Parts for Force 25 HP (1996) Fuel System
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| # | 27-809516A 1 | POWERHEAD GASKET SET (- required per assembly) |
  |
|
27-809516A 1 - Gasket Set [ More info ] Unavailable |
| # | 800-819240A 3 | POWERHEAD ASS'Y (- required per assembly) |
  |
800-819240A 3 - Powerhead [ More info ] Unavailable |
|
  |
|
800-819240A 6 - Powerhead, 25HP 1996 to 1998 [ More info ] Unavailable |
| #1 | 819213 1 | PUMP ASSEMBLY-FUEL (1 required per assembly) |
  |
|
819213 1 - Fuel Pump,NLA [ More info ] Unavailable |
| #2 | 27-820748A 1 | GASKET/DIAPHRAGM KIT (1 required per assembly) |
  |
|
27-820748A 1 - Gasket/Diaphragm [ More info ] Unavailable |
| #3 | NSS | WASHER (2 required per assembly) . |
  |
|
NSS - NOT SOLD SEPARATE [ More info ] Unavailable |
| #4 | 10-820749 | SCREW (#10-24 X 1.250) (2 required per assembly) |
  |
|
10-820749 - Screw, NLA [ More info ]
|
| #5 | 10-819499 | SCREW (#10-24 X 1.625) (2 required per assembly) |
  |
|
10-819499 - Screw, NLA [ More info ]
|
| #6 | 25-38933 | O RING (1 required per assembly) |
  |
|
25-38933 - O-Ring, Lower Shift Control Shaft [ More info ]
|
  |
|
18-7120 - O-Ring 322598 [ More info ]
|
| #7 | 56762 | CABLE TIE (AR required per assembly) (4.00 IN.) |
  |
|
56762 - Tie Strap - Priced Individually [ More info ]
|
| #8 | 32-819398 53 | HOSE (1 required per assembly) (15.500 IN. BULK) (CUT 1.625 IN.) |
  |
32-819398 53 - Hose-18 INCH [ More info ] Unavailable |
|
  |
|
32-819398T - Hose -18 Inch [ More info ]
|
| #11 | F681954 1 | COVER-PRIMER BULB (1 required per assembly) |
  |
F681954-1 - Cover [ More info ] Unavailable |
|
  |
|
851934 - Primer Bulb Cover [ More info ] Unavailable |
| #12 | F681046 | BULB-PRIMER (1 required per assembly) |
  |
|
F681046 - Primer Bulb [ More info ]
|
| #14 | 35-816296 | FILTER-FUEL (1 required per assembly) |
  |
35-816296 - Fuel Filter [ More info ] Unavailable |
|
  |
35-816296Q - Fuel Filter - Priced Individually [ More info ] Unavailable |
|
  |
|
35-816296Q03 - Fuel Filter - Priced Individually [ More info ]
|
  |
|
18-7829 - Filter, 35-816296 [ More info ]
|
  |
|
35-816296K03 - Fuel Filter - Priced Individually [ More info ]
|
| #15 | 22-F197767 2 | CONNECTOR-FUEL (1 required per assembly) |
  |
|
22-F197767-2 - Fuel Bushing [ More info ]
|
