Parts for Chrysler 7.5 HP (1982) Engine Cover & Support Plate

Revise Search: All Models > 7.5 HP (1982) > 71H2C ( ) > Engine Cover & Support Plate

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#	2C 609712	*ENGINE COVER COMPLETE. (1 required per assembly) INCLUDES ALL ITEMS MARKED WITH AN ASTERISK (), ORDER "SAILOR 180" SEPARATE**
#	FC525390	DECAL STOP - CANADA (1 required per assembly)
		FC525390 - DECAL,NLA [ More info ] Unavailable
#	FA539392	DECAL, SAILOR 180 PORT (1 required per assembly) W/LITERATURE
		FA539392 - DECAL,NLA [ More info ] Unavailable
#	F84991-1	GROMMET LIGHTING COIL WIRE (1 required per assembly)
		25-F84991-1 - Grommet, NLA [ More info ] $4.34 $3.68 10+ In Stock.
#	FC525394	DECAL CHOKE - CANADA (1 required per assembly)
		FC525394 - DECAL,NLA [ More info ] Unavailable
#	FA609397	DECAL "CHRYSLER" - PORT (1 required per assembly) W/LITERATURE
		FA609397 - DECAL NLA [ More info ] Unavailable
#1	FS537712	ENGINE COVER W/PACKING, REAR RETAINER AND LATCH BRACKET (1 required per assembly)
		FS537712 - COWL ASSY [ More info ] Unavailable
		100-FS537712T - COWL ASSY,NLA [ More info ] Unavailable
#2	F1475	FILL HD SCREW, 10 - 24 X 1/2 (7 required per assembly)
		10-F1475 - Screw -ss, NLA [ More info ] Unavailable
#3	817858A 1	RETAINER ENGINE COVER (2 required per assembly) W/ILLUS. 2 AND 4 ORIGINAL FORCE P/N A 525480-1
		817858A 1 - Retainer Kit,NLA [ More info ] Unavailable
#4	F7011	ELASTIC STOP NUT, 10 - 24 (7 required per assembly)
		11-F7011 - 11F7009 [ More info ] Unavailable
		11-F7009 - Nut, (#10-24) [ More info ] Unavailable
#5	FK525713	ENGINE COVER PACKING (1 required per assembly) W/LITERATURE
		FK525713 - Packing Kit, NLA [ More info ] $28.00 $23.72 4 In Stock.
#6	FA609396	DECAL "CHRYSLER" - STARBOARD (1 required per assembly) W/LITERATURE
		FA609396 - DECAL NLA [ More info ] Unavailable
#7	FA539391	DECAL, SAILOR 180 ST'BD (1 required per assembly) W/LITERATURE
		FA539391 - DECAL,NLA [ More info ] Unavailable
#8	A 487038	SUPPORT PLATE W/EYELET (1 required per assembly)
#9	F525615	ROD GEAR SHIFT UPPER (1 required per assembly)
		F525615 - ROD,NLA [ More info ] Unavailable
#10	F1950	HEX HD SCREW, 10 - 24 X 5/8 (1 required per assembly)
		10-F1950 - Screw -ss, NLA [ More info ] $2.71 $2.29 10+ In Stock.
#11	F178446	CLAMP LEAD WIRE (1 required per assembly)
		54-F178446 - CLAMP,NLA [ More info ] Unavailable
#12	F1734	SLOTTED FILL HD SCREW, 1/4 - 20 X 1/2 (1 required per assembly)
		F1734 - Screw w/ Lw, NLA [ More info ] Unavailable
		10-34939 - Screw w/ Lw, NLA [ More info ] $1.96 10+ In Stock.
#13	F1515	NUT, 5/16 - 18 (2 required per assembly)
		F1515 - Hex Hut, 5/16 - 18 [ More info ] $0.30 10+ In Stock.
		11-68292 - Nut (5/16 Inch) [ More info ] $1.50 10+ In Stock.
		11-8M0204668 - NUT @5 [ More info ] Unavailable
#14	F392777	CAM COVER LATCH (1 required per assembly)
		F392777 - Cam, NLA [ More info ] Unavailable
#15	F307818	BEARING (NYLINER) (2 required per assembly)
		23-F307818 - Bushing -nyLiner [ More info ] Unavailable
		23-26841 - Bushing - Priced Individually [ More info ] $7.59 10+ In Stock.
#16	F525840	GROMMET REMOTE THROTTLE CABLE (1 required per assembly)
		F525840 - Grommet, NLA [ More info ] Unavailable
#17	F525469	HANDLE LATCH (1 required per assembly)
		F525469 - HANDLE [ More info ] Unavailable
		817857A 1 - Handle Kit, NLA [ More info ] Unavailable
#18	F8547	SPRING PIN, 1/8 X 5/8 (1 required per assembly)
		F8547 - Spring Pin, 1/8 X 5/8, Stainless Steel [ More info ] $0.25 5 In Stock.
		17-25905 - Pin, Roll, NLA [ More info ] $7.81 10+ In Stock.
#19	F525763	SHAFT COVER LATCH (1 required per assembly)
		F525763 - Shaft, NLA [ More info ] $9.00 $7.62 5 In Stock.
#20	F73741-1	RING (1 required per assembly)
		53-F73741-1 - Ring, NLA [ More info ] $1.25 $1.06 1 In Stock.
#21	F197767-1	BUSHING FUEL LINE (1 required per assembly)
		21-F197767-1 - 22F1977672 [ More info ] Unavailable
		22-F197767-2 - Fuel Bushing [ More info ] $33.03 1 In Stock.
#22	F525390	DECAL STOP - U.S.A. (1 required per assembly)
		37-F525390 - DECAL,NLA [ More info ] Unavailable
#23	F521547	CHOKE KNOB (1 required per assembly)
		F521547 - Choke Knob, NLA [ More info ] $6.00 $5.08 10+ In Stock.
#24	F525394	DECAL CHOKE - U.S.A. (1 required per assembly)
		37-F525394 - Decal, NLA [ More info ] $5.00 $4.24 10+ In Stock.
#25	F487455	GUIDE STARTER ROPE (1 required per assembly)
		F487455 - GUIDE,NLA [ More info ] Unavailable
#26	F1513	HEX NUT (4 required per assembly)
		F1513 - Hex Nut 10 - 32 [ More info ] $0.86 10+ In Stock.
		11-68219 - Nut (#10-32) [ More info ] $2.99 10+ In Stock.
#27	F8058	INTERNAL TOOTH LOCKWASHER (4 required per assembly)
		13-F8058 - LockWasher, NLA [ More info ] $1.09 10+ In Stock.
#28	F525504	GROMMET, CHOKE ROD (1 required per assembly)
		25-F525504 - Grommet, NLA [ More info ] Unavailable
#29	F1975	LOCKWASHER, #10 (1 required per assembly)
		13-F1975 - LockWasher - Priced Individually [ More info ] Unavailable
		13-26996 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#30	F2041	HEX HD SCREW, 10 - 24 X 3/8 (1 required per assembly)
		10-F2041 - Screw -ss, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#31	F525925	LINK CHOKE KNOB (1 required per assembly)
		F525925 - LINK,NLA [ More info ] Unavailable
#32	F8567	SPRING PIN, 1/8 X 13/16 (1 required per assembly)
		17-F8567 - PIN,NLA [ More info ] $1.25 $1.06 1 In Stock.
#33	F525614	HANDLE GEAR SHIFT (1 required per assembly)
		F525614 - HANDLE,NLA [ More info ] Unavailable
#34	F8049	WASHER BOWED SPRING (1 required per assembly)
		13-F8049 - Bow Washer, NLA [ More info ] $1.73 $1.46 4 In Stock.
#35	F525871	SHAFT GEAR SHIFT LEVER (1 required per assembly)
		F525871 - SHAFT,NLA [ More info ] Unavailable
#36	F525263	LINK STARTER INTERLOCK (1 required per assembly)
		F525263 - Link, NLA [ More info ] Unavailable
#37	F1689	HEX HD SCREW, 1/4 - 20 X 1/2 (2 required per assembly)
		F1689 - Screw SS [ More info ] Unavailable
		10-73286 - Screw [ More info ] $1.80 Available to Order: Shipping delay up to 10 days.
#38	F318307	SEAL, DRIVESHAFT (1 required per assembly)
		26-F318307 - Seal [ More info ] $45.99 $30.80 10+ In Stock.
#39	F8538	SPRING PIN, 3/32 X 1/2 (1 required per assembly)
		17-F8538 - Spring Pin, NLA [ More info ] $0.22 $0.18 10+ In Stock.
#41	F525876	LEVER GEAR SHIFT (1 required per assembly)
		F525876 - Lever [ More info ] Unavailable
#42	F318818	BEARING, SHIFT LEVER SHAFT (2 required per assembly)
		F318818 - Bearing, NLA [ More info ] Unavailable
#43	F1573	FILL HD SCREW, 1/4 - 20 X 1/2 (4 required per assembly)
		F1573 - Screw, NLA [ More info ] Unavailable
#44	F525977	LEVER SHIFT INTERLOCK (1 required per assembly)
		F525977 - FS525977 FS525977, NLA [ More info ] Unavailable
		FS525977 - LEVER,NLA [ More info ] Unavailable
#45	FA525774	BRACKET COVER LATCH (1 required per assembly) W/ILLUS. 2 AND 4
		FA525774 - Bracket Kit,NLA [ More info ] Unavailable
#46	FA609892	DECAL ENGINE COVER FRONT (1 required per assembly) W/LITERATURE
		FA609892 - DECAL NLA [ More info ] Unavailable
#47	F609400	DECAL, SHIFT (ST'BD) (1 required per assembly)
		F609400 - DECAL,NLA [ More info ] Unavailable
