Parts for Chrysler 85 HP (1978) Distributor
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| # | 817822A 1 | DISTRIBUTOR (1 required per assembly) |
  |
|
817822A 1 - Distributor,Chrysler O/B [ More info ] Unavailable |
| # | 481373 1 | DECAL, "ELECTRONIC" (NOT SHOWN) (1 required per assembly) |
| #1 | F85311 | DISTRIBUTOR BELT (1 required per assembly) |
  |
|
57-F85311 - Distributor Belt [ More info ]
|
| #2 | F7013 | STOP NUT (1 required per assembly) |
  |
|
11-F7013 - Nut, NLA [ More info ]
|
| #3 | 817786A 1 | DISTRIBUTOR PULLEY (1 required per assembly) |
  |
|
817786A 1 - Pulley Kit, NLA [ More info ] Unavailable |
| #4 | F14025 | SPACER (1 required per assembly) |
  |
|
F14025 - Spacer, NLA [ More info ] Unavailable |
| #5 | F14028 | THRUST WASHER (1 required per assembly) |
  |
|
F14028 - Thrust Washer, NLA [ More info ] Unavailable |
| #6 | F85173 | RETAINING RING (1 required per assembly) |
  |
|
53-F85173 - RING-RETAIN,NLA [ More info ] Unavailable |
| #7 | F14029 | THRUST WASHER (1 required per assembly) |
  |
|
F14029 - Thrust Wash, NLA [ More info ] Unavailable |
| #8 | F1612 | HEX CAP SCREW, 3/8 - 16 X 1 1/4 (2 required per assembly) |
  |
F1612 - Screw - Priced Individually [ More info ] Unavailable |
|
  |
|
10-35047 - Screw - Priced Individually [ More info ]
|
| #9 | F2014 | PLAIN WASHER (2 required per assembly) |
  |
|
|
  |
|
12-34931 - Washer, (.406 X .734 X .063 - Stainless Steel) [ More info ]
|
| #10 | FA321574 | DISTRIBUTOR BRACKET (1 required per assembly) |
  |
|
FA321574 - Bracket Kit,NLA [ More info ] Unavailable |
| #11 | F1759 | SHIM, DISTRIBUTOR (QTY. AS REQUIRED) (2 required per assembly) |
  |
|
15-F1759 - Shim, NLA [ More info ] Unavailable |
| #12 | F14042 | DISTRIBUTOR HOUSING W/BEARINGS (1 required per assembly) |
  |
|
F14042 - Housing ASY,USED [ More info ] Unavailable |
| #13 | F14036 | SWIVEL (2 required per assembly) |
  |
|
|
| #14 | F14037 | CAP CLIPS (2 required per assembly) |
  |
|
F14037 - Clip, NLA [ More info ]
|
| #15 | F14038 | CAP CLIP SCREWS (2 required per assembly) |
  |
|
F14038 - Screw, NLA [ More info ] Unavailable |
| #16 | F14045 | SCREW (2 required per assembly) |
  |
F14045 - Screw SS [ More info ] Unavailable |
|
  |
|
391-5087 - Screw, NLA [ More info ]
|
| #17 | 14048 2 | PREAMPLIFIER (1 required per assembly) |
| #18 | F8056 | LOCKWASHER (2 required per assembly) |
  |
|
13-F8056 - LockWasher [ More info ]
|
| #19 | F14046 | TERMINAL SCREW (2 required per assembly) |
  |
|
F14046 - Screw SS, NLA [ More info ] Unavailable |
| #20 | F14047 | TERMINAL INSULATOR (INSIDE) (2 required per assembly) |
  |
|
F14047 - Insulator, NLA [ More info ] Unavailable |
| #21 | F14015 | CAP CLIP RIVET (2 required per assembly) |
  |
|
F14015 - Rivet, NLA [ More info ] Unavailable |
| #22 | F14049 | TERMINAL INSULATOR (OUTSIDE) (1 required per assembly) |
  |
|
F14049 - Insulator, NLA [ More info ] Unavailable |
| #23 | F14041 | EXTERNAL TOOTH LOCKWASHER (2 required per assembly) |
  |
|
F14041 - LOCK WASHER,NLA [ More info ] Unavailable |
| #24 | F1647 | HEX NUT, 8 - 32 (2 required per assembly) |
  |
|
11-F1647 - Nut, (#8-32)(Stainless Steel) NLA [ More info ] Unavailable |
| #25 | F1760 | PAN HD SCREW, 10 - 24 X 3/8 (2 required per assembly) |
  |
|
10-F1760 - Screw -ss, NLA [ More info ]
|
| #26 | F1975 | SPRING LOCKWASHER (2 required per assembly) |
  |
13-F1975 - LockWasher - Priced Individually [ More info ] Unavailable |
|
  |
|
13-26996 - LockWasher - Priced Individually [ More info ]
|
| #27 | F213274 | GREASE FITTING (1 required per assembly) |
  |
|
22-F213274 - Grease Fitting [ More info ] Unavailable |
| #28 | F85664 | DISTRIBUTOR GROUND (1 required per assembly) |
  |
|
84-F85664 - Wire - Ground, NLA [ More info ]
|
| #29 | 84-817775A 1 | COIL WIRE W/TERMINAL CLIP (1 required per assembly) |
  |
|
84-817775A 1 - Wire Assembly, NLA [ More info ]
|
| #30 | F203276 | BOOT (1 required per assembly) |
  |
|
|
| #31 | F203673 | TERMINAL CLIP (1 required per assembly) |
  |
F203673 - 54F2036731 [ More info ] Unavailable |
|
  |
|
54-F203673-1 - Clip, NLA [ More info ]
|
| #32 | F321841-2 | LEAD WIRE (3 required per assembly) |
  |
F321841-2 - WIRE [ More info ] Unavailable |
|
  |
|
84-817774A 4 - Wire Assembly, NLA [ More info ] Unavailable |
| #33 | F14007 | CAP SCREW (2 required per assembly) |
  |
F14007 - Cap Screw [ More info ] Unavailable |
|
  |
|
F14059 - Screw, NLA [ More info ]
|
| #34 | F14011-1 | CAP COVER (1 required per assembly) |
  |
|
F14011-1 - Cap Cover [ More info ]
|
| #35 | F14040 | VENT (2 required per assembly) |
  |
|
F14040 - Vent, NLA [ More info ]
|
| #36 | F14020-1 | CAP SEAL (1 required per assembly) |
  |
|
F14020-1 - Cap Seal -3 Cylinder, NLA [ More info ]
|
| #37 | F14006-2 | CAP BASE (1 required per assembly) |
  |
|
F14006-2 - Distributor Cap - 3 Cyl [ More info ] Unavailable |
| #38 | F14030 | CAP GASKET (1 required per assembly) |
  |
|
F14030 - Cap Gasket [ More info ]
|
| #39 | F14012-1 | BRUSH (1 required per assembly) |
  |
|
F14012-1 - Brush Assembly, NLA [ More info ] Unavailable |
| #40 | F14043 | DISTRIBUTOR SHAFT (1 required per assembly) |
  |
|
F14043 - Distributor Shaft - 3 Cyl [ More info ] Unavailable |
| #41 | F1692 | WOODRUFF KEY (1 required per assembly) |
  |
|
28-F1692 - Key, NLA [ More info ]
|
| #42 | F14024 | SPACER (1 required per assembly) |
  |
|
F14024 - Spacer, NLA [ More info ] Unavailable |
| #44 | FK750-1 | SPARKIE W/SPRING (3 required per assembly) |
  |
FK750-1 - FK7502, NLA [ More info ] Unavailable |
|
  |
FK750-2 - FK1123, NLA [ More info ] Unavailable |
|
  |
FK1123 - Boot Kit [ More info ] Unavailable |
|
  |
|
85-63709A 1 - Boot Kit - Black - Priced Individually [ More info ]
|
| #46 | F14017 | TERMINAL INSULATOR (OUTSIDE) (1 required per assembly) |
  |
|
F14017 - Insulator, NLA [ More info ] Unavailable |
