Parts for Chrysler 75 HP (1977) Power Head

Revise Search: All Models > 75 HP (1977) > 756HC ( ) > Power Head

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#	FG460-1	GASKET SET (NOT SHOWN) (1 required per assembly)
		FG460-1 - 27FG4602 [ More info ] Unavailable
		27-FG460-2 - Gasket Set [ More info ] Unavailable
		27-809747A 1 - Gasket Set [ More info ] Unavailable
#	800-817901A 9	*SHORT BLOCK (1 required per assembly) INCLUDES ALL ITEMS MARKED WITH AN ASTERISK (). ALSO REFER TO CRANKSHAFT PAGE. ORIGINAL FORCE P/N C481010-3**
		800-817901A 9 - Powerhead KIT,NLA [ More info ] Unavailable
#	C438010 3	*SHORT BLOCK (1 required per assembly) INCLUDES ALL ITEMS MARKED WITH AN ASTERISK (). ALSO REFER TO CRANKSHAFT PAGE.**
#	C523227	SPARK PLUG (CHAMPION QL-76V) (3 required per assembly) FOR MODELS 756BC, 757BC, 906BC, 907BC
#1	FA480894	TIMING POINTER (1 required per assembly)
		FA480894 - Pointer Kit - Timing, NLA [ More info ] $2.70 2 In Stock.
#2	F1760	PAN HD SCREW, 10 - 24 X 3/8 (2 required per assembly)
		10-F1760 - Screw -ss, NLA [ More info ] $1.50 $1.28 10+ In Stock.
#3	F84991-1	GROMMET (3 required per assembly)
		25-F84991-1 - Grommet, NLA [ More info ] $4.34 $3.68 10+ In Stock.
#5	F2042	PLAIN WASHER (1 required per assembly)
		F2042 - Washer - Priced Individually [ More info ] Unavailable
		12-89302 - Washer (.203 X .406 X .040) [ More info ] $1.80 10+ In Stock.
#6	F1203	HEX BOLT, 1/4 - 20 X 7/8 (14 required per assembly)
		F1203 - Screw - Priced Individually [ More info ] Unavailable
		10-28668 - Screw - Priced Individually [ More info ] $1.70 1 In Stock.
#7	F1513	HEX NUT, 10 - 32 (4 required per assembly)
		F1513 - Hex Nut 10 - 32 [ More info ] $0.86 10+ In Stock.
		11-68219 - Nut (#10-32) [ More info ] $2.99 10+ In Stock.
#8	F85502	THROTTLE LINK (1 required per assembly)
		F85502 - Throttle Link [ More info ] Unavailable
		819002 - Throttle Link [ More info ] $47.42 10+ In Stock.
#9	817747 1	BALL JOINT W/STUD (1 required per assembly)
		817747 1 - Ball Joint Assembly [ More info ] Unavailable
		828514A 1 - Ball and Socket [ More info ] $22.61 10+ In Stock.
#10	FA85838-5	TOWERSHAFT W/BEARINGS, SWIVEL, ARMS AND SCREW (1 required per assembly)
		FA85838-5 - FA85838-5 - TOWERSHAFT ASSY [ More info ] Unavailable Replaced by -FK85838-6
		FK85838-6 - TowerShaft Kit, NLA [ More info ] $55.00 $46.58 3 In Stock.
#11	F1475	FILL HD SCREW, 10 - 24 X 1/2 (4 required per assembly)
		10-F1475 - Screw -ss, NLA [ More info ] Unavailable
#12	F1504	FILL HD SCREW, 1/4 - 20 X 1 1/4 (1 required per assembly)
		10-F1504 - Screw -ss [ More info ] $2.79 Available to Order: Shipping delay up to 10 days.
#13	F1341	HEX NUT, 1/4 - 20 (1 required per assembly)
		F1341 - Hex Nut 1/4 - 20 [ More info ] Unavailable
		11-64015 - Nut (1 /4-20) [ More info ] $2.79 10+ In Stock.
#14	F1556	FILL HD SCREW W/LOCKWASHER, 10 - 24 X 3/8 (2 required per assembly)
		F1556 - 10F2217 [ More info ] Unavailable
		10-F2217 - Screw [ More info ] $0.72 3 In Stock.
		10-F2217-1 - 10-F2217-1 - SCREW (10-24 x .3 [ More info ] Unavailable Replaced by 10-F2217-1
#15	FK405020	SWIVEL W/PIVOT SCREW AND NUT (2 required per assembly)
		FK405020 - Swivel Kit, NLA [ More info ] $26.95 10+ In Stock.
#16	F1727	PLASTIC RIVET (1 required per assembly)
		17-F1727 - Rivet, NLA [ More info ] $1.79 10 In Stock.
#17	F85036	TOWERSHAFT CONTROL ROD END (1 required per assembly)
		F85036 - F4990361 [ More info ] Unavailable
		F499036-1 - End, Control Rod, .250-28 LH [ More info ] $17.89 10+ In Stock.
#18	F85445	DISTRIBUTOR CONTROL ROD (1 required per assembly)
		F85445 - F854451 [ More info ] Unavailable
		F85445-1 - Spark Control Rod [ More info ] $49.99 Available to Order: Shipping delay up to 10 days.
#19	F2015	HEX NUT, 1/4 - 28 (1 required per assembly)
		11-F2015 - Nut, (.250-28) Stainless Steel [ More info ] $2.39 10+ In Stock.
#20	F85035	DISTRIBUTOR CONTROL ROD END (1 required per assembly)
		F85035 - End, Control Rod [ More info ] Unavailable
		F499035 - Control Rod End Timing Ring [ More info ] $13.09 7 In Stock.
#21	F85026	SWIVEL (1 required per assembly)
		F85026 - Swivel -.88, NLA [ More info ] $22.22 $18.82 10+ In Stock.
#22	F84314-2	ELBOW (1 required per assembly)
		22-F84314-2 - Elbow, NLA [ More info ] Unavailable
#23	F85859	STUD, FORWARD (4 required per assembly)
		16-F85859 - Stud, NLA [ More info ] Unavailable
#24	F7004	STOP NUT, 3/18 - 16 (10 required per assembly)
		11-F7004 - Nut, (.375-16) [ More info ] $0.49 7 In Stock.
		11-28010 - Nut - Priced Individually [ More info ] Unavailable
		11-68411 - Nut (3/8-16) [ More info ] $6.66 10+ In Stock.
		11-826709 12 - Nut, (.375-16) Stainless Steel [ More info ] $6.79 $3.81 10+ In Stock.
#25	F85748-2	GASKET, CYLINDER DRAIN REED PLATE (1 required per assembly)
		27-F85748-2 - Cylinder Drain Reed Plate Gasket [ More info ] $7.49 10+ In Stock.
#26	F93811	SCREEN (3 required per assembly)
		35-F93811 - Screen, NLA [ More info ] $2.29 10+ In Stock.
#27	F2A404757	CYLNDR DRAIN REED PLATE W/REEDS,STOPS, METERING CUP & SCREWS (1 required per assembly)
		F2A404757 - Drain Plate, NLA [ More info ] Unavailable
#28	F18160-1	REED (3 required per assembly)
		F18160-1 - F181602 [ More info ] Unavailable
		F18160-2 - 34F181603 [ More info ] Unavailable
		34-F18160-3 - Reed [ More info ] $10.19 6 In Stock.
#29	F93920	REED STOP (3 required per assembly)
		F93920 - Reed Stop, NLA [ More info ] $2.37 10+ In Stock.
#30	F8003	PLAIN WASHER (3 required per assembly)
		F8003 - Washer [ More info ] Unavailable
		12-18552 - Washer [ More info ] Unavailable
#31	F1286	PAN HD SCREW, 4 - 40 X 3/16 (3 required per assembly)
		10-F1286 - Screw, NLA [ More info ] $2.59 10+ In Stock.
#32	F85472-2	GASKET, CYLINDER DRAIN COVER (1 required per assembly)
		27-F85472-2 - Cylinder Drain Cover Gasket [ More info ] $7.59 10+ In Stock.
#33	817787A 1	CYLINDER DRAIN COVER (1 required per assembly)
		817787A 1 - Drain Cover Kit [ More info ] Unavailable
#35	F1187	HEX HD SCREW, 1/4 - 20 X 1 (6 required per assembly)
		F1187 - 10F1532 [ More info ] Unavailable
		10-F1532 - Screw [ More info ] Unavailable
		10-819110100 - Screw [ More info ] $0.50 Available to Order: Shipping delay up to 10 days.
#36	F404801	FITTING (1 required per assembly)
		22-F404801 - Fitting, NLA [ More info ] $7.02 10+ In Stock.
#37	F433253	HOSE (1 required per assembly)
		F433253 - 32F691796 [ More info ] Unavailable
		32-F691796 - Hose [ More info ] Unavailable
		32-819029 62 - Hose -22.5 Inch, NLA [ More info ] Unavailable
#39	F1502	HEX HD SCREW, 1/4 - 20 X 5/8 (8 required per assembly)
		F1502 - Screw [ More info ] $0.30 9 In Stock.
		10-98254 - Screw [ More info ] $0.60 Available to Order: Shipping delay up to 10 days.
#40	FA411222	TRANSFER PORT COVER W/PLUG (2 required per assembly)
		FA411222 - Transfer Port Cover [ More info ] Unavailable
		817790A 1 - Cover Kit [ More info ] Unavailable
#41	F40223	GASKET, TRANSFER PORT COVER (3 required per assembly)
		27-F40223 - Transfer Port Cover Gasket [ More info ] Unavailable
		27-820500 - Transfer Port Gasket [ More info ] Unavailable
		27-820500A 3 - Gasket Kit [ More info ] $17.67 5 In Stock.
		18-0869-9 - Gasket 27-F40223 2-Pack [ More info ] $19.99 $19.30 Available to Order: Shipping delay up to 10 days.
#42	F1999	HEX CAP SCREW, 1/4 - 20 X 7/8 (2 required per assembly)
		10-F1999 - Screw -ss [ More info ] $1.10 10 In Stock.
#43	F1238	HEX HD SCREW, 1/4 - 20 X 3/4 (10 required per assembly)
		F1238 - Screw - Priced Individually [ More info ] Unavailable
		10-49668 - Screw - Priced Individually [ More info ] $1.10 $0.88 5 In Stock.
#44	F1199	HEX CAP SCREW, 1/4 - 20 X 1 (1 required per assembly)
		F1199 - Screw SS [ More info ] Unavailable
		10-14168 - Screw [ More info ] $1.39 $1.17 10+ In Stock.
#46	F85211	STUD, REAR (6 required per assembly)
		F85211 - 16F6932111 [ More info ] Unavailable
		16-F693211-1 - STUD [ More info ] Unavailable
		16-826391 - Stud, NLA [ More info ] $6.00 $5.08 10+ In Stock.
#47	F476066-1	COVER, THERMOSTAT (1 required per assembly)
		F476066-1 - Thermostat Cover [ More info ] Unavailable
		819693 - Thermostat Cover [ More info ] Unavailable
#48	F8058	INTERNAL TOOTH LOCKWASHER (4 required per assembly)
		13-F8058 - LockWasher, NLA [ More info ] $1.09 10+ In Stock.
#49	F321872	BRACKET (1 required per assembly)
		F321872 - F321872 - BRACKET [ More info ] Unavailable Replaced by -F85872-2
		F85872-2 - Bracket, NLA [ More info ] Unavailable
#50	F98273	ROD END CONNECTOR STUD (2 required per assembly)
		16-F98273 - Stud, NLA [ More info ] $19.92 $16.88 10 In Stock.
#51	F85279-2	CYLINDER EXHAUST GASKET, UPPER (1 required per assembly)
		F85279-2 - Cylinder Exhaust Gasket [ More info ] Unavailable
		27-819381 - Spacer Plate Gasket [ More info ] $23.47 8 In Stock.
#52	F369887	SHOULDER SCREW (1 required per assembly)
		10-F369887 - Screw, NLA [ More info ] $4.31 7 In Stock.
#53	F369610	BEARING (1 required per assembly)
		23-F369610 - Bushing, NLA [ More info ] $2.39 6 In Stock.
#54	F369977-1	INTERLOCK ARM (1 required per assembly)
		F369977-1 - Interlock Arm [ More info ] Unavailable
		819932 1 - Arm - Interlock [ More info ] $60.99 Available to Order: Shipping delay up to 10 days.
#55	F1885	HEX BOLT, 5/16 - 18 X 4 1/4 (1 required per assembly)
		10-F1885 - Screw -ss, NLA [ More info ] $2.50 $2.13 10+ In Stock.
#56	F85610	BEARING (2 required per assembly)
		23-F85610 - Bushing [ More info ] $0.35 10+ In Stock.
		23-97896 - Bushing [ More info ] $4.49 10+ In Stock.
#57	FA480876	GEAR SHIFT ARM W/SWIVEL, INTERLOCK ARM AND BEARINGS (1 required per assembly)
		FA480876 - Shift Arm Kit [ More info ] Unavailable
#58	F2108	STOP NUT, 5/16 - 18 (1 required per assembly)
		11-F2108 - Nut (5/16-18) NLA [ More info ] $1.38 $1.17 10+ In Stock.
#59	F1832	STOP NUT, 1/4 - 20 (1 required per assembly)
		11-F1832 - Nut (1 /4-20)(Stainless Steel) [ More info ] Unavailable
		11-814101 - Nut (1/4-20) [ More info ] Unavailable
		118M0207776 - NUT [ More info ] $7.09 Available to Order: Shipping delay up to 10 days.
#60	FA98689	BEARING, TOWERSHAFT (1 required per assembly)
		FA98689 - FA98689 - BEARING [ More info ] Unavailable Replaced by 23-F40689-1
		23-F40689-1 - Bearing - Towershaft Lower [ More info ] $2.59 10+ In Stock.
#61	F1869	HEX BOLT, 3/8 - 16 X 1 1/4 (6 required per assembly)
		F1869 - Screw - Priced Individually [ More info ] Unavailable
		10-37612 - Screw - Priced Individually [ More info ] $2.49 3 In Stock.
#62	F1703	SPRING LOCKWASHER (7 required per assembly)
		F1703 - LockWasher - Priced Individually [ More info ] $0.30 3 In Stock.
		13-35048 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#63	817788A 3	SPACER PLATE W/PLUGS (1 required per assembly)
		817788A 3 - PLATE KIT-SPACER,NLA [ More info ] Unavailable
#64	F2090	PLUG (1 required per assembly)
		22-F2090 - Plug, NLA [ More info ] $4.31 1 In Stock.
#65	33-97180	SPARK PLUG (CHAMPION L-20-V) (3 required per assembly)
		33-97180 - NGK BUHW Note: Priced Individually [ More info ] Unavailable
		33-97180Q - NGK Spark Plug Buhw - Priced Individually [ More info ] Unavailable
		33-896329827 - Spark Plug - L76V - Priced Individually [ More info ] Unavailable
		BUH - NGK Spark Plug, 2422 [ More info ] $8.14 10+ In Stock.
		L76V - Champion Spark Plug ( #827M) [ More info ] $15.33 10+ In Stock.
#66	F1987	PLAIN WASHER (14 required per assembly)
		F1987 - Washer - Priced Individually [ More info ] $0.25 10+ In Stock.
		12-34437 - Washer (5/16 In. I.d.) [ More info ] $2.89 Available to Order: Shipping delay up to 10 days.
#67	F1883	HEX BOLT, 5/16 - 18 X 2 3/8 (14 required per assembly)
		10-F1883 - Screw [ More info ] $7.59 Available to Order: Shipping delay up to 10 days.
#68	F499995	CYLINDER HEAD COVER (1 required per assembly)
		1000-F499995 - Cylinder Head Cover, NLA [ More info ] $30.18 5 In Stock.
#70	F335068	THERMOSTAT (1 required per assembly)
		F335068 - Thermostat, 143 Degrees [ More info ] Unavailable
		47594 - Thermostat, 143 Degree, Seal Not Included [ More info ] $40.99 Available to Order: Shipping delay up to 10 days.
		18-3557 - Thermostat, 143 Degrees, Seal Not Included, 396987, 47594 [ More info ] $36.71 3 In Stock.
		75-00422-BR - Thermostat, 143 Degree, Seal Not Included [ More info ] $28.07 2 In Stock.
		75-00422 - Thermostat, 143 Deg, 396987 [ More info ] $33.99 $29.36 In Stock
#71	F84504	GROMMET (1 required per assembly)
		25-F84504 - Thermostat Grommet [ More info ] $11.09 3 In Stock.
#72	F480518	CYLINDER HEAD (1 required per assembly)
		F480518 - Cylinder Head [ More info ] Unavailable
		900-F630518-1 - Cylinder Head [ More info ] $149.99 1 In Stock.
		900-803933T - Cylinder Head [ More info ] $360.49 Available to Order: Shipping delay up to 10 days.
#73	F19109	PLUG (1 required per assembly)
		F19109 - Plug - (1/8-27 NPT) [ More info ] Unavailable
		22-47945 - Pipe Plug [ More info ] Unavailable
#74	F369529	CYLINDER HEAD GASKET (1 required per assembly)
		F369529 - F3695291 [ More info ] Unavailable
		F369529-1 - F3695292 [ More info ] Unavailable
		F369529-2 - 27F3695293 [ More info ] Unavailable
		27-F369529-3 - Gasket [ More info ] Unavailable
		27-820438 - Cylinder Head Gasket [ More info ] $83.49 Available to Order: Shipping delay up to 10 days.
		18-3855 - Head Gasket, 27-820438 [ More info ] $52.99 $51.64 2 In Stock.
#75	F438398	DECAL, WIRING (1 required per assembly)
		F438398 - 37F4383981 [ More info ] Unavailable
		37-F438398-1 - Decal -Wiring, NLA [ More info ] Unavailable
#76	F1709	HEX HD SCREW, 1/4 - 20 X 1 1/8 (5 required per assembly)
		F1709 - Screw - Priced Individually [ More info ] Unavailable
		10-76213 - Screw - Priced Individually [ More info ] $1.80 $0.37 2 In Stock.
#77	F1849	HEX HD SCREW, 1/4 - 20 X 1 3/8 (1 required per assembly)
		10-F1849 - Screw -ss [ More info ] $0.90 $0.18 9 In Stock.
#78	F85152-4	EXHAUST PORT COVER (1 required per assembly)
		F85152-4 - Exhaust Cover, NLA [ More info ] Unavailable
#79	F85154-1	GASKET, EXHAUST PORT PLATE (2 required per assembly)
		27-F85154-1 - 27-F85154-1 - GASKET [ More info ] Unavailable Replaced by 27-F85154-1
#80	F85151-1	EXHAUST PORT PLATE (1 required per assembly)
		F85151-1 - Exhaust Plate, NLA [ More info ] $79.99 $67.74 1 In Stock.
#81	F1950	HEX HD SCREW, 10 - 24 X 5/8 (2 required per assembly)
		10-F1950 - Screw -ss, NLA [ More info ] $2.71 $2.29 10+ In Stock.
#82	F438066	BY-PASS VALVE COVER (1 required per assembly)
		F438066 - Cover, NLA [ More info ] Unavailable
#83	F85762	GASKET, BY-PASS VALVE (1 required per assembly)
		27-F85762 - By Pass Valve Gasket [ More info ] $1.90 10+ In Stock.
#84	F404268	SPRING, BY-PASS VALVE (1 required per assembly)
		24-F404268 - Spring, By Pass Valve [ More info ] $12.99 $11.00 10+ In Stock.
#85	F85916-1	BY-PASS VALVE (1 required per assembly)
		20-F85916-1 - Valve [ More info ] $20.52 $17.39 10+ In Stock.
#86	F1647	HEX NUT, 10 - 32 (1 required per assembly)
		11-F1647 - Nut, (#8-32)(Stainless Steel) NLA [ More info ] Unavailable
#87	F8056	SPRING LOCKWASHER (1 required per assembly)
		13-F8056 - LockWasher [ More info ] $0.98 $0.83 10+ In Stock.
#88	F404449	THERMOSWITCH (1 required per assembly)
		87-F404449 - ThermoSwitch [ More info ] $87.99 $74.52 6 In Stock.
#90	F1864	HEX HD SCREW, 1/4 - 20 X 3/4 (1 required per assembly)
		10-F1864 - Screw SS [ More info ] Unavailable
		10-28636 - Screw - Priced Individually [ More info ] $1.80 10+ In Stock.
#91	F85210	STUD (1 required per assembly)
		16-F85210 - STUD [ More info ] Unavailable
		16-826394 - STUD [ More info ] Unavailable
		16-826394 1 - STUD [ More info ] Unavailable
		16-826394 2 - Stud [ More info ] $10.00 $8.47 10+ In Stock.
#92	F8563	DOWEL PIN (2 required per assembly)
		17-F8563 - Pin -Dowel, NLA [ More info ] Unavailable
		17-20433 - Pin -Dowel, NLA [ More info ] $1.50 $1.28 10 In Stock.
#93	F85122	PARTING LINE SEAL (1 required per assembly)
		F85122 - F1841221 [ More info ] Unavailable
		F184122-1 - Seal - Red, 40 Inches, NLA [ More info ] $19.90 $13.54 10 In Stock.
#94	F476067	GASKET, THERMOSTAT COVER (1 required per assembly)
		27-F476067 - Thermostat Cover Gasket [ More info ] Unavailable
		27-828319 - Thermostat Cover Gasket [ More info ] $4.49 6 In Stock.
		18-0854-9 - Gasket 27-828319 2-Pack [ More info ] $8.99 $8.01 Available to Order: Shipping delay up to 10 days.
#95	F1346	HEX NUT, 3/8 - 16 (1 required per assembly)
		11-F1346 - Hex Nut, 3/8 - 16 [ More info ] $0.44 2 In Stock.
		11-86226 - Nut (3/8-16) [ More info ] $2.21 10 In Stock.
		11-8M0204671 - NUT [ More info ] Unavailable
#96	F1873	HEX BOLT, 3/8 - 16 X 3 (3 required per assembly)
		10-F1873 - Screw [ More info ] Unavailable
		10-53734 - Screw [ More info ] $0.50 $0.43 10+ In Stock.
#97	F1009	HEX BOLT, 3/8 - 16 X 2 3/4 (1 required per assembly)
		10-F1009 - Screw [ More info ] $0.69 5 In Stock.
		10-47688 - Screw [ More info ] $3.59 Available to Order: Shipping delay up to 10 days.
#98	F1107	FILL HD SCREW, 1/4 - 20 X 3/4 (4 required per assembly)
		10-F1107 - Screw [ More info ] $0.70 $0.60 10+ In Stock.
#99	F1872	HEX BOLT, 3/8 - 16 X 1 3/4 (2 required per assembly)
		10-F1872 - Screw [ More info ] Unavailable
		10-32132 - Screw [ More info ] $2.99 4 In Stock.
#100	F1099	FILL HD SCREW, 1/4 - 20 X 1 1/4 (2 required per assembly)
		F1099 - 10F1504 [ More info ] Unavailable
#101	F2089	SLOTTED PAN HD MACHINE SCREW, 10 - 24 X 5/16 (2 required per assembly)
		10-F2089 - Screw -ss, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#102	F480107-1	CAM, STARTER INTERLOCK (1 required per assembly)
		F480107-1 - F4801072 [ More info ] Unavailable
		F480107-2 - Cam -interlock, NLA [ More info ] $7.61 $6.45 10+ In Stock.
#89	A438010 3	CYLINDER ASSEMBLY (1 required per assembly) W/PARTING LINE SEAL AND LOWER MAIN BEARING ASSEMBLY
#89	800-817823A 7	CYLINDER ASSEMBLY (1 required per assembly) W/PARTING LINE SEAL AND LOWER MAIN BEARING ASSEMBLY ORIGINAL FORCE P/N A481010-3
		800-817823A 7 - Cylinder Kit [ More info ] Unavailable
		800-817823A 9 - Cylinder Kit, NLA [ More info ] Unavailable
