009500-0E093699 |
  |
|
10-86885 - Screw [ More info ]
|
| #16 | 10-76630 | SCREW (1/4-20 X 1") (1 required per assembly) SERIAL 0E009500-0E093699 |
  |
|
10-76630 - Screw - Priced Individually [ More info ]
|
  |
|
108M0214943 - SCREW, Priced Individually [ More info ]
|
| #17 | 11-34059 | NUT (10-32) (1 required per assembly) |
  |
|
11-34059 - Nut (#10-32) [ More info ]
|
  |
|
11-826709 6 - Nut [ More info ]
|
| #18 | 23-819452 | BUSHING (2 required per assembly) |
  |
|
23-819452 - Bushing, Sold Individually [ More info ]
|
