Parts for Force 125 HP (1989) Gear Housing

Revise Search: All Models > 125 HP (1989) > 1254A9D ( ) > Gear Housing

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	-F438129	SEAL, DRIVESHAFT SPLINE (1 required per assembly)
		23-F438129 - Seal [ More info ] Unavailable
		25-819427 - Seal [ More info ] $3.69 6 In Stock.
#2	-F438271	RETAINER, DRIVESHAFT SPLINE SEAL (1 required per assembly)
		23-F438271 - Retainer, NLA [ More info ] Unavailable
#3	-F694128	DRIVESHAFT, UPPER (20 INCH MODELS) (1 required per assembly)
		45-F694128 - Drive Shaft -20 [ More info ] $99.99 $84.68 2 In Stock.
#	-F693128	DRIVESHAFT, UPPER (25 INCH MODELS) (1 required per assembly)
		45-F693128 - Drive Shaft -25, NLA [ More info ] $95.20 $80.63 2 In Stock.
#4	-F694125	COUPLING, DRIVESHAFT (1 required per assembly)
		F694125 - Coupling, NLA [ More info ] $63.75 $53.99 10+ In Stock.
#5	-F694736	SEAL (1 required per assembly)
		25-F694736 - O-Ring [ More info ] $15.58 10+ In Stock.
#6	-F7061	NUT, 1/4 - 28 (4 required per assembly)
		11-F7061 - Nut, Sold Individually [ More info ] Unavailable
		11-35045 - Nut (1/4-28) [ More info ] Unavailable
		11-826709109 - Nut, (.250-28) Stainless Steel [ More info ] $3.59 4 In Stock.
#7	-F2012	WASHER (4 required per assembly)
		F2012 - Washer [ More info ] Unavailable
		12-29245 - Washer [ More info ] $0.89 10+ In Stock.
		12-8M0204649 - WASHER Note: Priced Individually [ More info ] $1.20 7 In Stock.
#8	-F694210	STUD (4 required per assembly)
		16-F694210 - STUD-SS [ More info ] Unavailable
		16-826372 - Stud [ More info ] Unavailable
		16-30667 - Stud [ More info ] Unavailable
		16306671 - Stud [ More info ] $10.19 Available to Order: Shipping delay up to 10 days.
#9	-F694735-1	SEAL, WATER LINE (1 required per assembly)
		26-F694735-1 - Water Line Seal [ More info ] $7.99 Available to Order: Shipping delay up to 10 days.
#10	-F694060-1	BODY, WATER PUMP (1 required per assembly)
		F694060-1 - 46F6940602 [ More info ] Unavailable
		46-F694060-2 - Water Pump Body [ More info ] Unavailable
		46-803757T - Water Pump Body [ More info ] $42.92 2 In Stock.
#11	-F694564-1	INSERT (1 required per assembly)
		F694564-1 - Insert [ More info ] $30.29 Available to Order: Shipping delay up to 10 days.
#12	-F694065	IMPELLER (1 required per assembly)
		47-F694065 - Impeller [ More info ] Unavailable
		47-803631T - Impeller [ More info ] Unavailable
		47-89984T 3 - Impeller [ More info ] $45.99 3 In Stock.
		18-3017 - Impeller 47-89984 [ More info ] $39.99 $23.95 10+ In Stock.
#13	-F694498	KEY (1 required per assembly)
		28-F694498 - Key [ More info ] $17.29 Available to Order: Shipping delay up to 10 days.
#14	-F694031	GASKET (1 required per assembly)
		27-F694031 - Water Pump Gasket [ More info ] $3.69 3 In Stock.
#15	-F694562	PLATE (1 required per assembly)
		F694562 - Plate -with Hole [ More info ] $19.08 $18.32 2 In Stock.
#16	-F694830	GASKET (1 required per assembly)
		27-F694830 - Water Pump Gasket [ More info ] $2.69 4 In Stock.
#17	-F694211	STUD (1 required per assembly)
		16-F694211 - STUD,NLA [ More info ] Unavailable
#18	-F8143	WASHER (1 required per assembly)
		12-F8143 - WASHER,NLA [ More info ] Unavailable
#19	-F7062	NUT, 10 - 32 (1 required per assembly)
		11-F7062 - Nut - Priced Individually [ More info ] Unavailable
		11-29488 - Nut, (#10-32) [ More info ] $3.61 10+ In Stock.
		11-826709106 - Nut, (#10-32) Stainless Steel [ More info ] $4.50 6 In Stock.
		11-8M0204718 - NUT [ More info ] $4.69 Available to Order: Shipping delay up to 10 days.
#20	-F1015	COTTER PIN (1 required per assembly)
		18-F1015 - Cotter Pin - Priced Individually [ More info ] $1.46 10+ In Stock.
#21	-F694615	ROD, INTERMEDIATE SHIFT (1 required per assembly)
		F694615 - ROD-SHIFT,NLA [ More info ] Unavailable
#22	-F85372	PIN (1 required per assembly)
		17-F85372 - Gear Shift Rod Lower Pin [ More info ] $6.39 3 In Stock.
#23	-F694618	BELLOWS (1 required per assembly)
		F694618 - Bellows, NLA [ More info ] Unavailable
		FK721706 - Gear Housing Cover [ More info ] Unavailable
#24	-F2A694706	COVER, GEAR HOUSING W/SEAL (1 required per assembly)
		F2A694706 - FK721706, NLA [ More info ] Unavailable
#25	-F1999	SCREW, 1/4 - 20 X 7/8 (4 required per assembly)
		10-F1999 - Screw -ss [ More info ] $1.10 10 In Stock.
		10-28668 - Screw - Priced Individually [ More info ] $1.70 Available to Order: Shipping delay up to 10 days.
#27	-F694307	SEAL (1 required per assembly)
		26-F694307 - F6943071 [ More info ] Unavailable
		F694307-1 - SEAL [ More info ] Unavailable
		26-819740 - Seal [ More info ] $8.79 4 In Stock.
#28	-F694305	SEAL (1 required per assembly)
		26-F694305 - Seal [ More info ] Unavailable
		26-89238 - Seal [ More info ] $21.68 1 In Stock.
		18-2014 - Seal 26-89238, 26F69430 [ More info ] $18.86 5 In Stock.
		26-00171 - Seal 26-89238, 26F694305 [ More info ] $16.99 $14.00 Available to Order: Shipping delay up to 10 days.
#29	-F74305	SEAL (1 required per assembly)
		25-F74305 - Drive Shaft Cover O-Ring [ More info ] Unavailable
		25-90011 - Drive Shaft Cover O-Ring [ More info ] Unavailable
		25-896523 - O-ring, (2.175 X .103) [ More info ] Unavailable
		25-8M0142854 - O-Ring [ More info ] $1.10 5 In Stock.
#30	-F694961	RETAINER (1 required per assembly)
		F694961 - F6949611 [ More info ] Unavailable
		F694961-1 - Retainer [ More info ] Unavailable
		824519 - Retainer [ More info ] Unavailable
		824519 1 - Retainer [ More info ] $6.99 Available to Order: Shipping delay up to 10 days.
		18-2346 - Retainer, 824519 1 [ More info ] $5.25 Available to Order: Shipping delay up to 10 days.
#32	-F695930	RING, RETAINING (1 required per assembly)
		53-F695930 - RING-RETAINING [ More info ] Unavailable
		53-818826 - Ring - Retaining, NLA [ More info ] $9.69 10+ In Stock.
#33	-FS694628	DRIVESHAFT, LOWER W/ PINION GEAR AND BEARING (1 required per assembly)
		45-FS694628 - 45FS707628 [ More info ] Unavailable
		45-FS707628 - Drive Shaft, Force [ More info ] Unavailable
#34	-F9280	SHIM, (.002) (A/R required per assembly)
		15-F9280 - Shim - (.002), NLA [ More info ] Unavailable
#	-F9279	SHIM, (.003) (A/R required per assembly)
		15-F9279 - Shim - (.003), NLA [ More info ] Unavailable
#	-F9278	SHIM, (.005) (A/R required per assembly)
		15-F9278 - Shim - (.005), NLA [ More info ] $2.20 $1.86 10+ In Stock.
#	-F9277	SHIM, (.010) (A/R required per assembly)
		15-F9277 - Shim - (.010), NLA [ More info ] $1.88 $1.59 1 In Stock.
#35	-F694705	ROD, LOWER SHIFT (1 required per assembly)
		F694705 - ROD-SHIFT,NLA [ More info ] Unavailable
#36	-FA84621-1	ARM (1 required per assembly)
		FA84621-1 - Coupling [ More info ] Unavailable
#37	-F694057	BEARING (1 required per assembly)
		31-F694057 - Bearing [ More info ] Unavailable
		31-42647A 1 - Roller Bearing - Drive Shaft [ More info ] $65.99 Available to Order: Shipping delay up to 10 days.
		18-1117 - Bearing, 387817, 31-42647A1 [ More info ] $56.09 1 In Stock.
		31-02762 - Bearing, 31-42647A1, 387817 [ More info ] $47.99 $40.13 In Stock
#38	-F694186	WASHER (1 required per assembly)
		12-F694186 - Washer - Priced Individually [ More info ] Unavailable
		12-92721 - Washer, Pinion Gear [ More info ] $1.50 $0.85 10+ In Stock.
		18-2359 - Nut Kit [ More info ] $5.19 $3.51 Available to Order: Shipping delay up to 10 days.
#39	-F694226	PLUG, PITOT (1 required per assembly)
		F694226 - PLUG,NLA [ More info ] $3.65 2 In Stock.
		892827 - PLUG,NLA [ More info ] Unavailable
#40	-F50109	PLUG (3 required per assembly)
		10-F50109 - Screw -Special [ More info ] $7.77 4 In Stock.
		10-79953A 2 - Drain Screw Kit [ More info ] Unavailable
		10-79953Q 2 - Screw Kit - Priced Individually [ More info ] Unavailable
		10-79953Q04 - Screw Kit - Priced Individually [ More info ] $7.49 9 In Stock.
		18-2244 - Plug Kit, 10-79953A2 [ More info ] $3.79 10+ In Stock.
		10-79953K04 - Drain Screw - Priced Individually [ More info ] $8.19 6 In Stock.
#41	-F8077	WASHER (3 required per assembly)
		F8077 - SEAL [ More info ] Unavailable
		F8186 - Washer-BLK - Priced Individually [ More info ] Unavailable
		12-19183 - Washer (3/8 Inch Screw) [ More info ] Unavailable
		12-19183 2 - Washer - Priced Individually [ More info ] Unavailable
		12-19183 3 - Seal -Blue - Priced Individually [ More info ] Unavailable
		12-8M0187157 - SEAL-BLUE, Sold Individually [ More info ] $1.49 10+ In Stock.
		18-2945-9 - Gasket 12-19183 2-Pack [ More info ] $2.41 10+ In Stock.
		12-19183Q02 - Seals, Pack of 4 (yes this is actually a pack of 4) [ More info ] $6.69 10+ In Stock.
		12-19183K02 - Seal, Pack of 4 [ More info ] $7.29 6 In Stock.
		12-02108-1 - Drain Gasket (1 piece) [ More info ] $1.20 $0.85 10+ In Stock.
#42	-F498618	SEAL (1 required per assembly)
		25-F498618 - O-Ring [ More info ] Unavailable
		26-817469 - O-Ring [ More info ] Unavailable
		25-25007 - O-ring, Gear Shift Arm Pin [ More info ] $1.50 Available to Order: Shipping delay up to 10 days.
		18-7120 - O-Ring 322598 [ More info ] $1.07 5 In Stock.
#43	-F498891	PIN (1 required per assembly)
		F498891 - Shift Pivot Pin [ More info ] Unavailable
		817468 - Shift Pivot Pin [ More info ] Unavailable
		826374 - Pin - Retainer [ More info ] Unavailable
#44	-F1491	SCREW, 5/16 - 18 X 3-1/4 (6 required per assembly)
		10-F1491 - Screw -ss [ More info ] $9.40 $7.52 7 In Stock.
#45	-F8096	WASHER (7 required per assembly)
		F8096 - LockWasher - Priced Individually [ More info ] Unavailable
		13-53166 - LockWasher - Priced Individually [ More info ] $1.80 10+ In Stock.
#46	-F1858	SCREW, 5/16 - 18 X 1 (1 required per assembly)
		10-F1858 - Screw -ss, NLA [ More info ] $3.56 2 In Stock.
#47	-F9284	SHIM (.002) (A/R required per assembly)
		15-F9284 - Shim - (.002), NLA [ More info ] $4.50 $3.82 4 In Stock.
#	-F9283	SHIM (.003) (A/R required per assembly)
		15-F9283 - Shim - (.003) [ More info ] Unavailable
#	-F9282	SHIM (.005) (A/R required per assembly)
		15-F9282 - Shim - (.005), NLA [ More info ] Unavailable
#	-F9281	SHIM (.010) (A/R required per assembly)
		15-F9281 - Shim - (.010), NLA [ More info ] $2.00 $1.69 10+ In Stock.
#48	-FS694023	GEAR, FORWARD W/BEARING AND CUP (1 required per assembly)
		43-FS694023 - Forward Gear Only, NLA [ More info ] Unavailable
		FS707023 - Forward Gear Only [ More info ] Unavailable
		43-816434A 5 - Forward Gear Only [ More info ] $124.99 $105.86 8 In Stock.
#49	-F2290	SPACER (.060) (A/R required per assembly)
		23-F2290 - Spacer - (.060), NLA [ More info ] Unavailable
#	-F2291	SPACER (.070) (A/R required per assembly)
		23-F2291 - Spacer - (.070), NLA [ More info ] Unavailable
#	-F2292	SPACER (.080) (A/R required per assembly)
		23-F2292 - Spacer - (.080), NLA [ More info ] Unavailable
#50	-F694521	CLUTCH (1 required per assembly)
		F694521 - Clutch [ More info ] Unavailable
		52-816433 - Clutch [ More info ] $149.99 1 In Stock.
		52-816433T - Clutch [ More info ] $363.49 Available to Order: Shipping delay up to 10 days.
#51	-F1713	SPRING PIN (1 required per assembly)
		F1713 - 17F2419 [ More info ] Unavailable
		17-F2419 - Spring Pin [ More info ] $1.43 2 In Stock.
		17-8M0029889 - Pin -roll [ More info ] $2.11 10+ In Stock.
#52	-F84871-1	SHIFT PIN (1 required per assembly)
		17-F84871-1 - Gear Shift Pin [ More info ] Unavailable
#53	-F90619-2	YOKE (1 required per assembly)
		F90619-2 - Yoke [ More info ] $61.49 Available to Order: Shipping delay up to 10 days.
#54	-FA694098	SHAFT, PROPELLER (1 required per assembly)
		44-FA694098 - Prop Shaft Assembly, NLA [ More info ] Unavailable
#55	-F438930	RETAINER SNOUT (1 required per assembly)
		10-F438930 - Screw [ More info ] $5.99 1 In Stock.
		10-826377 - Screw [ More info ] $10.76 10+ In Stock.
#56	-F523116-1	SNOUT, EXHAUST (1 required per assembly)
		F523116-1 - F5231164 [ More info ] Unavailable
		F523116-4 - SNOUT NLA [ More info ] Unavailable
#57	-F1856	WASHER (1 required per assembly)
		12-F1856 - Washer, NLA [ More info ] $1.62 10+ In Stock.
#58	-F1994	SCREW, 5/16 - 18 X 1 (1 required per assembly)
		10-F1994 - Screw - SS [ More info ] $1.49 10+ In Stock.
		10-90073 - Screw [ More info ] $1.85 $1.46 10+ In Stock.
#59	-F2A694662	GEAR, REVERSE W/BEARING (1 required per assembly)
		43-F2A694662 - Reverse Gear Assembly [ More info ] Unavailable
		43-803843T - Gear Assembly - Rear, NLA [ More info ] $79.99 $67.74 6 In Stock.
#60	-F523411	RETAINING RING (1 required per assembly)
		53-F523411 - Ring - Retaining, NLA [ More info ] $14.43 $12.23 4 In Stock.
#61	-F84305	SEAL (1 required per assembly)
		25-F84305 - Seal [ More info ] $4.43 10+ In Stock.
		25-32507 - O-ring, (3.359 X .139) [ More info ] $5.19 1 In Stock.
		18-7127 - O-Ring 313446 [ More info ] $3.99 $3.93 Available to Order: Shipping delay up to 10 days.
#62	-F2A523239	SPOOL, PROPELLER SHAFT W/BEARING AND SEALS (1 required per assembly)
		F2A523239 - Spool Assembly [ More info ] Unavailable
		803940T - Spool Assembly, NLA [ More info ] Unavailable
#63	-F24278	SEAL (1 required per assembly)
		25-F24278 - O-Ring Seal-Propshaft Spool (type A) [ More info ] Unavailable
		18-7169-9 - O-Ring (PK5) 25-70937, 911686 [ More info ] $20.63 Available to Order: Shipping delay up to 10 days.
#64	-F523058	BEARING (1 required per assembly)
		31-F523058 - Bearing [ More info ] Unavailable
		31-30956 - Roller Bearing - Bearing Carrier [ More info ] Unavailable
		31-30956T - Roller Bearing [ More info ] $19.88 4 In Stock.
#65	-F506118-1	SEAL (1 required per assembly)
		26-F506118-1 - 26-F506118-1 - SEAL [ More info ] Unavailable Replaced by 26-F506118-1
#66	-F50342-1	SEAL (4 required per assembly)
		25-F50342-1 - Seal - Priced Individually [ More info ] Unavailable
		25-62702 - O-ring, (.301 X .070) [ More info ] Unavailable
		25-62702 1 - O-Ring [ More info ] $1.70 10+ In Stock.
#67	-F1907	WASHER (4 required per assembly)
		F1907 - Washer, Stainless Steel [ More info ] Unavailable
		12-12038 - Washer [ More info ] $2.30 3 In Stock.
		12-8M0207778 - WASHER Note: Priced Individually [ More info ] $11.89 5 In Stock.
#68	-F1885	SCREW, 5/16 - 18 X 4-1/4 (4 required per assembly)
		10-F1885 - Screw -ss, NLA [ More info ] $2.50 $2.13 10+ In Stock.
#69	-FA523485	ANODE, ANTI-CORROSION (1 required per assembly)
		FA523485 - Anti-Corrosion Anode, NLA [ More info ] Unavailable
#70	-F8083	LOCKWASHER (2 required per assembly)
		F8083 - LockWasher SS [ More info ] Unavailable
		13-26992 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#71	-F1112	SCREW, 1/4 - 20 X 7/8 (2 required per assembly)
		10-F1112 - Screw -ss, NLA [ More info ] $2.57 10+ In Stock.
#72	-F523099-1	SPACER, PROPELLER (1 required per assembly)
		23-F523099-1 - Propeller Spacer [ More info ] Unavailable
#74	-F523282	WASHER, PROP SPLINE (1 required per assembly)
		12-F523282 - Washer (splined) NLA [ More info ] Unavailable
#75	-F8167	WASHER (1 required per assembly)
		12-F8167 - Washer [ More info ] Unavailable
#76	-F7048	STOP NUT (1 required per assembly)
		11-F7048 - Prop Nut - Priced Individually [ More info ] $13.97 1 In Stock.
#77	-F523244	INLET WATER LINE (20 INCH MODELS) (1 required per assembly)
		32-F523244 - Water Line -20 In, NLA [ More info ] $47.43 10+ In Stock.
#	-F500244	INLET WATER LINE (25 INCH MODELS) (1 required per assembly)
		32-F500244 - LINE-WATER-25 IN,NLA [ More info ] $40.00 10+ In Stock.
#78	-F523899	GROMMET, WATER LINE (1 required per assembly)
		F523899 - Grommet, Inlet Water Line [ More info ] Unavailable
		25-817491 - Grommet, (.56 Inside Diameter) [ More info ] $5.89 Available to Order: Shipping delay up to 10 days.
#79	-F84342	SEAL, WATER LINE (1 required per assembly)
		25-F84342 - Water Line Seal [ More info ] Unavailable
#80	-F85117	BRACKET, WATER LINE (1 required per assembly)
		F85117 -Waterline Bracket [ More info ] Unavailable
		F692117 - Bracket, NLA [ More info ] Unavailable
#81	-F1705	SCREW, 1/4 - 20 X 3/4 S.S. (2 required per assembly)
		F1705 - Screw - Priced Individually [ More info ] Unavailable
		10-28636 - Screw - Priced Individually [ More info ] $1.80 10+ In Stock.
#82	-FK1203	SEAL KIT (1 required per assembly)
		FK1203 - FK12031 [ More info ] Unavailable
		FK1203-1 - Seal Kit [ More info ] Unavailable
		18-2640 - Seal Kit, FK1203 1 [ More info ] $96.99 $96.66 1 In Stock.
#83	-FK1202	WATER PUMP KIT (1 required per assembly)
		FK1202 - Water Pump Kit [ More info ] Unavailable
		FK1202-1 - Water Pump Kit [ More info ] $118.49 $113.52 2 In Stock.
#84	-F694056	CUP, BEARING (1 required per assembly)
		31-F694056 - Bearing Cup [ More info ] Unavailable
#85	-F694058	BEARING (CONE) (1 required per assembly)
		31-F694058 - Bearing [ More info ] Unavailable
		31-35924A 1 - Bearing Set [ More info ] Unavailable
		31-35924T 1 - Bearing [ More info ] Unavailable
#86	-F694299	SPACER (1 required per assembly)
		F694299 - SPACER-PROP [ More info ] Unavailable
		F694099 - Thrust Washer, NLA [ More info ] $40.33 $34.16 10+ In Stock.
#87	-FA694054	GEAR HOUSING (1 required per assembly)
		FA694054 - Gear Housing [ More info ] Unavailable
		1600-819190A 1 - Gear Housing Kit [ More info ] Unavailable
		1600-819190A 2 - Gear Housing Kit [ More info ] Unavailable
		1600-819190A 3 - Basic Gear Housing Assembly [ More info ] Unavailable
		1600-817925A 5 - Gear Housing, NLA [ More info ] Unavailable
#	-FC694054	GEAR HOUSING COMPLETE (1 required per assembly)
		FC694054 - Gear Housing Complete [ More info ] Unavailable
		1600-817925A 3 - Gear Housing [ More info ] Unavailable
		1600-817925A 4 - Gear Housing Kit [ More info ] Unavailable
