Parts for Force 125 HP (1987) Power Trim Unit

Revise Search: All Models > 125 HP (1987) > 1258F7A ( ) > Power Trim Unit

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	F17543	HEAD ASSEMBLY, COMMUTATOR END (1 required per assembly)
		F17543 - Head Assembly [ More info ] Unavailable
		803889T - Head Assembly [ More info ] $149.99 Available to Order: Shipping delay up to 10 days.
#2	F17539	BALL (1 required per assembly)
		F17539 - Ball, NLA [ More info ] $1.36 10+ In Stock.
#3	F17504	BRUSH SET (1 required per assembly)
		F17504 - Brush Set [ More info ] Unavailable
		F17611 - Brush Set [ More info ] Unavailable
		392-8989 - Brush Set for 3 - Wire Motors Only. [ More info ] $14.99 2 In Stock.
#4	F17500	SPRING SET (1 required per assembly)
		F17500 - Spring Set-brush (2 Per Set) [ More info ] Unavailable
		392-2529 - Spring Set, Brush Tension,NLA [ More info ] $11.70 10+ In Stock.
#5	F17557	GASKET (2 required per assembly)
		F17557 - Gasket [ More info ] $16.40 8 In Stock.
#6	F17556	FIELD AND FRAME ASSEMBLY (1 required per assembly)
		F17556 - FK654541, NLA [ More info ] Unavailable
		FK654541 - Trim Motor [ More info ] Unavailable
		6216 - Trim Motor, 172543, F17563 [ More info ] $311.75 In Stock
#7	F17555	ARMATURE (1 required per assembly)
		F17555 - Armature, Use ARC6216 , NLA [ More info ] Unavailable
#8	F449843	CABLE (1 required per assembly)
		F449843 - 84F4498431 [ More info ] Unavailable
		84-F449843-1 - Cable Assembly, NLA [ More info ] Unavailable
#9	F1877	TY-RAP (4 required per assembly)
		F1877 - TY RAP [ More info ] Unavailable
		54-816311 - TIE STRAP Note: Priced Individually [ More info ] Unavailable
		54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ] $0.60 10+ In Stock.
#10	F449181	PLATE, TRIM SWITCH (1 required per assembly)
		38-F449181 - Plate [ More info ] $2.93 $2.48 10+ In Stock.
#11	F17508	THRUST WASHER (A/R required per assembly)
		F17508 - Washer, Thrust, NLA [ More info ] $6.52 $5.53 10+ In Stock.
#12	F17518	FILLER CAP (1 required per assembly)
		F17518 - Filler Cap [ More info ] Unavailable
#13	F17510	O-RING (1 required per assembly)
		F17510 - 25F503421 [ More info ] Unavailable
		25-F50342-1 - Seal - Priced Individually [ More info ] Unavailable
		25-62702 - O-ring, (.301 X .070) [ More info ] Unavailable
		25-62702 1 - O-Ring [ More info ] $1.70 10+ In Stock.
#14	F17505	RESERVOIR AND BRACKET W/SEAL (1 required per assembly)
		F17505 - Reservoir,NLA [ More info ] Unavailable
#15	F1966	PLUG, SWIVEL BRACKET (1 required per assembly)
		19-F1966 - Plug, NLA [ More info ] Unavailable
#16	F1203	HEX CAP SCREW, 1/4 - 20 X 7/8 (1 required per assembly)
		F1203 - Screw - Priced Individually [ More info ] Unavailable
		10-28668 - Screw - Priced Individually [ More info ] $1.70 4 In Stock.
#17	F17564	VALVE BODY AND PUMP (1 required per assembly) W/ILLUS. 16, 18, 19 AND 21
		F17564 - FK654541, See Note Below!, Nl [ More info ] Unavailable
#18	F17566	IDLE GEAR (1 required per assembly)
		F17566 - Idler Gear, NLA [ More info ] Unavailable
#19	F17565	DRIVE GEAR (1 required per assembly)
		F17565 - GEAR-DRIVE-T/T,NLA [ More info ] Unavailable
#20	F17563	MOTOR AND RESERVOIR (1 required per assembly)
		F17563 - Motor & Reservoir [ More info ] Unavailable
#21	F17522	O-RING (1 required per assembly)
		F17522 - O-Ring [ More info ] Unavailable
		392-2525 - O Ring (3.125 O.d.) [ More info ] $5.99 6 In Stock.
#22	F1310	ROUND HD SCREW, 10 - 24 X 5/8 (4 required per assembly)
		F1310 - Screw, NLA [ More info ] $1.94 10+ In Stock.
#23	F449254	HYDRAULIC LINE, TRIM CYLINDER, UPPER (1 required per assembly)
		32-F449254 - Hydraulic Line, NLA [ More info ] $36.00 $30.49 1 In Stock.
#24	F1959	SCREW, 1/4 - 20 X 1-3/4, STAINLESS STEEL (5 required per assembly)
		10-F1959 - Screw -ss , NLA [ More info ] Unavailable
#25	F449354	THRUST BRACKET (1 required per assembly)
		F449354 - Bracket, NLA [ More info ] $18.23 5 In Stock.
#26	F1734	SCREW AND LOCKWASHER, 1/4 - 20 X 1/2 (2 required per assembly)
		F1734 - Screw w/ Lw, NLA [ More info ] Unavailable
		10-34939 - Screw w/ Lw, NLA [ More info ] $1.96 10+ In Stock.
#27	FA449149	COVER W/SEALS AND RETAINER (1 required per assembly)
		FA449149 - Hydraulic Cylinder Cover [ More info ] Unavailable
		817802A 2 - Hydraulic Cylinder Cover [ More info ] Unavailable
		817802A 3 - Cover, NLA [ More info ] Unavailable
#28	F449342	SEAL, PISTON SHAFT (1 required per assembly)
		25-F449342 - O-ring, Piston Shaft [ More info ] $1.00 3 In Stock.
#29	FA449015	PISTON (1 required per assembly)
		FA449015 - Hydraulic Piston Assembly [ More info ] Unavailable
		803481T - Hydraulic Piston Assembly [ More info ] Unavailable
#30	F449278	PISTON SEAL (1 required per assembly)
		25-F449278 - O-ring, Piston [ More info ] $2.99 5 In Stock.
#31	F40278	SEAL, CYLINDER (2 required per assembly)
		25-F40278 - O-Ring [ More info ] $3.39 5 In Stock.
#32	F449010	CYLINDER (1 required per assembly)
		F449010 - Hydraulic Cylinder [ More info ] Unavailable
		803823T - Hydraulic Cylinder [ More info ] $79.99 Available to Order: Shipping delay up to 10 days.
#33	F449545-2	CYLINDER HOUSING (1 required per assembly)
		F449545-2 - Housing-HYD T/T [ More info ] Unavailable
		818055F - Housing, Hydraulic Tilt Trim [ More info ] Unavailable
#34	F1963	NUT, 5/8 - 18 (2 required per assembly)
		F1963 - 11F7053 [ More info ] Unavailable
		11-F7053 - Nut, (5/8-18) Brass [ More info ] $13.80 Available to Order: Shipping delay up to 10 days.
#35	F449362	BEARING (2 required per assembly)
		23-F449362 - Bushing [ More info ] $9.89 3 In Stock.
#36	F449632	SHAFT (1 required per assembly)
		F449632 - Shaft SS [ More info ] $85.00 $81.60 10+ In Stock.
#37	F449253-1	HYDRAULIC LINE TRIM CYLINDER, LOWER (1 required per assembly)
		32-F449253-1 - Hydraulic Line- Lower [ More info ] Unavailable
#38	F449758	HYDRAULIC LINE, LIFT CYLINDER, UPPER (1 required per assembly)
		32-F449758 - Hydraulic Line [ More info ] $53.18 1 In Stock.
#39	F449754-1	HYDRAULIC LINE, LIFT CYLINDER, LOWER (1 required per assembly)
		32-F449754-1 - Hydraulic Line, NLA [ More info ] $28.70 $24.32 2 In Stock.
#40	FA17559	LIFT CYLINDER COMPLETE (1 required per assembly) W/ILLUS. 41
		FA17559 - FS654381, NLA [ More info ] Unavailable
		FS654381 - Lift Cylinder [ More info ] Unavailable
		819365A 2 - Lift Cylinder Assembly, NLA [ More info ] Unavailable
#41	F178344	BUSHING, SHOCK ABSORBER - UPPER (1 required per assembly)
		23-F178344 - Bushing, NLA [ More info ] Unavailable
#42	F17577	ADAPTER FITTING PACKAGE (1 required per assembly)
		F17577 - BAND [ More info ] Unavailable
		F2A654983 - Tilt Cylinder Band Assembly [ More info ] $82.77 2 In Stock.
#43	F17558	THRU-BOLT PACKAGE (1 required per assembly)
		F17558 - Thru Bolt Package, NLA [ More info ] Unavailable
#44	FA17561-1	O-RING (1 required per assembly) W/LITERATURE
		FA17561-1 - 25F654984 [ More info ] Unavailable
		25-F654984 - O-Ring [ More info ] $6.79 6 In Stock.
#45	F17562-1	PISTON ASSEMBLY (1 required per assembly)
		F17562-1 - FA654015 FA654015 [ More info ] Unavailable
		FA654015 - Order 819108F Assembly, NLA [ More info ] Unavailable
#46	F17528	O-RING (1 required per assembly)
		F17528 - 25F654618 [ More info ] Unavailable
		25-F654618 - O-Ring [ More info ] $1.70 3 In Stock.
#47	F17560	HEAD ASSEMBLY (1 required per assembly)
		F17560 - Head Assembly [ More info ] Unavailable
		FA654055 - Cap [ More info ] Unavailable
#48	F413420	RETAINER, SWITCH PLATE (1 required per assembly)
		F413420 - Retainer, NLA [ More info ] $5.63 $4.77 10+ In Stock.
#49	F1931	NUT, 1/2 - 20, STAINLESS STEEL (2 required per assembly)
		F1931 - Nut (.500-20) [ More info ] Unavailable
		11-35778 - Nut (1/2-20) [ More info ] Unavailable
		11-826709117 - Nut, (.500-20) Stainless Steel [ More info ] $10.99 4 In Stock.
#50	F1960	PLAIN WASHER (2 required per assembly)
		12-F1960 - Washer, NLA [ More info ] Unavailable
#51	F449889	SHAFT, UPPER (1 required per assembly)
		F449889 - Upper Shaft SS [ More info ] $66.42 $56.26 10+ In Stock.
#52	F1822	SCREW, 5/16 - 18 X 7/8, STAINLESS STEEL (3 required per assembly)
		10-F1822 - Screw -ss [ More info ] Unavailable
		10-28782 - Screw - Priced Individually [ More info ] $2.99 10+ In Stock.
#53	F299449-4	TOGGLE SWITCH (1 required per assembly)
		87-F299449-4 - Switch Assembly, NLA [ More info ] $23.95 10+ In Stock.
#54	F1934	FLAT HD THREAD FORMING SCREW 6 X 1/2 (4 required per assembly)
		10-F1934 - Screw -ss, NLA [ More info ] $1.25 $1.06 10+ In Stock.
