Parts for Chrysler 85 HP (1978) Starter
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| # | FS480955 | STARTER COMPLETE (1 required per assembly) |
  |
FS480955 - FK616955, NLA [ More info ] Unavailable |
|
  |
|
FK616955 - Starter Kit [ More info ] Unavailable |
  |
|
18-5613 - Starter, 50-819085 [ More info ]
|
  |
|
5393 - Outboard Starter [ More info ]
|
| #1 | F15111 | NUT, STOP RETAINING (1 required per assembly) |
  |
F15111 - 11F7001 [ More info ] Unavailable |
|
  |
|
11-F7001 - Nut, NLA [ More info ]
|
| #2 | F15112 | STOP, PINION (1 required per assembly) |
  |
|
F15112 - Starter Part, NLA [ More info ] Unavailable |
| #3 | F15080 | SPRING (1 required per assembly) |
  |
|
F15080 - Spring, NLA [ More info ]
|
| #4 | F15110 | CLUTCH ASSEMBLY (1 required per assembly) |
  |
F15110 - Starter Drive [ More info ] Unavailable |
|
  |
|
F15100 - Starter Drive, NLA [ More info ]
|
| #5 | F15167 | HEAD ASSEMBLY DRIVE END (1 required per assembly) |
  |
|
F15167 - Head Assembly, NLA [ More info ] Unavailable |
| #6 | F1641 | LOCK NUT, 1/4 - 28 (2 required per assembly) |
  |
F1641 - Nut, 1/4 - 28 [ More info ] Unavailable |
|
  |
|
|
  |
|
11-826708 9 - Nut - Priced Individually [ More info ]
|
  |
|
18-3722-9 - Lock Nut, 121731, 11-35888, Pack of 5 [ More info ]
|
| #7 | F15126 | THRUST WASHER PACKAGE (1 required per assembly) |
  |
|
F15126 - WASHER PKG,NLA [ More info ] Unavailable |
| #8 | F15099 | ARMATURE (1 required per assembly) |
  |
|
F15099 - Armature, NLA [ More info ] Unavailable |
| #9 | 15169 | FRAME AND FIELD ASSEMBLY (1 required per assembly) |
| #10 | F15165 | BRUSH TERMINAL SET (1 required per assembly) |
  |
|
F15165 - Brush and Terminal Set, NLA [ More info ]
|
| #11 | FA15072 | HEX LOCK NUT, 1/4 - 20 (1 required per assembly) |
  |
|
FA15072 - FA15072 - NUT [ More info ] Unavailable Replaced by -F15162 |
  |
|
F15162 - Nut (1/4-20) NLA [ More info ]
|
| #12 | F15168 | THRU BOLT PACKAGE (1 required per assembly) |
  |
|
F15168 - Thru Bolt P, NLA [ More info ]
|
| #13 | F8028 | PLAIN WASHER (2 required per assembly) |
  |
F8028 - 12F8008 [ More info ] Unavailable |
|
  |
12-F8008 - Washer [ More info ] Unavailable |
|
  |
|
12-35044 - Washer, (.281 X .625 X .065) Stainless Steel [ More info ]
|
| #14 | F1502 | HEX HD SCREW, 1/4 - 20 X 5/8 (1 required per assembly) |
  |
|
|
  |
|
10-98254 - Screw [ More info ]
|
| #15 | F511675 | STARTER BRACKET, LOWER (1 required per assembly) |
  |
|
F511675 - Bracket, NLA [ More info ]
|
| #16 | F15125 | HEAD ASSEMBLY, COMMUTATOR END (1 required per assembly) |
  |
|
F15125 - Starter Part, NLA [ More info ] Unavailable |
| #17 | F15034 | SPRING SET (1 required per assembly) |
  |
F15034 - Spring Set [ More info ] Unavailable |
|
  |
|
392-2514 - Spring Set (2 Springs Per Set)NLA [ More info ]
|
| #18 | F15057 | BRUSH PLATE AND HOLDER (1 required per assembly) |
  |
|
F15057 - Holder w/o Brushes, NLA [ More info ]
|
| #19 | F85908 | STARTER LEAD WIRE (1 required per assembly) |
  |
F85908 - 84F859081 [ More info ] Unavailable |
|
  |
|
84-F85908-1 - Wire Assembly, NLA [ More info ]
|
| #20 | F15100 | BENDIX (1 required per assembly) |
