Parts for Chrysler 3.5 HP (1981) Hand Starter
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| # | FA27232 | EMERGENCY STARTER ROPE (NOT SHOWN) W/HANDLE (1 required per assembly) |
  |
FA27232 - ROPE W/HANDLE [ More info ] Unavailable |
|
  |
50-12066A 9 - Starter Rope , Priced Individually [ More info ] Unavailable |
|
  |
50-12066Q 9 - Starter Rope , Priced Individually [ More info ] Unavailable |
|
  |
|
50-12066Q10 - Starter Rope - Priced Individually [ More info ]
|
  |
|
18-4915 - Pull Rope, 50-12066Q9 [ More info ]
|
  |
|
50-12066K10 - Starter Rope - Priced Individually [ More info ]
|
| #1 | F1097 | FILL HD SCREW, 1/4 - 20 X 3/8 (1 required per assembly) |
  |
|
F1097 - Screw, NLA [ More info ] Unavailable |
| #2 | F487674 | STARTER PINION GEAR (1 required per assembly) |
  |
F487674 - 43F617674 [ More info ] Unavailable |
|
  |
43-F617674 - Starter Gear [ More info ] Unavailable |
|
  |
|
43-803624T - Starter Gear [ More info ]
|
| #3 | F40425 | STARTER PINION PIN (1 required per assembly) |
  |
|
17-F40425 - Pin,Starter Pinion Gear, NLA [ More info ]
|
| #4 | F485424 | SPRING, STARTER PINION (1 required per assembly) |
  |
|
24-F485424 - SPRING,NLA [ More info ] Unavailable |
| #5 | F901739 | STARTER REWIND SPRING DRIVE (1 required per assembly) |
  |
|
F901739 - Drive, NLA [ More info ]
|
| #6 | F328710 | STARTER ROPE GUIDE POST (1 required per assembly) |
  |
|
F328710 - POST NLA [ More info ] Unavailable |
| #7 | F2042 | WASHER, PLAIN (1 required per assembly) |
  |
F2042 - Washer - Priced Individually [ More info ] Unavailable |
|
  |
|
12-89302 - Washer (.203 X .406 X .040) [ More info ]
|
| #8 | F286132 | STARTER ROPE HANDLE (1 required per assembly) |
  |
|
F286132 - Starter Rope Handle, NLA [ More info ]
|
| #9 | F328232 | STARTER ROPE (1 required per assembly) |
  |
|
F328232 - F328232 - ROPE [ More info ] Unavailable Replaced by -818020A2 |
  |
|
818020A 2 - Rope Kit, NLA [ More info ]
|
| #10 | F1111 | FILL HD SCREW, 1/4 - 20 X 7/8 (4 required per assembly) |
  |
F1111 - 10F1112 [ More info ] Unavailable |
|
  |
|
10-F1112 - Screw -ss, NLA [ More info ]
|
| #11 | F8060 | EXTERNAL TOOTH LOCKWASHER (1 required per assembly) |
  |
|
13-F8060 - LockWasher, NLA [ More info ]
|
| #12 | F328455 | STATER ROPE GUIDE (1 required per assembly) |
  |
|
F328455 - GUIDE,NLA [ More info ] Unavailable |
| #13 | A 486427 | STARTER MOUNTING BRACKET (1 required per assembly) W/CAPS AND ILLUS. 10 |
| #14 | F901970 | SPRING STARTER REWIND (1 required per assembly) |
  |
|
24-F901970 - Spring [ More info ] Unavailable |
| #15 | F191737 | RETAINER, STARTER SPRING (1 required per assembly) |
  |
|
F191737 - Retainer, NLA [ More info ] Unavailable |
| #16 | F328239 | STARTER SPOOL (1 required per assembly) |
  |
|
F328239 - SPOOL NLA [ More info ] Unavailable |
| #17 | F24333 | END, STARTER ROPE (1 required per assembly) |
  |
|
F24333 - Ferrule, NLA [ More info ] Unavailable |
| #18 | F8540 | SPRING PIN (1 required per assembly) |
  |
17-F8540 - Roll Pin [ More info ] Unavailable |
|
  |
|
17-38489 - Pin -roll [ More info ]
|
| #19 | F191971 | STARTER RETAINER EXTENSION (1 required per assembly) |
  |
|
F191971 - Extension, NLA [ More info ] Unavailable |
| #20 | F1513 | HEX NUT, 10 - 32 (4 required per assembly) |
  |
|
F1513 - Hex Nut 10 - 32 [ More info ]
|
  |
|
11-68219 - Nut (#10-32) [ More info ]
|
| #21 | F478502 | LINK (1 required per assembly) |
  |
|
16-F478502 - STUD,NLA [ More info ] Unavailable |
| #22 | 817747 1 | BALL JOINT W/BEARING (1 required per assembly) |
  |
817747 1 - Ball Joint Assembly [ More info ] Unavailable |
|
  |
|
828514A 1 - Ball and Socket [ More info ]
|
| #23 | F485781 | STARTER INTERLOCK LOCK (1 required per assembly) |
  |
|
F485781 - LOCK,NLA [ More info ] Unavailable |
| #24 | F8058 | INTERNAL TOOTH LOCKWASHER (1 required per assembly) |
  |
|
13-F8058 - LockWasher, NLA [ More info ]
|
| #25 | F369887 | INTERLOCK SCREW (2 required per assembly) |
  |
|
10-F369887 - Screw, NLA [ More info ]
|
| #26 | F8028 | PLAIN WASHER (2 required per assembly) |
  |
F8028 - 12F8008 [ More info ] Unavailable |
|
  |
12-F8008 - Washer [ More info ] Unavailable |
|
  |
|
12-35044 - Washer, (.281 X .625 X .065) Stainless Steel [ More info ]
|
| #27 | F486531 | STARTER INTERLOCK ROD (1 required per assembly) |
  |
|
F486531 - ROD-INTERLO,NLA [ More info ] Unavailable |
| #28 | F485971 | STARTER SPRING EXTENSION (1 required per assembly) |
  |
|
F485971 - EXTENSION,NLA [ More info ] Unavailable |
| #29 | F1515 | HEX NUT, 5/16 - 18 (3 required per assembly) |
  |
|
F1515 - Hex Hut, 5/16 - 18 [ More info ]
|
  |
|
11-68292 - Nut (5/16 Inch) [ More info ]
|
  |
|
11-8M0204668 - NUT @5 [ More info ] Unavailable |
| #30 | F8096 | SPRING LOCKWASHER (3 required per assembly) |
  |
F8096 - LockWasher - Priced Individually [ More info ] Unavailable |
|
  |
|
13-53166 - LockWasher - Priced Individually [ More info ]
|
| #31 | F307211 | STUD (3 required per assembly) |
  |
|
16-F307211 - Stud, NLA [ More info ]
|
