Parts for Chrysler 3.5 HP (1981) Carburetor

Revise Search: All Models > 3.5 HP (1981) > 353H1N ( ) > Carburetor

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#	FO14302	MAIN FUEL JET .084 (OPT.) 6250 - 8250 FEET (- required per assembly)
		FO14302 - JET-.084 [ More info ] Unavailable
		F10229 - Jet -.084 [ More info ] Unavailable
		1399-3517 - Jet -.084 [ More info ] $4.09 2 In Stock.
#	FO13193	MAIN FUEL JET .088 (OPT.) 1250 - 3750 FEET (- required per assembly)
		FO13193 - .088 Main Jet - [ More info ] $17.69 1 In Stock.
#	FO13949	MAIN FUEL JET .086 (OPT.) 3750 - 6250 FEET (- required per assembly)
		FO13949 - .086 Main Jet - [ More info ] $17.69 Available to Order: Shipping delay up to 10 days.
#1	F1059	FILL HD SCREW, 6 - 32 X 1 - 4 (1 required per assembly)
		10-F1059 - Screw -ss, NLA [ More info ] $2.93 10+ In Stock.
#2	F184033-1	SWIVEL, CHOKE ROD (1 required per assembly)
		F184033-1 - Swivel [ More info ] $9.12 10+ In Stock.
#3	F184579	SEAL, CHOKE ARM SWIVEL (2 required per assembly)
		25-F184579 - O-Ring [ More info ] Unavailable
		25-68211 - O-Ring [ More info ] $1.40 Available to Order: Shipping delay up to 10 days.
#4	FO16383	CHOKE SHAFT AND LEVER (1 required per assembly)
		FO16383 - SHAFT AND LEVER,NLA [ More info ] Unavailable
#5	F8088	PLAIN WASHER (1 required per assembly)
		12-F8088 - Washer - Priced Individually [ More info ] Unavailable
		12-27882 - Washer - Priced Individually [ More info ] $1.27 10+ In Stock.
#6	F1014	COTTER PIN (1 required per assembly)
		F1014 - Cotter Pin - Priced Individually [ More info ] Unavailable
		18-26953 - Cotter Pin - Priced Individually [ More info ] $4.19 7 In Stock.
#7	FO16385	CHOKE SHAFT RETURN SPRING (1 required per assembly)
		FO16385 - Spring [ More info ] $2.16 4 In Stock.
#8	FO12251	CHOKE RELIEF VALVE (1 required per assembly)
		FO12251 - Relief Valve, NLA [ More info ] $1.25 $1.06 3 In Stock.
#9	FO11103	IDLE MIXTURE SCREW SPRING (1 required per assembly)
		FO11103 - Spring, Idle Mixture [ More info ] Unavailable
		24-27160 - Spring, Idle Adjusting Screw [ More info ] $4.09 10+ In Stock.
#10	FO13946	IDLE MIXTURE SCREW (1 required per assembly)
		FO13946 - Screw - Idle, NLA [ More info ] $8.98 10+ In Stock.
#11	FO10280	CHOKE SHUTTER RETAINING SCREW AND LOCKWASHER (2 required per assembly)
		10-FO10280 - SCREW-W/LW [ More info ] Unavailable
		10-803176 - Screw [ More info ] $3.59 1 In Stock.
#12	FO12250	CHOKE SHUTTER (1 required per assembly)
		FO12250 - CARB PART NLA [ More info ] Unavailable
#13	FO10883	CHOKE RELIEF VALVE SPRING (1 required per assembly)
		FO10883 - 24F10296 [ More info ] Unavailable
		24-F10296 - Spring, Shutter [ More info ] $2.15 $1.82 10+ In Stock.
#14	FO10165	INLET SEAT GASKET (1 required per assembly)
		27-FO10165 - Gasket [ More info ] Unavailable
#15	FO10790	INLET NEEDLE, SEAT AND GASKET (1 required per assembly)
		FO10790 - Inlet Needle, Seat and Gasket, NLA [ More info ] $21.54 2 In Stock.
		18-7057 - Needle And Seat 1395-9258 [ More info ] $11.90 3 In Stock.
		18-7041 - Needle And Seat, FO16311 [ More info ] $19.49 $18.00 2 In Stock.
#16	FO13944	FLOAT LEVER PIN (1 required per assembly)
		17-FO13944 - Carburetor Float Pin [ More info ] $5.59 4 In Stock.
#17	FO15623	FUEL BOWL GASKET (1 required per assembly)
		27-FO15623 - Fuel Bowl Gasket [ More info ] $4.29 10+ In Stock.
#18	F10019	*REPAIR PARTS KIT (1 required per assembly) INCLUDES ALL ITEMS MARKED WITH AN ASTERISK ()**
		F10019 - FK10057, NLA [ More info ] Unavailable
		FK10057 - Carburetor Repair Kit, NLA [ More info ] Unavailable
		18-7037 - Carburetor Kit, FK10008 [ More info ] $23.89 $23.25 10+ In Stock.
#19	FO2510	FUEL BOWL RETAINING SCREW GASKET (2 required per assembly)
		27-FO2510 - Fuel Bowl Gasket [ More info ] $2.39 10+ In Stock.
#20	FO13552	FUEL BOWL (1 required per assembly)
		FO13552 - Bowl [ More info ] Unavailable
		F10127 - BOWL [ More info ] Unavailable
		F10333 - Fuel Bowl [ More info ] $34.48 2 In Stock.
#21	FO13945	FUEL BOWL RETAINING SCREW (1 required per assembly)
		FO13945 - SCREW [ More info ] $29.99 1 In Stock.
		1399-5128 - Screw, NLA [ More info ] Unavailable
#22	FK10000	GASKET SET (1 required per assembly) W/ILLUS. MARKED WITH A DOUBLE ASTERISK ()**
		FK10000 - Carburetor Gasket Set [ More info ] Unavailable
#23	FO13554	FLOAT (1 required per assembly)
		FO13554 - Carburetor Float [ More info ] Unavailable
		891730A01 - Float [ More info ] $38.48 9 In Stock.
#24	F1515	HEX NUT, 5/16 - 18 (2 required per assembly)
		F1515 - Hex Hut, 5/16 - 18 [ More info ] $0.30 10+ In Stock.
		11-68292 - Nut (5/16 Inch) [ More info ] $1.50 10+ In Stock.
		11-8M0204668 - NUT @5 [ More info ] Unavailable
#25	FO16251	MAIN NOZZLE (1 required per assembly)
		FO16251 - Nozzle, NLA [ More info ] Unavailable
#26	FO15406	MAIN FUEL JET .090 (STD.) (1 required per assembly)
		FO15406 - Jet - .090 [ More info ] Unavailable
		1395-6247 - Jet -.090 [ More info ] $15.49 4 In Stock.
#27	F333316	THROTTLE ROLLER SHAFT (1 required per assembly)
		F333316 - Roller Shaft, NLA [ More info ] Unavailable
		830110 - Roller Shaft, NLA [ More info ] $11.84 3 In Stock.
#28	F92759	ROLLER (1 required per assembly)
		F92759 - Roller, NLA [ More info ] Unavailable
		819225 - Roller, NLA [ More info ] $9.69 10+ In Stock.
#29	FO15728	THROTTLE SHAFT AND LEVER (1 required per assembly)
		FO15728 - SHAFT AND LEVER,NLA [ More info ] Unavailable
#30	F1997	STOP NUT, 10 - 24 (1 required per assembly)
		11-F1997 - Nut (#8-32) [ More info ] Unavailable
		11-826709 4 - Nut - Priced Individually [ More info ] $1.88 3 In Stock.
#31	FO14292	THROTTLE SHAFT RETURN SPRING (1 required per assembly)
		24-FO14292 - Spring, NLA [ More info ] $1.62 3 In Stock.
#32	FO16119	THROTTLE SHUTTER (1 required per assembly)
		FO16119 - SHUTTER,NLA [ More info ] Unavailable
#33	FO8942	THROTTLE SHUTTER RETAINING SCREW AND LOCKWASHER (2 required per assembly)
		FO8942 - 10F10328 [ More info ] $0.59 9 In Stock.
		10-F10328 - Screw -w/Lw [ More info ] Unavailable
#34	F40906-1	FLANGE GASKET (1 required per assembly)
		F40906-1 - 27F85906 [ More info ] Unavailable
		27-F85906 - Carburetor Gasket [ More info ] Unavailable
		27-828925 - Carburetor Gasket [ More info ] $2.39 10+ In Stock.
#35	F433061-2	CARBURETOR COMPLETE (WB-17C) (1 required per assembly)
#36	FO4326	BODY CHANNEL WELCH PLUG (1 required per assembly)
		FO4326 - 19F10153 [ More info ] Unavailable
		19-F10153 - Plug [ More info ] $2.39 1 In Stock.
#37	FO10588	BODY CHANNEL CUP PLUG (1 required per assembly)
		19-FO10588 - Plug -cup - Priced Individually [ More info ] $7.49 6 In Stock.
#38	FO3804	THROTTLE SHAFT POSITION RETAINING SCREW WASHER (1 required per assembly)
		FO3804 - WASHER,NLA [ More info ] Unavailable
#39	FO6396	THROTTLE SHAFT POSITION RETAINING SCREW LOCKWASHER (1 required per assembly)
		FO6396 - LOCKWASHER,NLA [ More info ] Unavailable
#40	FO6393	THROTTLE SHAFT POSITION RETAINING SCREW (1 required per assembly)
		FO6393 - SCREW,NLA [ More info ] Unavailable
#41	F84314-2	ELBOW, FUEL LINE (1 required per assembly)
		22-F84314-2 - Elbow, NLA [ More info ] Unavailable
