Parts for Chrysler 45 HP (1975) Engine Cover & Support Plate

Revise Search: All Models > 45 HP (1975) > 455BH ( ) > Engine Cover & Support Plate

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#	FA466893	INSERT, FRONT PLATE, CANADA, FOR ALTERNATOR MODELS (1 required per assembly)
		FA466893 - DECAL NLA [ More info ] Unavailable
#	AC16395 7	IDENTIFICATION PLATE W/SCREWS, CANADA (1 required per assembly)
#	A463893	INSERT, FRONT PLATE, CANADA FOR HAND START MODELS (1 required per assembly)
#	321373 2	DECAL, "MAGNAPOWER IGNITION" (NOT SHOWN) (1 required per assembly)
#	FA467892	INSERT, FRONT PLATE, U.S.A., FOR C.D. MODELS (1 required per assembly)
		FA467892 - Decal, NLA [ More info ] $6.52 $5.53 1 In Stock.
#	FA466892	INSERT, FRONT PLATE, U.S.A., FOR ALTERNATOR MODELS (1 required per assembly)
		FA466892 - DECAL NLA [ More info ] Unavailable
#	F310189	BUSHING ELECTRIC CABLE ENTRY, FOR ELECTRIC START MODELS (1 required per assembly)
		F310189 - Bushing [ More info ] Unavailable
		F549189 - F5491891 [ More info ] Unavailable
		F549189-1 - 23F5491892 [ More info ] Unavailable
		23-F549189-2 - Bushing [ More info ] Unavailable
		23-828763 - Bushing, NLA [ More info ] $9.17 $7.76 10+ In Stock.
#	FA467893	INSERT, FRONT PLATE, CANADA, FOR C.D. MODELS (1 required per assembly)
		FA467893 - DECAL NLA [ More info ] Unavailable
#	F307038	SUPPORT PLATE, FOR ELECTRIC START MODELS (1 required per assembly)
		100-F307038 - PLATE,NLA [ More info ] Unavailable
#	F191993-1	BRACKET, CHOKE CABLE (NOT SHOWN) (1 required per assembly)
		F191993-1 - Bracket, NLA [ More info ] Unavailable
#1	F463711-1	PLATE, FRONT (1 required per assembly)
		F463711-1 - F463711-1 - PLATE [ More info ] Unavailable Replaced by -FK606711
		FK606711 - Plate Kit [ More info ] $10.87 $9.21 7 In Stock.
#2	F366392	SIDE PLATE (2 required per assembly)
		F366392 - DECAL NLA [ More info ] Unavailable
#3	FS463712	ENGINE COVER (1 required per assembly) INCLUDES ITEMS 7, 49, 50, 58 AND 61
		FS463712 - Cover, NLA [ More info ] Unavailable
#4	FA463892	INSERT, FRONT PLATE, U.S.A. FOR HAND START MODELS (1 required per assembly)
		FA463892 - DECAL NLA [ More info ] Unavailable
#6	F1475	FILL HD SCREW, 10 - 24 X 1/2 (4 required per assembly)
		10-F1475 - Screw -ss, NLA [ More info ] Unavailable
#7	FA366778	ENGINE COVER RETAINER FORWARD W/SCREWS AND NUTS (1 required per assembly)
		FA366778 - Retainer Kit, NLA [ More info ] $5.00 $4.24 10+ In Stock.
#8	F1864	HEX HD SCREW, 1/4 - 20 X 3/4 (2 required per assembly)
		10-F1864 - Screw SS [ More info ] Unavailable
		10-28636 - Screw - Priced Individually [ More info ] $1.80 10+ In Stock.
#9	F307860	INTAKE SILENCER (1 required per assembly)
		F307860 - SILENCER,NLA [ More info ] $4.00 2 In Stock.
#10	F1953	HEX HD SCREW, 1/4 - 20 X 1 (2 required per assembly)
		10-F1953 - 10F1532 [ More info ] Unavailable
		10-F1532 - Screw [ More info ] Unavailable
		10-819110100 - Screw [ More info ] $0.50 Available to Order: Shipping delay up to 10 days.
#11	F1293	RD HD SCREW, 2 X 3/16 (2 required per assembly)
		F1293 - F1293 - SCREW [ More info ] Unavailable Replaced by 10-F1447
		10-F1447 - SCREW [ More info ] Unavailable
		10-20314 - Screw, NLA [ More info ] Unavailable
#12	FA77395-5	IDENTIFICATION PLATE W/SCREWS, U.S.A. (1 required per assembly)
		FA77395-5 - ID PLATE NLA [ More info ] Unavailable
#13	F458677	INSERT, CHOKE KNOB (1 required per assembly)
		F458677 - Insert, NLA [ More info ] $3.17 $2.68 10+ In Stock.
#15	F1993	HEX SLOT HD SCREW, 1/4 - 20 X 5/8 (2 required per assembly)
		10-F1993 - SCREW SS [ More info ] Unavailable
		10-820628 - Screw, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#17	F1647	HEX NUT, 8 - 32 (1 required per assembly)
		11-F1647 - Nut, (#8-32)(Stainless Steel) NLA [ More info ] Unavailable
#18	F8056	SPRING LOCKWASHER (1 required per assembly)
		13-F8056 - LockWasher [ More info ] $0.98 $0.83 10+ In Stock.
#19	89-817760A 2	CHOKE SOLENOID (1 required per assembly)
		89-817760A 2 - Solenoid Kit [ More info ] Unavailable
#20	F1515	HEX NUT, 5/16 - 18 (2 required per assembly)
		F1515 - Hex Hut, 5/16 - 18 [ More info ] $0.30 10+ In Stock.
		11-68292 - Nut (5/16 Inch) [ More info ] $1.50 10+ In Stock.
		11-8M0204668 - NUT @5 [ More info ] Unavailable
#21	F8096	SPRING LOCKWASHER (2 required per assembly)
		F8096 - LockWasher - Priced Individually [ More info ] Unavailable
		13-53166 - LockWasher - Priced Individually [ More info ] $1.80 10+ In Stock.
#21A	F89777-1	LATCH CAM (1 required per assembly)
		F89777-1 - Cam - Latch, NLA [ More info ] $6.00 $5.08 10+ In Stock.
#22	F183300	SPRING (1 required per assembly)
		24-F183300 - Spring, NLA [ More info ] $6.75 10+ In Stock.
#22A	F1987	PLAIN WASHER (1 required per assembly)
		F1987 - Washer - Priced Individually [ More info ] $0.25 10+ In Stock.
		12-34437 - Washer (5/16 In. I.d.) [ More info ] $2.89 Available to Order: Shipping delay up to 10 days.
#23	F307818	BEARING, LATCH SHAFT (2 required per assembly)
		23-F307818 - Bushing -nyLiner [ More info ] Unavailable
		23-26841 - Bushing - Priced Individually [ More info ] $7.59 10+ In Stock.
#24	F1733	PAN HD SCREW, 10 - 24 X 9/16 (3 required per assembly)
		10-F1733 - Screw, SS [ More info ] $1.29 2 In Stock.
		10-852453 - Screw [ More info ] $1.50 Available to Order: Shipping delay up to 10 days.
#25	F311189-1	BUSHING, CABLE ENTRY (1 required per assembly)
		F3111891 - Bushing, NLA [ More info ] $1.25 $1.06 3 In Stock.
#26	F286547	CHOKE, KNOB (1 required per assembly)
		F286547 - Choke Knob, NLA [ More info ] $31.99 $27.09 10+ In Stock.
#27	F433503	CHOKE CABLE (1 required per assembly)
		F433503 - Cable, NLA [ More info ] Unavailable
#28	F8094	PLAIN WASHER (1 required per assembly)
		F8094 - Washer SS [ More info ] $1.29 5 In Stock.
		12-40023 16 - Washer - Priced Individually [ More info ] $1.17 2 In Stock.
		128M0214930 - WASHER Note: Must be ordered in multiples of 5 [ More info ] $1.00 1 In Stock.
#29	FA328763	COVER LATCH HANDLE W/SHAFT (1 required per assembly)
		FA328763 - Handle Kit, NLA [ More info ] Unavailable
#30	FA366953	BUSHING STARTER HANDLE, FOR HAND START MODELS (1 required per assembly)
		FA366953 - Bushing, NLA [ More info ] $8.00 $6.78 6 In Stock.
#31	F1615	HEX NUT, 5/16 - 24 (2 required per assembly)
		F1615 - Hex Nut, 5/16 - 24 [ More info ] Unavailable
		11-28770 - Nut (5/16-24) [ More info ] $3.59 10+ In Stock.
#33	F177917	STARTER RELAY (1 required per assembly)
		F177917 - Relay Solenoid - 3 Post. [ More info ] Unavailable
		803822T - Relay [ More info ] Unavailable
		18-5835 - Solenoid, 89-817109A3 - 4 Post [ More info ] $54.99 $52.26 1 In Stock.
		SW774 - Solenoid [ More info ] $45.12 $39.02 2 In Stock.
#34	F8083	SPRING LOCKWASHER (2 required per assembly)
		F8083 - LockWasher SS [ More info ] Unavailable
		13-26992 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#35	F91460-2	CIRCUIT BREAKER (1 required per assembly)
		F91460-2 - 88F510460 [ More info ] Unavailable
		88-F510460 - Circuit Breaker [ More info ] Unavailable
#36	F8011	PLAIN WASHER (2 required per assembly)
		F8011 - Washer SS [ More info ] Unavailable
		12-89302 - Washer (.203 X .406 X .040) [ More info ] $1.80 10+ In Stock.
#38	F1975	SPRING LOCKWASHER (3 required per assembly)
		13-F1975 - LockWasher - Priced Individually [ More info ] Unavailable
		13-26996 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#39	F1513	HEX NUT, 10 - 32 (5 required per assembly)
		F1513 - Hex Nut 10 - 32 [ More info ] $0.86 10+ In Stock.
		11-68219 - Nut (#10-32) [ More info ] $2.99 10+ In Stock.
#40	F1238	HEX HD SCREW, 1/4 - 20 X 3/4 (8 required per assembly)
		F1238 - Screw - Priced Individually [ More info ] Unavailable
		10-49668 - Screw - Priced Individually [ More info ] $1.10 $0.88 5 In Stock.
#41	F307683	CIRCUIT BREAKER WIRE (1 required per assembly)
		84-F307683 - Wire, NLA [ More info ] $8.15 $6.90 10+ In Stock.
#42	F91446-1	CIRCUIT BREAKER BRACKET (1 required per assembly)
		F91446-1 - F914462 [ More info ] Unavailable
		F91446-2 - Bracket, NLA [ More info ] $6.56 $5.56 4 In Stock.
#43	F1738	HEX JAM NUT, 3/8 - 24 (1 required per assembly)
		11-F1738 - Nut -ss, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#44	F458774	BRACKET RETAINER REAR (1 required per assembly)
		F458774 - Bracket, NLA [ More info ] $2.50 $2.13 1 In Stock.
#46	F85756	SUPPORT PLATE PACKING (1 required per assembly)
		F85756 - HOOD SEAL,NLA [ More info ] Unavailable
#47	F463366	NAME PLATE, "CHRYSLER" (2 required per assembly)
		F463366 - Medallion, NLA [ More info ] Unavailable
#49	FA458480	ENGINE COVER RETAINER W/SCREWS AND NUTS (1 required per assembly)
		FA458480 - Retainer Kit,NLA [ More info ] $5.00 $4.24 1 In Stock.
#50	F463864	RETAINER, TILT HANDLE (2 required per assembly)
		F463864 - Retainer, NLA [ More info ] $1.50 $1.28 9 In Stock.
#51	F7011	HEX NUT, 10 - 24 (4 required per assembly)
		11-F7011 - 11F7009 [ More info ] Unavailable
		11-F7009 - Nut, (#10-24) [ More info ] Unavailable
#52	F433180-1	TRIM, REAR (1 required per assembly)
		F4331801 - TRIM,NLA [ More info ] Unavailable
#53	FA486385	INSERT, PLATE SIDE (2 required per assembly)
		FA486385 - Decal , 45 [ More info ] Unavailable
#54	F85735-1	SEAL (24 required per assembly)
		26-F85735-1 - Seal, NLA [ More info ] $1.99 $1.68 10+ In Stock.
#55	F1753	FASTENER (24 required per assembly)
		F1753 - Fastener, NLA [ More info ] $1.99 $1.68 10+ In Stock.
#58	F463269	TILT HANDLE (1 required per assembly)
		F463269 - F463269 - HANDLE [ More info ] Unavailable Replaced by -817814A1
		817814A 1 - Handle Kit, NLA [ More info ] $8.89 $7.53 4 In Stock.
#59	FA307779	BAFFLE, AIR INTAKE W/SILENCER (1 required per assembly)
		FA307779 - BAFFLE KIT,NLA [ More info ] Unavailable
#60	A310038 2	SUPPORT PLATE, FOR HAND START MODELS (1 required per assembly)
#61	F1728	PAN HD SELF-TAPPING SCREW (4 required per assembly)
		10-F1728 - SCREW,NLA [ More info ] $1.25 10+ In Stock.
#62	A464528 1	INSERT, TRIM REAR (1 required per assembly)
#63	F485512	INSERT, PLATE (2 required per assembly)
		F485512 - PLATE NLA [ More info ] Unavailable
#64	F2025	PAN HD SCREW, 10 X 5/8 (1 required per assembly)
		10-F2025 - Screw -ss, NLA [ More info ] $1.25 $1.06 10+ In Stock.
