Parts for Chrysler 3.5 HP (1981) Power Head

Revise Search: All Models > 3.5 HP (1981) > 353H1N ( ) > Power Head

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#	F93748-1	GASKET, CYLINDER DRAIN (1 required per assembly)
		27-F93748-1 - Cylinder Drain Reed Plate Gasket [ More info ] $2.99 10+ In Stock.
#	F40279-1	GASKET, CYLINDER EXHAUST LOWER (1 required per assembly)
		27-F40279-1 - Gasket [ More info ] $14.48 $12.26 10 In Stock.
#	800-817894A 2	*SHORT BLOCK (NOT SHOWN) (1 required per assembly) INCLUDES ALL ITEMS MARKED WITH AN ASTERISK (). ALSO REFER TO CRANKSHAFT AND PISTON PAGE ORIGINAL FORCE P/N C 433010-2**
		800-817894A 2 - SHORT BLOCK,NLA [ More info ] Unavailable
#	F40906-1	GASKET, CARBURETOR (1 required per assembly)
		F40906-1 - 27F85906 [ More info ] Unavailable
		27-F85906 - Carburetor Gasket [ More info ] Unavailable
		27-828925 - Carburetor Gasket [ More info ] $2.39 10+ In Stock.
#	F269122-1	GASKET, CRANKCASE PARTING LINE SEAL (1 required per assembly)
		F269122-1 - F1841221 [ More info ] Unavailable
		F184122-1 - Seal - Red, 40 Inches, NLA [ More info ] $19.90 $13.54 10 In Stock.
#	F433168	GASKET, CARBURETOR ADAPTER (1 required per assembly)
		27-F433168 - Carburetor Adapter Gasket [ More info ] $2.69 10+ In Stock.
#	F84036	SPARK CONTROL BEARING, L.H. (1 required per assembly)
		F84036 - Spark Control Bearing - LH [ More info ] Unavailable
		819208 - Spark Control Bearing [ More info ] Unavailable
#	F40223	GASKET, TRANSFER PORT COVER (1 required per assembly)
		27-F40223 - Transfer Port Cover Gasket [ More info ] Unavailable
		27-820500 - Transfer Port Gasket [ More info ] Unavailable
		27-820500A 3 - Gasket Kit [ More info ] $17.67 5 In Stock.
		18-0869-9 - Gasket 27-F40223 2-Pack [ More info ] $19.99 $19.30 Available to Order: Shipping delay up to 10 days.
#	F97067	GASKET, THERMOSTAT COVER (1 required per assembly)
		27-F97067 - Gasket [ More info ] Unavailable
		27-819377 - Thermostat Cover Gasket [ More info ] $2.59 1 In Stock.
#	F311996	GASKET, CYLINDER HEAD COVER (1 required per assembly)
		27-F311996 - Gasket [ More info ] $3.00 10+ In Stock.
#	F93472-1	GASKET, CYLINDER DRAIN (1 required per assembly)
		27-F93472-1 - Cylinder Drain Cover Gasket [ More info ] $7.40 10+ In Stock.
#	F307279-2	GASKET, CYLINDER EXHAUST UPPER (1 required per assembly)
		27-F307279-2 - Gasket [ More info ] $7.09 10+ In Stock.
#	F433406	GASKET, DEFLECTOR PLATE (1 required per assembly)
		27-F433406 - Deflector Plate Gasket [ More info ] $5.09 $2.86 10+ In Stock.
#	F40833-4	GASKET, RELIEF COVER (1 required per assembly)
		27-F40833-4 - Gasket [ More info ] $4.94 10+ In Stock.
#	F201529-1	GASKET, CYLINDER HEAD (1 required per assembly)
		27-F201529-1 - 27-F201529-1 - GASKET [ More info ] Unavailable Replaced by 27-F201529-1
#	F366277	GASKET, BEARING CAGE (1 required per assembly)
		27-F366277 - Gasket [ More info ] $3.01 $2.56 10+ In Stock.
#	F40154-3	GASKET, EXHAUST PORT PLATE (3 required per assembly)
		F40154-3 - Exhaust Port Plate Gasket [ More info ] Unavailable
		27-F40154-4 - Gasket, NLA [ More info ] $13.49 10+ In Stock.
#1	FG1007-1	GASKET SET (1 required per assembly)
		FG1007-1 - FG10072, NLA [ More info ] Unavailable
		FG1007-2 - Gasket Set [ More info ] Unavailable
		27-809755A 1 - Gasket Set [ More info ] Unavailable
#2	F1864	HEX SLOT HD SCREW, 1/4 - 20 X 3/4 (9 required per assembly)
		10-F1864 - Screw SS [ More info ] Unavailable
		10-28636 - Screw - Priced Individually [ More info ] $1.80 10+ In Stock.
#3	F1646	HEX SOCKET HD CAP SCREW, 3/8 - 16 X 2 1/4 (1 required per assembly)
		F1646 - Screw, NLA [ More info ] Unavailable
		10-85577 - Screw, NLA [ More info ] Unavailable
#4	F1879	HEX SOCKET HD CAP SCREW, 3/8 - 16 X 1 5/8 (5 required per assembly)
		F1879 - Screw [ More info ] Unavailable
		F2246 - SCREW [ More info ] Unavailable
		10-812567 - Screw [ More info ] $11.59 $9.28 3 In Stock.
#5	F1922	HEX HD SCREW, 1/4 - 20 X 5/8 (3 required per assembly)
		10-F1922 - Screw, NLA [ More info ] Unavailable
#6	F433209-1	STUD, THROTTLE CAM (1 required per assembly)
		16-F433209-1 - Stud [ More info ] $8.61 10+ In Stock.
#7	F1513	HEX NUT, 10 - 32 (2 required per assembly)
		F1513 - Hex Nut 10 - 32 [ More info ] $0.86 10+ In Stock.
		11-68219 - Nut (#10-32) [ More info ] $2.99 10+ In Stock.
#8	F269319	THROTTLE CAM BEARING (2 required per assembly)
		23-F269319 - Bushing, NLA [ More info ] $9.69 10+ In Stock.
#9	F8058	INTERNAL TOOTH LOCKWASHER (4 required per assembly)
		13-F8058 - LockWasher, NLA [ More info ] $1.09 10+ In Stock.
#10	F433192	THROTTLE CAM (1 required per assembly)
		F433192 - Cam, NLA [ More info ] $6.00 $5.08 10+ In Stock.
#11	817747 1	BALL JOINT W/BEARING (2 required per assembly)
		817747 1 - Ball Joint Assembly [ More info ] Unavailable
		828514A 1 - Ball and Socket [ More info ] $22.61 10+ In Stock.
#12	F1910	ELASTIC STOP NUT, 1/4 - 20 (1 required per assembly)
		F1910 - 11F7008 [ More info ] Unavailable
		11-F7008 - Nut, (.250-20) [ More info ] Unavailable
		11-72008 - Nut (1/4-20) [ More info ] Unavailable
		11-826708 8 - Nut [ More info ] $1.70 Available to Order: Shipping delay up to 10 days.
#14	F85502	THROTTLE LINK (1 required per assembly)
		F85502 - Throttle Link [ More info ] Unavailable
		819002 - Throttle Link [ More info ] $47.42 10+ In Stock.
#15	F84035-2	SPARK CONTROL BEARING, R.H. (1 required per assembly)
		F84035-2 - Spark Control Bearing - RH [ More info ] Unavailable
		816514 - Bearing - Black [ More info ] Unavailable
#16	F84026	SPARK CONTROL SWIVEL (2 required per assembly)
		10-F84026 - SCREW-SHOULDER [ More info ] Unavailable
		10-819625 - Screw, NLA [ More info ] $9.89 10+ In Stock.
#17	F1134	FILL HD SCREW, 8 - 32 X 1 - 1/8 (2 required per assembly)
		10-F1134 - SCREW,NLA [ More info ] Unavailable
#18	F307942-1	BUMPER (2 required per assembly)
		F307942-1 - F3079422 [ More info ] Unavailable
		F307942-2 - Bushing, NLA [ More info ] $1.50 $1.28 10+ In Stock.
#19	F1997	STOP NUT, 8 - 32 (2 required per assembly)
		11-F1997 - Nut (#8-32) [ More info ] Unavailable
		11-826709 4 - Nut - Priced Individually [ More info ] $1.88 3 In Stock.
#20	F1473	HEX NUT, 10 - 24 (1 required per assembly)
		F1473 - Hex Nut 10 - 24 [ More info ] Unavailable
		11-79989 - Nut (10 - 24) [ More info ] $2.79 10+ In Stock.
#21	F269445-1	SPARK CONTROL LINK (1 required per assembly)
		F269445-1 - Link, NLA [ More info ] $4.49 $3.80 10+ In Stock.
#22	F1995	FILL HD SCREW. 10 - 24 X 1 (4 required per assembly)
		10-F1995 - Screw [ More info ] $0.30 10+ In Stock.
		10-68918 - Screw [ More info ] $3.20 $1.79 10+ In Stock.
#23	F433689	BEARING, TOWERSHAFT (4 required per assembly)
		F433689 - Towershaft Bearing [ More info ] Unavailable
		816957 - Towershaft Bearing, NLA [ More info ] $2.50 1 In Stock.
#24	FK433838	TOWERSHAFT ASSEMBLY (1 required per assembly) W/ILLUS. 26 AND 27
		FK433838 - TOWERSHAFT KIT [ More info ] Unavailable
		819537A 1 - Tower Shaft Kit [ More info ] Unavailable
		819522A 3 - TowerShaft Kit [ More info ] Unavailable
#25	F1727	PLASTIC RIVET (1 required per assembly)
		17-F1727 - Rivet, NLA [ More info ] $1.79 10 In Stock.
#26	F1052	FILL HD SCREW, 1/4 - 20 X 1 (1 required per assembly)
		F1052 - Screw SS [ More info ] $0.56 10+ In Stock.
		10-28666 - Screw, NLA [ More info ] $1.83 $1.56 10+ In Stock.
#27	F1341	HEX NUT, 1/4 - 20 (1 required per assembly)
		F1341 - Hex Nut 1/4 - 20 [ More info ] Unavailable
		11-64015 - Nut (1 /4-20) [ More info ] $2.79 10+ In Stock.
#28	F1969	FILL HD SCREW, 1/4 - 20 X 3/4 (1 required per assembly)
		F1969 - 10F2207 [ More info ] Unavailable
		10-F2207 - Screw, NLA [ More info ] $1.46 10+ In Stock.
#29	FA434876	SHIFT ARM W/ROLLER (1 required per assembly)
		FA434876 - FA434876 - ARM ASSY [ More info ] Unavailable Replaced by -817794A1
		817794A 1 - ARM ASSY,NLA [ More info ] Unavailable
#30	F85610	BEARING (1 required per assembly)
		23-F85610 - Bushing [ More info ] $0.35 10+ In Stock.
		23-97896 - Bushing [ More info ] $4.49 10+ In Stock.
#31	F269052	SHIFT ARM BEARING (2 required per assembly)
		23-F269052 - Bushing, NLA [ More info ] $3.90 10+ In Stock.
#32	F8559	DOWEL PIN (2 required per assembly)
		17-F8559 - Pin, Dowel [ More info ] $1.30 $1.11 10 In Stock.
#33	800-817791A 1	CYLINDER W/CRANKCASE COVER, DEFLECTOR PLATE (1 required per assembly) ILLUS. 3, 4, 32, 38, 39, AND LITERATURE ORIGINAL FORCE P/N A 433010-1
		800-817791A 1 - Cylinder Assembly, NLA [ More info ] Unavailable
#34	F404801	ELBOW (1 required per assembly)
		22-F404801 - Fitting, NLA [ More info ] $7.02 10+ In Stock.
#35	F93811	SCREEN, CYLINDER DRAIN REED PLATE (2 required per assembly)
		35-F93811 - Screen, NLA [ More info ] $2.29 10+ In Stock.
#37	F3A433757	CYLINDER DRAIN REED PLATE (1 required per assembly) W/ILLUS. 35, 40, 41, 42 AND 43
		F3A433757 - Cylinder Drain Reed Plate , NLA [ More info ] Unavailable
#38	F8545	SPRING PIN (1 required per assembly)
		F8545 - Spring Pin [ More info ] Unavailable
		17-22863 - Pin -roll, NLA [ More info ] Unavailable
#40	F18160-2	REED, CYLINDER DRAIN (2 required per assembly)
		F18160-2 - 34F181603 [ More info ] Unavailable
		34-F18160-3 - Reed [ More info ] $10.19 6 In Stock.
#41	F93920	CYLINDER DRAIN REED STOP (2 required per assembly)
		F93920 - Reed Stop, NLA [ More info ] $2.37 10+ In Stock.
#42	F8003	PLAIN WASHER (2 required per assembly)
		F8003 - Washer [ More info ] Unavailable
		12-18552 - Washer [ More info ] Unavailable
#43	F1286	PAN HD SCREW, 4 - 40 X 3/16 (2 required per assembly)
		10-F1286 - Screw, NLA [ More info ] $2.59 10+ In Stock.
#45	FA433471	CYLINDER DRAIN COVER W/FITTING (1 required per assembly)
		FA433471 - Cover, NLA [ More info ] Unavailable
#46	F1136	FLAT HD SCREW, 1/4 - 20 X 1 (2 required per assembly)
		10-F1136 - Screw, NLA [ More info ] Unavailable
#47	F1446	SLOTTED PAN HD SCREW, 1/4 - 20 X 1 (2 required per assembly)
		10-F1446 - SCREW,NLA [ More info ] Unavailable
#48	F7004	STOP NUT, 3/8 - 16 (1 required per assembly)
		11-F7004 - Nut, (.375-16) [ More info ] $0.49 7 In Stock.
		11-28010 - Nut - Priced Individually [ More info ] Unavailable
		11-68411 - Nut (3/8-16) [ More info ] $6.66 10+ In Stock.
		11-826709 12 - Nut, (.375-16) Stainless Steel [ More info ] $6.79 $3.81 10+ In Stock.
#49	F433254	HOSE (1 required per assembly)
		F433254 - 32F691796 [ More info ] Unavailable
		32-F691796 - Hose [ More info ] Unavailable
		32-819029 62 - Hose -22.5 Inch, NLA [ More info ] Unavailable
#50	F84314-2	ELBOW, FUEL LINE (1 required per assembly)
		22-F84314-2 - Elbow, NLA [ More info ] Unavailable
#52	FA411222	TRANSFER PORT COVER (1 required per assembly) W/FITTING AND LITERATURE
		FA411222 - Transfer Port Cover [ More info ] Unavailable
		817790A 1 - Cover Kit [ More info ] Unavailable
#54	F1525	WELCH PLUG (1 required per assembly)
		19-F1525 - Plug, NLA [ More info ] $1.50 $1.28 6 In Stock.
#56	2A 307518	CYLINDER HEAD (1 required per assembly) W/ILLUS. 57 AND 54
#57	F1526	WELCH PLUG (1 required per assembly)
		19-F1526 - Plug, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#58	FS174227	SPARK PLUG (L-4-J) (2 required per assembly)
		FS174227 - SPARK PLUG-L82C [ More info ] Unavailable
		33-817996 2 - SPARK PLUG-L82C [ More info ] Unavailable
		33-811 - SP #L82C Note: Priced Individually [ More info ] Unavailable
		33-896323 - Spark Plug - L82C - Priced Individually [ More info ] Unavailable
		B7HS - NGK Spark Plug, 5110 [ More info ] $4.99 $4.74 10+ In Stock.
		L82C - Champion Spark Plug ( #811M) [ More info ] $4.50 $4.18 10+ In Stock.
#59	F1544	HEX HD SCREW, 3/8 - 16 X 2 - 1/4 (10 required per assembly)
		F1544 - Screw - Priced Individually [ More info ] Unavailable
		10-35787 - Screw - Priced Individually [ More info ] $2.79 Available to Order: Shipping delay up to 10 days.
#60	F2014	PLAIN WASHER (10 required per assembly)
		F2014 - Washer [ More info ] $0.49 3 In Stock.
		12-34931 - Washer, (.406 X .734 X .063 - Stainless Steel) [ More info ] $2.59 10+ In Stock.
#61	F328109	PIPE PLUG CYLINDER HEAD (1 required per assembly)
		22-F328109 - Plug, NLA [ More info ] $3.02 $2.56 10+ In Stock.
#62	F97504	GROMMET, THERMOSTAT (1 required per assembly)
		25-F97504 - Grommet [ More info ] $3.69 Available to Order: Shipping delay up to 10 days.
#63	F97068-1	THERMOSTAT (1 required per assembly)
		F97068-1 - F970682 [ More info ] Unavailable
		F97068-2 - Thermostat, 130 Degree [ More info ] Unavailable
		895338 - Thermostat, 130 Degrees [ More info ] $45.05 4 In Stock.
		18-3556 - Thermostat, 130 Degrees, F97068-2 [ More info ] $41.32 6 In Stock.
#65	F97066-1	THERMOSTAT COVER (1 required per assembly)
		F97066-1 - FA970661 [ More info ] Unavailable
		FA97066-1 - Cover Kit, NLA [ More info ] Unavailable
#67	F97275	FITTING, THERMOSTAT (1 required per assembly)
		22-F97275 - Fitting, NLA [ More info ] $8.46 $7.16 10+ In Stock.
#68	FA97247	WATER TUBE, THERMOSTAT (1 required per assembly) W/LITERATURE
		FA97247 - Thermostat Water Tube, NLA [ More info ] $6.02 $5.10 8 In Stock.
#69	F97772	CLAMP (2 required per assembly)
		F97772 - Clamp, NLA [ More info ] Unavailable
		54-63933 - Clamp [ More info ] $1.96 10+ In Stock.
#70	F141275	FITTING, THERMOSTAT (1 required per assembly)
		F141275 - Thermostat Fitting [ More info ] Unavailable
#71	F1791	HEX HD SCREW, 1/4 - 20 X 2 - 1/8 (9 required per assembly)
		F1791 - Nut, Hex Hd Screw, 1/4 - 20, NLA [ More info ] Unavailable
#72	F8083	SPRING LOCKWASHER (9 required per assembly)
		F8083 - LockWasher SS [ More info ] Unavailable
		13-26992 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#73	F901834	LEAD WIRE CLIP (1 required per assembly)
		F901834 - CLIP,NLA [ More info ] Unavailable
#74	FA433152	EXHAUST PORT COVER W/SCREWS (1 required per assembly)
		FA433152 - COVER KIT-EXHAUS,NLA [ More info ] Unavailable
#75	F40151-1	EXHAUST PORT PLATE (1 required per assembly)
		F40151-1 - F401512 [ More info ] $15.00 1 In Stock.
		F40151-2 - Exhaust Plate, NLA [ More info ] $29.95 10 In Stock.
#7	F463314	FITTING (1 required per assembly)
		21-F463314 - Check Valve, NLA [ More info ] $8.46 $7.16 10+ In Stock.
#78	FS433758	HOSE (1 required per assembly) W/LITERATURE
		FS433758 - Hose [ More info ] $18.75 $15.88 5 In Stock.
#79	22-817740A 1	ELBOW W/METERING CUP (1 required per assembly)
		22-817740A 1 - Fitting Assembly, NLA [ More info ] Unavailable
