Parts for Chrysler 45 HP (1975) Engine Cover & Support Plate

Revise Search: All Models > 45 HP (1975) > 468BA ( ) > Engine Cover & Support Plate

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#	475892	DECAL, TOP TRIM FOR MODELS 464HB AND 468HB (NOT SHOWN) (1 required per assembly)
#	475893	DECAL, ACCENT LINE FOR MODELS 464HB AND 468HB (NOT SHOWN) (1 required per assembly)
#	478385	DECAL, 691 C. C. FOR MODELS 464HB AND 468HB (NOT SHOWN) (1 required per assembly)
#	F191993-1	BRACKET, CHOKE CABLE FOR MODELS 360HA AND 360HB (NOT SHOWN) (1 required per assembly)
		F191993-1 - Bracket, NLA [ More info ] Unavailable
#3	F85735	SEAL (24 required per assembly)
		F85735 - 26F857351 [ More info ] Unavailable
		26-F85735-1 - Seal, NLA [ More info ] $1.99 $1.68 10+ In Stock.
#4	F1753	FASTENER (24 required per assembly)
		F1753 - Fastener, NLA [ More info ] $1.99 $1.68 10+ In Stock.
#5	FS463712	ENGINE COVER, (1 required per assembly) INCLUDES ITEMS 6, 8, 9, 15 AND 45
		FS463712 - Cover, NLA [ More info ] Unavailable
#7	F2025	PAN HD SCREW, 10 X 5/8 (1 required per assembly)
		10-F2025 - Screw -ss, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#8	F1728	PAN HD SELF-TAPPING SCREW (4 required per assembly)
		10-F1728 - SCREW,NLA [ More info ] $1.25 10+ In Stock.
#9	F463864	RETAINER, TILT HANDLE (2 required per assembly)
		F463864 - Retainer, NLA [ More info ] $1.50 $1.28 9 In Stock.
#12	F366392	SIDE PLATE (2 required per assembly)
		F366392 - DECAL NLA [ More info ] Unavailable
#13	F463366	NAME PLATE, "CHRYSLER" (2 required per assembly)
		F463366 - Medallion, NLA [ More info ] Unavailable
#14	F7011	HEX NUT, 10 - 24 (4 required per assembly)
		11-F7011 - 11F7009 [ More info ] Unavailable
		11-F7009 - Nut, (#10-24) [ More info ] Unavailable
#15	FA458480	ENGINE COVER RETAINER W/SCREWS & NUTS (1 required per assembly)
		FA458480 - Retainer Kit,NLA [ More info ] $5.00 $4.24 1 In Stock.
#16	F1475	FILL HD SCREW, 10 - 24 X 1/2 (4 required per assembly)
		10-F1475 - Screw -ss, NLA [ More info ] Unavailable
#17	F485512	INSERT PLATE (2 required per assembly)
		F485512 - PLATE NLA [ More info ] Unavailable
#19	F1238	HEX CAP SCREW, 1/4 - 20 X 3/4 (2 required per assembly)
		F1238 - Screw - Priced Individually [ More info ] Unavailable
		10-49668 - Screw - Priced Individually [ More info ] $1.10 $0.88 5 In Stock.
#20	F458774	BRACKET, RETAINER REAR (1 required per assembly)
		F458774 - Bracket, NLA [ More info ] $2.50 $2.13 1 In Stock.
#21	F85756	SUPPORT PLATE PACKING (1 required per assembly)
		F85756 - HOOD SEAL,NLA [ More info ] Unavailable
#23	F1738	HEX JAM NUT, 3/8 - 24 FOR MODELS 360HA AND 360HB (1 required per assembly)
		11-F1738 - Nut -ss, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#25	F1733	PAN HD SCREW, 10 - 24 X 9/16 (3 required per assembly)
		10-F1733 - Screw, SS [ More info ] $1.29 2 In Stock.
		10-852453 - Screw [ More info ] $1.50 Available to Order: Shipping delay up to 10 days.
#27	FA328763	COVER LATCH HANDLE W/SHAFT (1 required per assembly)
		FA328763 - Handle Kit, NLA [ More info ] Unavailable
#29	F307818	BEARING, LATCH SHAFT (2 required per assembly)
		23-F307818 - Bushing -nyLiner [ More info ] Unavailable
		23-26841 - Bushing - Priced Individually [ More info ] $7.59 10+ In Stock.
#30	F458677	INSERT, CHOKE KNOB, FOR MODELS 360HA AND 360HB (1 required per assembly)
		F458677 - Insert, NLA [ More info ] $3.17 $2.68 10+ In Stock.
#31	F286547	CHOKE KNOB FOR MODELS 360HA AND 360HB (1 required per assembly)
		F286547 - Choke Knob, NLA [ More info ] $31.99 $27.09 10+ In Stock.
#32	F433503	CHOKE KNOB CABLE FOR MODELS 360HA AND 360HB (1 required per assembly)
		F433503 - Cable, NLA [ More info ] Unavailable
#33	F311189-1	BUSHING, CABLE ENTRY (1 required per assembly)
		F3111891 - Bushing, NLA [ More info ] $1.25 $1.06 3 In Stock.
#34	F1987	PLAIN WASHER (1 required per assembly)
		F1987 - Washer - Priced Individually [ More info ] $0.25 10+ In Stock.
		12-34437 - Washer (5/16 In. I.d.) [ More info ] $2.89 Available to Order: Shipping delay up to 10 days.
#35	F183300	SPRING (1 required per assembly)
		24-F183300 - Spring, NLA [ More info ] $6.75 10+ In Stock.
#36	F1515	HEX NUT, 5/16 - 18 (2 required per assembly)
		F1515 - Hex Hut, 5/16 - 18 [ More info ] $0.30 10+ In Stock.
		11-68292 - Nut (5/16 Inch) [ More info ] $1.50 10+ In Stock.
		11-8M0204668 - NUT @5 [ More info ] Unavailable
#37	F8096	SPRING LOCKWASHER (2 required per assembly)
		F8096 - LockWasher - Priced Individually [ More info ] Unavailable
		13-53166 - LockWasher - Priced Individually [ More info ] $1.80 10+ In Stock.
#38	F89777-1	LATCH CAM (1 required per assembly)
		F89777-1 - Cam - Latch, NLA [ More info ] $6.00 $5.08 10+ In Stock.
#39	F1293	RD HD SCREW, 2 X 3/16 (2 required per assembly)
		F1293 - F1293 - SCREW [ More info ] Unavailable Replaced by 10-F1447
		10-F1447 - SCREW [ More info ] Unavailable
		10-20314 - Screw, NLA [ More info ] Unavailable
#40	FA468395	IDENTIFICATION PLATE W/SCREWS, U.S.A. (1 required per assembly)
		FA468395 - ID PLATE NLA [ More info ] Unavailable
#41	F307860	INTAKE SILENCER FOR MODELS 360HA AND 360HB (1 required per assembly)
		F307860 - SILENCER,NLA [ More info ] $4.00 2 In Stock.
#42	FA307779	BAFFLE, AIR INTAKE W/SILENCER FOR MDLS 360HA, 360HB & 468HB (1 required per assembly)
		FA307779 - BAFFLE KIT,NLA [ More info ] Unavailable
#43	F1864	HEX HD SCREW, 1/4 - 20 X 3/4 (2 required per assembly)
		10-F1864 - Screw SS [ More info ] Unavailable
		10-28636 - Screw - Priced Individually [ More info ] $1.80 10+ In Stock.
#44	F1953	HEX HD SCREW, 1/4 - 20 X 1 (2 required per assembly)
		10-F1953 - 10F1532 [ More info ] Unavailable
		10-F1532 - Screw [ More info ] Unavailable
		10-819110100 - Screw [ More info ] $0.50 Available to Order: Shipping delay up to 10 days.
#45	FA366778	ENGINE COVER RETAINER, FORWARD W/SCREWS AND NUTS (1 required per assembly)
		FA366778 - Retainer Kit, NLA [ More info ] $5.00 $4.24 10+ In Stock.
#46	467785	DECAL, "SUPER SPORT" FOR MODEL 464HB (2 required per assembly)
#47	475785	DECAL, "SPORT" FOR MODEL 468HB (2 required per assembly)
#1	FA467892	INSERT, FRONT PLATE, U.S.A. (1 required per assembly)
		FA467892 - Decal, NLA [ More info ] $6.52 $5.53 1 In Stock.
#2	F475711	FRONT PLATE (1 required per assembly)
		F475711 - F475711 - PLATE [ More info ] Unavailable Replaced by -FK606711
		FK606711 - Plate Kit [ More info ] $10.87 $9.21 7 In Stock.
#6	F467269	TILT HANDLE (1 required per assembly)
		F467269 - F467269 - HANDLE [ More info ] Unavailable Replaced by -817814A1
		817814A 1 - Handle Kit, NLA [ More info ] $8.89 $7.53 4 In Stock.
#10	A467528	INSERT, REAR TRIM (1 required per assembly)
#11	475180	REAR TRIM (1 required per assembly)
#18	A467385	INSERT, SIDE PLATE (2 required per assembly)
#22	F307038	SUPPORT PLATE (1 required per assembly)
		100-F307038 - PLATE,NLA [ More info ] Unavailable
#26	F310189	BUSHING, ELECTRIC CABLE ENTRY (1 required per assembly)
		F310189 - Bushing [ More info ] Unavailable
		F549189 - F5491891 [ More info ] Unavailable
		F549189-1 - 23F5491892 [ More info ] Unavailable
		23-F549189-2 - Bushing [ More info ] Unavailable
		23-828763 - Bushing, NLA [ More info ] $9.17 $7.76 10+ In Stock.
#1	A465892	INSERT, FRONT PLATE, U.S.A (1 required per assembly)
#1	FA463892	INSERT, FRONT PLATE, U.S.A. (1 required per assembly)
		FA463892 - DECAL NLA [ More info ] Unavailable
#2	F463711-1	FRONT PLATE (1 required per assembly)
		F463711-1 - F463711-1 - PLATE [ More info ] Unavailable Replaced by -FK606711
#6	F463269	TILT HANDLE (1 required per assembly)
		F463269 - F463269 - HANDLE [ More info ] Unavailable Replaced by -817814A1
#10	A463528 1	INSERT, REAR TRIM (1 required per assembly)
#11	F433180-1	REAR TRIM (1 required per assembly)
		F4331801 - TRIM,NLA [ More info ] Unavailable
#18	A485385	INSERT, SIDE PLATE (2 required per assembly)
#22	A310038 2	SUPPORT PLATE (1 required per assembly)
#26	FA366953	BUSHING, STARTER HANDLE (1 required per assembly)
		FA366953 - Bushing, NLA [ More info ] $8.00 $6.78 6 In Stock.
