Parts for Chrysler 20 HP (1981) Crankshaft & Piston Group
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| # | 39-818119A 1 | PISTON RINGS (4 PER SET) .030 OVERSIZE (NOT SHOWN) (1 required per assembly) |
  |
|
39-818119A 1 - Ring Set-2-.030,NLA [ More info ] Unavailable |
| # | FSA458015 | PISTON .010 OVERSIZE (NOT SHOWN) (2 required per assembly) |
  |
|
700-FSA458015 - Piston-.010,NLA [ More info ] Unavailable |
| # | 400-818063A 1 | CRANKSHAFT W/LOWER MAIN BEARING (ALT. MODELS) (1 required per assembly) |
  |
|
400-818063A 1 - Crankshaft,NLA [ More info ] Unavailable |
| # | FSA458260 | PISTON RINGS (4 PER SET) .010 OVERSIZE (NOT SHOWN) (1 required per assembly) |
  |
|
FSA458260 - Rings - 2-.010, NLA [ More info ]
|
| # | 700-818118A 1 | PISTON .030 OVERSIZE (NOT SHOWN) (2 required per assembly) |
  |
|
700-818118A 1 - Piston-.030,NLA [ More info ] Unavailable |
| #1 | F90096 | RETAINER, PISTON PIN (4 required per assembly) |
  |
|
53-F90096 - Lock Ring, NLA [ More info ]
|
| #2 | F366215 | SPACER, PISTON PIN (4 required per assembly) |
  |
|
23-F366215 - Spacer - Piston Pin [ More info ]
|
| #3 | F335217-1 | BEARING, PISTON PIN (2 required per assembly) |
  |
|
31-F335217-1 - Bearing - Piston Pin [ More info ]
|
| #4 | F458017 | PISTON PIN (2 required per assembly) |
  |
|
41-F458017 - PIN-Piston, NLA [ More info ] Unavailable |
| #5 | 600-818052A 4 | CONNECTING ROD (2 required per assembly) W/CAP AND ILLUS. 15 ORIGINAL FORCE P/N S 366016-4 |
  |
600-818052A 4 - Connecting Rod Assembly [ More info ] Unavailable |
|
  |
600-818052A 6 - Connecting Rod [ More info ] Unavailable |
|
  |
|
600-818052T 6 - Connecting Rod [ More info ]
|
| #6 | F458015-1 | PISTON (2 required per assembly) |
  |
700-F458015-1 - Piston - Standard,NLA [ More info ] Unavailable |
|
| #7 | FA458260 | PISTON RING SET (4 PER SET) (1 required per assembly) |
  |
|
39-FA458260 - Rings - 4, NLA [ More info ]
|
| #8 | FA458655 | LINER, CENTER MAIN (1 SET) (1 required per assembly) |
  |
|
FA458655 - Liner Set, NLA [ More info ]
|
| #9 | FA458571 | ROLLER, CENTER MAIN (1 required per assembly) |
  |
|
FA458571 - Roller Set, NLA [ More info ]
|
| #10 | F458579 | SEAL, CRANKCASE (1 required per assembly) |
  |
|
F458579 - Seal, NLA [ More info ]
|
| #11 | F2A458581 | COLLAR W/LOWER CRANKCASE SEAL (1 required per assembly) |
  |
|
F2A458581 - Collar Assembly, NLA [ More info ]
|
| #12 | F461342 | SEAL, DRIVESHAFT SPLINE (1 required per assembly) |
  |
25-F461342 - Seal [ More info ] Unavailable |
|
  |
|
25-32509 - O-ring, (.489 X .070) [ More info ]
|
  |
|
18-7165-9 - O-Ring (PK5) , 0304174 [ More info ]
|
| #13 | F455305 | SEAL, CRANKSHAFT COLLAR (1 required per assembly) |
  |
|
25-F455305 - O-Ring [ More info ]
|
  |
|
18-7457 - O-Ring 25-F455305 [ More info ]
|
| #14 | F286028 | BEARING, CRANKSHAFT LOWER MAIN (1 required per assembly) |
  |
|
30-F286028 - Ball Bearing, NLA [ More info ]
|
| #15 | F85634-2 | SCREW, CONNECTING ROD (4 required per assembly) |
  |
10-F85634-2 - Connecting Rod Screw [ More info ] Unavailable |
|
  |
|
10-91012 - Screw - Special - Priced Individually [ More info ]
|
| #16 | FK85228-1 | BEARING CAGE W/ROLLERS (16 PER SET) (2 required per assembly) |
  |
FK85228-1 - Cage/Roller Set [ More info ] Unavailable |
|
  |
|
31-62596A 2 - Cage Roller, for One Rod Only [ More info ]
|
| #17 | 400-818058A 1 | CRANKSHAFT W/LOWER MAIN BEARING (MANUAL START MODELS) (1 required per assembly) |
  |
|
400-818058A 1 - Crankshaft,NLA [ More info ] Unavailable |
| #18 | F458498 | FLYWHEEL KEY (MANUAL START MODELS) (1 required per assembly) |
  |
F458498 - 28F4584981 [ More info ] Unavailable |
|
  |
|
28-F458498-1 - Key, NLA [ More info ]
|
| #19 | F458028 | BEARING, CRANKSHAFT UPPER MAIN (1 required per assembly) |
  |
|
31-F458028 - Bearing, NLA [ More info ]
|
