Parts for Chrysler 75 HP (1977) Starter
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| # | FS438955 | STARTER COMPLETE (1 required per assembly) |
  |
FS438955 - FK616955, NLA [ More info ] Unavailable |
|
  |
|
FK616955 - Starter Kit [ More info ] Unavailable |
  |
|
18-5613 - Starter, 50-819085 [ More info ]
|
  |
|
5393 - Outboard Starter [ More info ]
|
| #1 | F15111 | NUT, STOP RETAINING (1 required per assembly) |
  |
F15111 - 11F7001 [ More info ] Unavailable |
|
  |
|
11-F7001 - Nut, NLA [ More info ]
|
| #2 | F15112 | STOP, PINION (1 required per assembly) |
  |
|
F15112 - Starter Part, NLA [ More info ] Unavailable |
| #3 | F15080 | SPRING (1 required per assembly) |
  |
|
F15080 - Spring, NLA [ More info ]
|
| #4 | F15110 | CLUTCH ASSEMBLY (1 required per assembly) |
  |
F15110 - Starter Drive [ More info ] Unavailable |
|
  |
|
F15100 - Starter Drive, NLA [ More info ]
|
| #5 | F15021-1 | HEAD ASSEMBLY DRIVE END (1 required per assembly) |
  |
|
F15021-1 - Head Assembly, NLA [ More info ]
|
| #6 | F1514 | HEX NUT, 1/4 - 20 (2 required per assembly) |
  |
F1514 - Hex Nut, 1/4 - 20 [ More info ] Unavailable |
|
  |
F1341 - Hex Nut 1/4 - 20 [ More info ] Unavailable |
|
  |
|
11-64015 - Nut (1 /4-20) [ More info ]
|
| #7 | F8028 | PLAIN WASHER (2 required per assembly) |
  |
F8028 - 12F8008 [ More info ] Unavailable |
|
  |
12-F8008 - Washer [ More info ] Unavailable |
|
  |
|
12-35044 - Washer, (.281 X .625 X .065) Stainless Steel [ More info ]
|
| #8 | F15073 | THRUST WASHER PACKAGE (1 required per assembly) |
  |
|
F15073 - Starter Part, NLA [ More info ]
|
| #9 | F15099 | ARMATURE (1 required per assembly) |
  |
|
F15099 - Armature, NLA [ More info ] Unavailable |
| #10 | F15101 | FRAME AND FIELD ASSEMBLY (1 required per assembly) |
  |
|
F15101 - Starter Part, NLA [ More info ] Unavailable |
| #11 | F15042 | BRUSH TERMINAL SET (1 required per assembly) |
  |
F15042 - Brush Set [ More info ] Unavailable |
|
  |
|
392-4866 - Brush Assembly, NLA [ More info ] Unavailable |
| #12 | FA15072 | HEX LOCK NUT, 1/4 - 20 (1 required per assembly) |
  |
|
FA15072 - FA15072 - NUT [ More info ] Unavailable Replaced by -F15162 |
  |
|
F15162 - Nut (1/4-20) NLA [ More info ]
|
| #13 | F15035 | THRU BOLT PACKAGE (1 required per assembly) |
  |
|
F15035 - Starter Part, NLA [ More info ]
|
| #14 | F8060 | LOCKWASHER (2 required per assembly) |
  |
|
13-F8060 - LockWasher, NLA [ More info ]
|
| #15 | F1502 | HEX HD SCREW, 1/4 - 20 X 5/8 (1 required per assembly) |
  |
|
|
  |
|
10-98254 - Screw [ More info ]
|
| #16 | F1868 | HEX CAP SCREW, 3/8 - 16 X 3 1/4 (1 required per assembly) |
  |
F1868 - 10F1874 [ More info ] Unavailable |
|
  |
|
10-F1874 - Screw, NLA [ More info ] Unavailable |
| #17 | F373675-1 | STARTER BRACKET, LOWER (1 required per assembly) |
  |
|
F373675-1 - BRACKET NLA [ More info ] Unavailable |
| #18 | 15037 | HEAD ASSEMBLY, COMMUTATOR END (1 required per assembly) |
| #19 | F15034 | SPRING SET (1 required per assembly) |
  |
F15034 - Spring Set [ More info ] Unavailable |
|
  |
|
392-2514 - Spring Set (2 Springs Per Set)NLA [ More info ]
|
| #20 | F15038-1 | BRUSH PLATE AND HOLDER (1 required per assembly) |
  |
F15038-1 - Plate [ More info ] Unavailable |
|
  |
|
392-4864 - Holder, NLA [ More info ]
|
| #21 | F85908 | STARTER LEAD WIRE (1 required per assembly) |
  |
F85908 - 84F859081 [ More info ] Unavailable |
|
  |
|
84-F85908-1 - Wire Assembly, NLA [ More info ]
|
| #22 | F404446 | CLAMP (1 required per assembly) |
  |
|
54-F404446 - CLAMP,NLA [ More info ] Unavailable |
| #23 | F15100 | BENDIX (1 required per assembly) |
