Parts for Chrysler 45 HP (1975) Reed Plate
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | F1915 | HEX HD SCREW, 1/4 - 20 X 7/8 (8 required per assembly) |
  |
10-F1915 - 10F2008 [ More info ] Unavailable |
|
  |
|
10-F2008 - Screw -ss, NLA [ More info ]
|
| #2 | F1515 | HEX NUT, 5/16 - 18 (2 required per assembly) |
  |
|
F1515 - Hex Hut, 5/16 - 18 [ More info ]
|
  |
|
11-68292 - Nut (5/16 Inch) [ More info ]
|
  |
|
11-8M0204668 - NUT @5 [ More info ] Unavailable |
| #3 | F40209 | CARBURETOR STUD (2 required per assembly) |
  |
16-F40209 - STUD [ More info ] Unavailable |
|
  |
|
16-826388 1 - Stud, NLA [ More info ]
|
| #5 | FA433167 | CARBURETOR ADAPTER FLANGE W/STUDS (1 required per assembly) |
  |
|
FA433167 - Adapter Kit, NLA [ More info ] Unavailable |
| #6 | F433168 | CARBURETOR ADAPTER GASKET (1 required per assembly) |
  |
|
27-F433168 - Carburetor Adapter Gasket [ More info ]
|
| #7 | F1141 | FLAT HD SCREW, 10 - 24 X 1/2 (4 required per assembly) |
  |
F1141 - Screw, NLA [ More info ] Unavailable |
|
  |
|
10-21424 - Screw, NLA [ More info ] Unavailable |
| #8 | F433404 | DEFLECTOR PLATE (1 required per assembly) |
  |
F433404 - Deflector Plate [ More info ] Unavailable |
|
  |
|
819807 1 - Deflector Plate, NLA [ More info ]
|
| #9 | F433406 | DEFLECTOR PLATE GASKET (1 required per assembly) |
  |
|
27-F433406 - Deflector Plate Gasket [ More info ]
|
| #10 | FA433158 | REED PLATE W/REEDS, STOPS AND SCREWS (2 required per assembly) |
  |
|
FA433158 - Reed Plate Assembly, NLA [ More info ]
|
  |
|
FA658158 - Reed Plate Assembly, NLA [ More info ] Unavailable |
| #11 | F335160 | REED (4 required per assembly) |
  |
34-F335160 - 34F316160 [ More info ] Unavailable |
|
  |
|
34-F316160 - Reed, 4 Petal, Sold as a Single Reed Only [ More info ]
|
| #12 | F88161-3 | REED STOP (4 required per assembly) |
  |
F88161-3 - 34F881614 [ More info ] Unavailable |
|
  |
|
34-F88161-4 - Reed Stop, NLA [ More info ]
|
| #13 | F1298 | ROUND HD SCREW W/LOCKWASHER, 6 - 32 X 1/4 (16 required per assembly) |
  |
|
|
  |
|
|
  |
|
10-819074 - Screw -w/Lw [ More info ]
|
| #14 | FA433387 | DECAL, TIMING (1 required per assembly) |
  |
|
FA433387 - FA433387 - DECAL KIT-TIMING [ More info ] Unavailable Replaced by 37-817792A1 |
  |
|
37-817792A 1 - Decal Kit - Timing, NLA [ More info ] Unavailable |
| #15 | F286772-1 | CLAMP, FOR HAND START MODELS ONLY (1 required per assembly) |
  |
|
54-F286772-1 - Clamp [ More info ]
|
