Parts for Chrysler 7.5 HP (1981) Motor Leg

Revise Search: All Models > 7.5 HP (1981) > 77HIC ( ) > Motor Leg

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#	37-F286585-2	DECAL, TILT RELEASE - CANADA (1 required per assembly)
		37-F286585-2 - DECAL-TILT,NLA [ More info ] Unavailable
#	F526244	WATERLINE (LONG LEG) (1 required per assembly)
		32-F526244 - Hose, NLA [ More info ] Unavailable
#1	F318342	SEAL, WATERLINE INLET UPPER (1 required per assembly)
		26-F318342 - Seal, NLA [ More info ] $6.60 $5.59 10+ In Stock.
#2	F525244	WATERLINE (STD. LEG) (1 required per assembly)
		32-F525244 - Hose, NLA [ More info ] Unavailable
#3	F525453	GASKET LEG MOUNTING (1 required per assembly)
		27-F525453 - Gasket [ More info ] Unavailable
#4	F525779	BAFFLE IDLE RELIEF (1 required per assembly)
		F525779 - BAFFLE,NLA [ More info ] Unavailable
#5	F525133	MOTOR LEG (1 required per assembly)
		1500-F525133 - LEG,NLA [ More info ] Unavailable
#6	F1532	HEX CAP SCREW, 1/4 - 20 X 1 (8 required per assembly)
		10-F1532 - Screw [ More info ] Unavailable
		10-819110100 - Screw [ More info ] $0.50 Available to Order: Shipping delay up to 10 days.
#7	1400-817964A 2	SWIVEL BRACKET (1 required per assembly) W/ILLUS. 10 AND 48 ORIGINAL FORCE P/N K 525072-2
		1400-817964A 2 - Swivel Bracket Kit,NLA [ More info ] Unavailable
#8	F286451	SPACER TILT LOCK (2 required per assembly)
		F286451 - Spacer - Tilt Lock [ More info ] Unavailable
		23-819226 - Spacer - Tilt Lock [ More info ] $3.22 10 In Stock.
#9	F286422-1	PIVOT TILT LOCK (2 required per assembly)
		10-F286422-1 - Screw -Special , NLA [ More info ] $19.39 10+ In Stock.
#10	F286169	BEARING SWIVEL BRACKET (2 required per assembly)
		23-F286169 - Bushing, NLA [ More info ] $5.85 10+ In Stock.
#11	F1805	SPRING PIN, 1/4 X 1-3/8 (1 required per assembly)
		17-F1805 - Spring, Pin [ More info ] Unavailable
		10-830112A 1 - Screw & Nut Kit, NLA [ More info ] $1.50 $1.28 10+ In Stock.
#12	F525346	MOUNT LOWER SHOCK (2 required per assembly)
		F525346 - MOUNT,NLA [ More info ] Unavailable
#13	F525707	COVER, SHOCK MOUNT LOWER (2 required per assembly)
		F525707 - Cover, NLA [ More info ] Unavailable
#14	F1972	HEX HD SCREW, 1/4 - 20 X 2 1/2 (2 required per assembly)
		10-F1972 - Screw -ss, NLA [ More info ] $2.03 10+ In Stock.
#15	F8540	SPRING PIN, 3/32 X 5/8 (1 required per assembly)
		17-F8540 - Roll Pin [ More info ] Unavailable
		17-38489 - Pin -roll [ More info ] $5.19 2 In Stock.
#16	F286461	SPRING LOCK BAR HANDLE (1 required per assembly)
		24-F286461 - Spring, Lock Bar Handle [ More info ] $9.69 10+ In Stock.
#17	F286114	HANDLE LOCK BAR (1 required per assembly)
		F286114 - Lock Bar Handle - Black [ More info ] $16.15 10+ In Stock.
#18	FA286113	BAR LOCK (1 required per assembly) W/ILLUS. 15, 16 AND 17
		FA286113 - FA617113 Tilt Pin [ More info ] Unavailable
		FA617113 -Lock Bar [ More info ] $24.99 10+ In Stock.
		851924A 2 - Tilt Pin Assembly [ More info ] $48.99 $41.49 10+ In Stock.
#19	F525019	KINGPIN (1 required per assembly)
		F525019 - KING PIN,NLA [ More info ] Unavailable
#20	F24074	FOOT CLAMP SCREW (2 required per assembly)
		F24074 - Foot- Clamp Screw, NLA [ More info ] $13.01 10+ In Stock.
#21	F8537	SPRING PIN (2 required per assembly)
		17-F8537 - Spring Pin, NLA [ More info ] $1.50 $1.28 10+ In Stock.
#22	F66480	STUD CLAMP SCREW (2 required per assembly)
		17-F66480 - Clampscrew Stud [ More info ] $4.95 $4.19 10 In Stock.
#23	F424075	HANDLE CLAMP SCREW (2 required per assembly)
		F424075 - HANDLE [ More info ] Unavailable
		F424075T - Handle -graph/Gray [ More info ] $8.80 10+ In Stock.
		F424075T3 - Handle - Steel/Gray [ More info ] $8.33 $7.05 10+ In Stock.
#24	F8554	SPRING PIN, 3/16 X 3/4 (2 required per assembly)
		F8554 - Pin -roll, NLA [ More info ] Unavailable
		17-24198 - Pin -roll, NLA [ More info ] $3.67 $3.11 8 In Stock.
#25	FS567532	BRACKET STERN PORT, W/SCREW CLAMP (1 required per assembly)
		FS567532 - Bracket Assembly -Stern, NLA [ More info ] Unavailable
#26	F286647	HANDLE CARRYING (1 required per assembly)
		F286647 - Carrying Handle [ More info ] $16.67 8 In Stock.
		832035T - Handle C [ More info ] $30.37 1 In Stock.
#28	F286037	BOLT STERN BRACKET (1 required per assembly)
		10-F286037 - Bolt, NLA [ More info ] Unavailable
#29	F8538	SPRING PIN, 3/32 X 1/2 (2 required per assembly)
		17-F8538 - Spring Pin, NLA [ More info ] $0.22 $0.18 10+ In Stock.
#30	F1666	WAVE WASHER (1 required per assembly)
		F1666 - Wave Washer - Priced Individually [ More info ] Unavailable
		13-69150 - Wave Washer - Priced Individually [ More info ] $3.79 10+ In Stock.
#31	F429541	LOCK TILT (1 required per assembly)
		F429541 - Tilt Lock [ More info ] $60.99 $58.16 1 In Stock.
#32	F286544-1	SPRING TILT LOCK (1 required per assembly)
		24-F286544-1 - Spring, Tilt Lock,NLA [ More info ] $3.10 10+ In Stock.
#33	F2014	PLAIN WASHER (1 required per assembly)
		F2014 - Washer [ More info ] $0.49 3 In Stock.
		12-34931 - Washer, (.406 X .734 X .063 - Stainless Steel) [ More info ] $2.59 10+ In Stock.
#34	F7026	NUT, 3/8 - 16 (1 required per assembly)
		11-F7026 - Nut (3/8- 16)NLA [ More info ] Unavailable
#35	F1341	NUT, 1/4 - 20 (2 required per assembly)
		F1341 - Hex Nut 1/4 - 20 [ More info ] Unavailable
		11-64015 - Nut (1 /4-20) [ More info ] $2.79 10+ In Stock.
#36	F8083	LOCKWASHER (2 required per assembly)
		F8083 - LockWasher SS [ More info ] Unavailable
		13-26992 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#37	F286349	LOCK REVERSE (1 required per assembly)
		F286349 - LOCK-REVERSE [ More info ] $14.05 2 In Stock.
		850259A 1 - Lock & Link Kit, NLA [ More info ] Unavailable
#38	FA341510	LINK REVERSE LOCK LEVER (1 required per assembly) W/LITERATURE
		FA341510 - Reverse Lock Lever Link [ More info ] $8.98 4 In Stock.
#39	F1794	SPRING PIN, 3/32 X 3/8 (2 required per assembly)
		17-F1794 - Spring, Pin, NLA [ More info ] $1.82 $1.54 10+ In Stock.
#40	F286364	LEVER REVERSE LOCK (1 required per assembly)
		F286364 - Reverse Lock Lever [ More info ] $4.44 10+ In Stock.
		F286364T - Reverse Lock Lever [ More info ] Unavailable
#41	F525286	WASHER (1 required per assembly)
		12-F525286 - 12F2037 [ More info ] Unavailable
		12-F2037 - Washer [ More info ] $1.70 $1.45 1 In Stock.
#42	F286827	LEVER REVERSE LOCK RELEASE (1 required per assembly)
		F286827 - Reverse Lock Release Lever [ More info ] $7.25 $6.14 10+ In Stock.
#43	F286585-1	DECAL, TILT RELEASE - USA (1 required per assembly)
		F286585-1 - 37F2865852 / ORD [ More info ] Unavailable
#44	F197813	BEARING (1 required per assembly)
		23-F197813 - Bushing -nyLiner [ More info ] Unavailable
		23-26856 - Bushing [ More info ] $4.19 Available to Order: Shipping delay up to 10 days.
#45	F1806	GROOVE PIN, 5/16 - 3 3/4 (1 required per assembly)
		17-F1806 - Pin, Groove, NLA [ More info ] Unavailable
#46	F286433	BRACKET SHALLOW WATER DRIVE (1 required per assembly)
		F286433 - Bracket [ More info ] Unavailable
		830111 - Bracket, NLA [ More info ] Unavailable
		830111 1 - Bracket, NLA [ More info ] $58.99 $49.96 4 In Stock.
#47	F286300	SPRING REVERSE LOCK (1 required per assembly)
		24-F286300 - Spring, Reverse Lock,NLA [ More info ] $6.80 $5.76 10+ In Stock.
#48	F213274	FITTING GREASE (2 required per assembly)
		22-F213274 - Grease Fitting [ More info ] Unavailable
#49	F1467	SCREW SWIVEL BRACKET (1 required per assembly)
		10-F1467 - Set Screw, NLA [ More info ] $1.25 $1.06 10 In Stock.
#50	F286011	WASHER SWIVEL BRACKET (1 required per assembly)
		12-F286011 - Washer, Swivel Bracket [ More info ] $2.05 5 In Stock.
#51	F525839	SCREW, STEERING FRICTION (1 required per assembly)
		10-F525839 - SCREW,NLA [ More info ] Unavailable
#52	F536813	BEARING (1 required per assembly)
		23-F536813 - Bushing [ More info ] Unavailable
#53	FA387742	LEVER REVERSE LOCK INTERMEDIATE (1 required per assembly)
		FA387742 - LEVER ASSY [ More info ] Unavailable
		820095A 1 - LEVER ASSY [ More info ] Unavailable
		820095A 2 - Lever Assembly [ More info ] $20.50 $19.68 1 In Stock.
#54	F286286-1	WASHER (1 required per assembly)
		12-F286286-1 - Washer -Stern Bracket, NLA [ More info ] $2.21 $1.88 10+ In Stock.
#55	817761A 2	SCREW CLAMP (2 required per assembly) W/ILLUS. 20, 21 AND 22 ORIGINAL FORCE P/N A 298073-2
		817761A 2 - Screw Kit -Stern [ More info ] Unavailable
		10-826248A 1 - Screw Kit -Stern, NLA [ More info ] $43.10 10+ In Stock.
