Parts for Chrysler 20 HP (1981) Magneto
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | F460097-1 | FLYWHEEL (1 required per assembly) |
  |
|
200-F460097-1 - 200-F460097-1 - FLYWHEEL [ More info ] Unavailable Replaced by 200-817812A1 |
  |
|
200-817812A 1 - Flywheel Kit,NLA [ More info ] Unavailable |
| #2 | F12170 | CONDENSER MOUNTING SCREW (2 required per assembly) |
  |
|
10-F12170 - Screw, NLA [ More info ]
|
| #3 | F12181-1 | CONDENSER (2 required per assembly) |
  |
|
F12181-1 - Condenser [ More info ]
|
| #4 | F12186-1 | GROUND LEAD (1 required per assembly) |
  |
|
F12186-1 - Wire Assembly, NLA [ More info ] Unavailable |
| #5 | F436449 | SHORTING SWITCH FOR MANUAL START MODELS (1 required per assembly) |
  |
F436449 - Switch, Shorting [ More info ] Unavailable |
|
  |
87-817952A 1 - Switch Kit [ More info ] Unavailable |
|
  |
|
87-824440A18 - Switch KIT,NLA [ More info ] Unavailable |
| #6 | F460664 | STATOR GROUND WIRE (1 required per assembly) |
  |
|
84-F460664 - Wire Assembly, NLA [ More info ]
|
| #7 | F1513 | HEX NUT (1 required per assembly) |
  |
|
F1513 - Hex Nut 10 - 32 [ More info ]
|
  |
|
11-68219 - Nut (#10-32) [ More info ]
|
| #8 | F8059 | SPRING LOCKWASHER (1 required per assembly) |
  |
13-F8059 - 13F1975 [ More info ] Unavailable |
|
  |
13-F1975 - LockWasher - Priced Individually [ More info ] Unavailable |
|
  |
|
13-26996 - LockWasher - Priced Individually [ More info ]
|
| #9 | F12346 | STATOR PLATE W/LAMINATIONS - USA (1 required per assembly) |
  |
|
F12346 - PLATE,NLA [ More info ] Unavailable |
| #10 | F2092 | FILL HD SCREW, 10 - 32 X 5/8 (1 required per assembly) |
  |
|
F2092 - SCREW,NLA [ More info ] Unavailable |
| #11 | F12146 | COIL WEDGE SPRING (2 required per assembly) |
  |
|
F12146 - Spring, Coil Wedge,NLA [ More info ]
|
| #12 | FA12370 | COIL W/LEAD WIRE (2 required per assembly) |
  |
FA12370 - Coil with Lead Wire and Wedge [ More info ] Unavailable |
|
  |
|
889493A01 - Coil Kit [ More info ]
|
  |
|
18-99275 - Magneto Ignition Coil, Chrysler Force 1 & 2 Cylinder 889493A01, 185-2370 [ More info ]
|
| #13 | F12088 | GROMMET, LEAD WIRE (2 required per assembly) |
  |
|
F12088 - Grommet, Lead Wire,NLA [ More info ]
|
| #14 | FK750-2 | SPARKIE W/SPRING (2 required per assembly) |
  |
FK750-2 - FK1123, NLA [ More info ] Unavailable |
|
  |
FK1123 - Boot Kit [ More info ] Unavailable |
|
  |
|
85-63709A 1 - Boot Kit - Black - Priced Individually [ More info ]
|
| #15 | F12153-1 | BREAKER POINT SET (2 required per assembly) |
  |
|
F12153-1 - Contact Set [ More info ] Unavailable |
| #16 | F12360 | CAM WIPER FELT (1 required per assembly) |
  |
|
F12360 - Felt Cam Wiper, NLA [ More info ]
|
| #18 | F2010 | FILL HD SCREW W/SPRING LOCKWASHER, 10 - 32 X 9/16 (3 required per assembly) |
  |
F2010 - FK2010, NLA [ More info ] Unavailable |
|
  |
|
FK2010 - Screw w/ Lw, NLA [ More info ]
|
| #19 | FK1066 | TUNE UP KIT. (1 required per assembly) |
  |
|
FK1066 - Tune Up Kit [ More info ] Unavailable |
| #20 | F2021 | FLYWHEEL NUT 5/8 - 18 (1 required per assembly) |
  |
|
11-F2021 - NUT,NLA [ More info ]
|
