Parts for Force 15 HP (1984-1995) Ignition System (Ser. # E090400 - E127699)
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| # | 54-816311 | CABLE TIE (8") (2 required per assembly) |
  |
54-816311 - TIE STRAP Note: Priced Individually [ More info ] Unavailable |
|
  |
|
54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ]
|
| #1 | F681091 | NUT-FLYWHEEL (1 required per assembly) |
  |
|
F681091 - Nut, NLA [ More info ] Unavailable |
| #2 | 200-824380T | FLYWHEEL (PAINTED) (1 required per assembly) |
  |
200-824380T - Flywheel [ More info ] Unavailable |
|
  |
200-824380T 1 - Flywheel [ More info ] Unavailable |
|
  |
|
200-824380T 2 - Flywheel -w/Teeth, NLA [ More info ]
|
| #4 | 87-824440A 9 | SWITCH ASSEMBLY-STOP (1 required per assembly) |
  |
|
87-824440A 9 - Switch-STOP [ More info ]
|
  |
|
87-824440A15 - Stop Switch Assembly [ More info ]
|
| #5 | 824466A 3 | COVER ASSEMBLY-STOP SWITCH (1 required per assembly) |
  |
|
824466A 3 - Cover Kit, NLA [ More info ]
|
| #6 | 87-826214A 1 | SWITCH ASSEMBLY-EMERGENCY STOP (1 required per assembly) |
  |
|
87-826214A 1 - Switch Assembly [ More info ]
|
| #7 | 819399A 1 | LANYARD ASSEMBLY (1 required per assembly) |
  |
|
819399A 1 - Lanyard Assembly [ More info ]
|
  |
|
879104 - LANYARD W/CLIP,NLA [ More info ] Unavailable |
| #8 | 84-819379A 7 | HARNESS ASSEMBLY-ENGINE STOP (1 required per assembly) |
  |
|
84-819379A 7 - Harness Assembly, NLA [ More info ]
|
| #9 | 300-826692T | PLATE-STATOR (1 required per assembly) |
  |
300-826692T - Stator Plate [ More info ] Unavailable |
|
  |
|
828243T - Stator Plate Kit [ More info ]
|
| #10 | 300-819156T | MODULE-IGNITION (CUT WIRE AS REQ'D) (2 required per assembly) |
  |
300-819156T - Module - 5/15 HP [ More info ] Unavailable |
|
  |
|
300-850899T - Ignition Module -5/15 HP [ More info ] Unavailable |
| #11 | 826691 | CAM-THROTTLE (1 required per assembly) |
  |
826691 - CAM-THROTTLE [ More info ] Unavailable |
|
  |
826691 1 - CAM-THROTTLE [ More info ] Unavailable |
|
  |
|
855352 - Throttle Cam, NLA [ More info ]
|
| #12 | FK1123 | BOOT KIT-SPARK PLUG (2 required per assembly) |
  |
FK1123 - Boot Kit [ More info ] Unavailable |
|
  |
|
85-63709A 1 - Boot Kit - Black - Priced Individually [ More info ]
|
| #13 | 33-813423 | SPARK PLUG (9.9) (2 required per assembly) |
  |
33-813423 - NGK BPR6HS - Priced Individually [ More info ] Unavailable |
|
  |
|
33-8M0182857 - NGK BPR6HS @4 [ More info ] Unavailable |
  |
|
BPR6HS - NGK Spark Plug, 7022 [ More info ]
|
  |
|
RL87YC - Champion Spark Plug ( #327) [ More info ]
|
| #13 | 33-813414 | SPARK PLUG (15) (2 required per assembly) |
  |
33-813414 - NGK BP7HS Note: Priced Individually [ More info ] Unavailable |
|
  |
|
33-813414 1 - NGK BP7HS - Priced Individually [ More info ] Unavailable |
  |
|
BP7HS - NGK Spark Plug, 5111 [ More info ]
|
  |
|
L82YC - Champion Spark Plug ( #328) [ More info ]
|
| #13 | ORDER LOC | SPARK PLUG (15) (RFI) (CHAMPION # RL82YC) (OPT. required per assembly) ORDER LOCAL |
| #14 | 28-F458498 1 | KEY-CRANKSHAFT/FLYWHEEL (1 required per assembly) |
  |
|
28-F458498-1 - Key, NLA [ More info ]
|
| #15 | 22-F681188 | NUT-STOP SWITCH SLEEVE (1 required per assembly) |
  |
22-F681188 - CONNECTOR [ More info ] Unavailable |
|
  |
|
11-855594 - Nut, (Special)-Stop Switch Sleeve [ More info ]
|
| #16 | 10-824353 | SCREW (8-32 X 3/4")-IGNITION MODULE (6 required per assembly) |
  |
|
10-824353 - Screw, NLA [ More info ]
|
| #17 | 10-824352 | SCREW (10-24 X 3/8")-GROUND (1 required per assembly) |
  |
|
10-824352 - Screw [ More info ] Unavailable |
| #18 | 56762 | CABLE TIE (4") (AR required per assembly) |
  |
|
56762 - Tie Strap - Priced Individually [ More info ]
|
| #19 | 10-824358 | SCREW (10-24 X 1/2")-STATOR PLATE (5 required per assembly) |
  |
|
10-824358 - Screw, NLA [ More info ]
|
| #20 | 84-60466A16 | WIRE ASSEMBLY-GROUND (1 required per assembly) |
  |
84-60466A16 - Cable [ More info ] Unavailable |
|
  |
|
84-60466A21 - Cable Assembly, NLA [ More info ]
|
