Parts for Chrysler 100 HP (1981) Motor Leg

Revise Search: All Models > 100 HP (1981) > 1006B1C ( ) > Motor Leg

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#	FC529390	DECAL, REVERSE LOCK - CANADA (NOT SHOWN) (1 required per assembly)
		FC529390 - FC529390 - DECAL-REV LOCK [ More info ] Unavailable Replaced by -F529390-1
		F529390-1 - DECAL-REV LOCK [ More info ] Unavailable
		37-819450 - Decal -Rev Lock, NLA [ More info ] Unavailable
#1	F85660-1	EXHAUST TUBE (1 required per assembly)
		F85660-1 - Exhaust Tube, NLA [ More info ] Unavailable
#2	F8083	SPRING LOCKWASHER (4 required per assembly)
		F8083 - LockWasher SS [ More info ] Unavailable
		13-26992 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#3	F1705	HEX SLOT HD SCREW, 1/4 - 20 X 3/4 (4 required per assembly)
		F1705 - Screw - Priced Individually [ More info ] Unavailable
		10-28636 - Screw - Priced Individually [ More info ] $1.80 10+ In Stock.
#4	F85258	INSERT (1 required per assembly)
		F85258 - Idle Exhaust Boot Insert [ More info ] Unavailable
		816513 - Idle Exhaust Boot Insert [ More info ] Unavailable
#5	F85130	BOOT IDLE EXHAUST (1 required per assembly)
		F85130 - Exhaust Boot [ More info ] Unavailable
		895012 - BOOT-EXHAUST [ More info ] Unavailable
		895012A01 - Exhaust Boot Kit [ More info ] $26.03 2 In Stock.
#6	F85380	SPRING (1 required per assembly)
		24-F85380 - Spring, Idle Exhaust Boot [ More info ] $5.09 1 In Stock.
#7	F85772	CLAMP (1 required per assembly)
		54-F85772 - Clamp [ More info ] $5.98 3 In Stock.
#8	F1729	PLUG (2 required per assembly)
		19-F1729 - Plug, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#9	817931A 7	MOTOR LEG COVER, REAR (1 required per assembly) W/ILLUS 8 AND 13 ORIGINAL FORCE P/N A178145-3
		817931A 7 - COVER KIT-LEG,NLA [ More info ] Unavailable
#10	F1664	SPRING PIN (2 required per assembly)
		17-F1664 - Spring, Pin [ More info ] $2.40 $2.03 9 In Stock.
#11	F438962	(2 required per assembly) SHOCK MOUNT LOWER REAR
		F438962 - Shock Mount, NLA [ More info ] $16.00 $13.55 2 In Stock.
#12	F1263	(2 required per assembly) HEX SOCKET HD CAP SCREW, 5/16 - 18 X 9/16
		10-F1263 - Screw -ss [ More info ] $15.00 10+ In Stock.
#13	F178323	SEAL, MOTOR LEG (1 required per assembly)
		F178323 - Motor Leg Seal, NLA [ More info ] Unavailable
#14	F523133-2	MOTOR LEG (1 required per assembly)
		F523133-2 - Housing - Leg [ More info ] Unavailable
		1500-817983A 2 - Housing Kit, 20 Inch [ More info ] Unavailable
		1500-819432A 1 - Housing Kit-20 IN [ More info ] Unavailable
		1500-819432A 2 - Housing Kit-20 I,NLA [ More info ] Unavailable
#15	F338618-1	SEAL, GEAR SHIFT ROD (1 required per assembly)
		F338618-1 - SEAL [ More info ] Unavailable
		26-817472 - Seal [ More info ] $8.99 4 In Stock.
		18-0500 - Seal, 26-817472 [ More info ] $8.99 $8.32 Available to Order: Shipping delay up to 10 days.
#16	F2093	STOP NUT (2 required per assembly)
		11-F2093 - Nut, (.375-24) [ More info ] Unavailable
		11-34863 - Nut (3/8-24) [ More info ] Unavailable
		11-826709113 - Nut, (.375-24) Stainless Steel [ More info ] Unavailable
		11-8M0042636 - Nut - Brass , Priced Individually [ More info ] Unavailable
		118M0204726 - NUT-BRASS Note: Priced Individually [ More info ] $1.80 10 In Stock.
#17	F523881-2	LINK STEERING (1 required per assembly)
		F523881-2 - LINK-STEERING [ More info ] Unavailable
		F5H094 - Steering Link Kit [ More info ] $78.27 $66.30 10+ In Stock.
#18	F8038	PLAIN WASHER (2 required per assembly)
		12-F8038 - Washer [ More info ] Unavailable
		12-37828 - Washer, (.390 X .625 X .062) Stainless Steel [ More info ] $0.80 2 In Stock.
#19	F523300-1	SPRING (1 required per assembly)
		24-F523300-1 - Spring-Steering Link,NLA [ More info ] $8.61 10+ In Stock.
#20	F1280	PAN HD SCREW (1 required per assembly)
		10-F1280 - Screw -ss [ More info ] $0.55 $0.46 10+ In Stock.
		108M0129582 - Screw [ More info ] $0.61 Available to Order: Shipping delay up to 10 days.
#21	F8080	HELICAL SPRING LOCKWASHER (1 required per assembly)
		F8080 - Lock Washer - Priced Individually [ More info ] Unavailable
		13-26995 - Lock Washer - Priced Individually [ More info ] Unavailable
#22	F523930	RETAINER STUD (1 required per assembly)
		F523930 - Retainer, NLA [ More info ] Unavailable
#23	F523273	STUD STEERING BALL (1 required per assembly)
		F523273 - Steering Ball Stud [ More info ] $6.52 $5.53 10+ In Stock.
#24	F1696	HEX BOLT, 5/16 - 18 X 1-3/4 (4 required per assembly)
		10-F1696 - Screw SS [ More info ] $1.29 10+ In Stock.
		10-69267 - Screw [ More info ] $1.90 $0.38 10+ In Stock.
#25	F85350-1	TILT STOP PIVOT (2 required per assembly)
		F85350-1 - Pivot SS [ More info ] $16.77 10+ In Stock.
#26	F1666	SPRING BOWED WASHER (1 required per assembly)
		F1666 - Wave Washer - Priced Individually [ More info ] Unavailable
		13-69150 - Wave Washer - Priced Individually [ More info ] $3.79 10+ In Stock.
#27	F85541-1	TILT LOCK (1 required per assembly)
		F85541-1 - Tilt Lock [ More info ] Unavailable
		F85541-2 - LOCK-TILT [ More info ] $18.00 10 In Stock.
		823786 - Strap- Port, NLA [ More info ] $9.00 $7.62 2 In Stock.
#28	1400-817958A 6	STERN BRACKET (2 required per assembly)
		1400-817958A 6 - Bracket Kit -Stern, NLA [ More info ] $135.00 1 In Stock.
#29	F7012	STOP NUT (1 required per assembly)
		11-F7012 - Nut, Lock (1/2 - 20) [ More info ] $1.59 6 In Stock.
		11-28040 - Nut (1/2-20) [ More info ] Unavailable
		11-826708 17 - Nut, (.500-20) [ More info ] Unavailable
		11-898832 - Nut, (.500-20) [ More info ] $3.69 Available to Order: Shipping delay up to 10 days.
#30	F1593	HEX HD SCREW, 3/8 - 16 X 3 (2 required per assembly)
		F1593 - 10F2185 [ More info ] Unavailable
		10-F2185 - Screw, NLA [ More info ] $11.00 $9.32 9 In Stock.
#31	F178173	RETAINING RING (4 required per assembly)
		53-F178173 - Ring - Retaining, NLA [ More info ] $3.00 $2.54 10+ In Stock.
#32	F1904	PLAIN WASHER (2 required per assembly)
		12-F1904 - Washer, NLA [ More info ] Unavailable
#33	F1346	HEX NUT (2 required per assembly)
		11-F1346 - Hex Nut, 3/8 - 16 [ More info ] $0.44 2 In Stock.
		11-86226 - Nut (3/8-16) [ More info ] $2.21 10 In Stock.
		11-8M0204671 - NUT [ More info ] Unavailable
#34	F353480	STUD (2 required per assembly)
		F353480 - Stud, NLA [ More info ] $3.00 $2.54 10+ In Stock.
#35	F84074	CLAMP SCREW FOOT (2 required per assembly)
		F84074 - Foot [ More info ] $6.75 $5.71 10+ In Stock.
#36	F474073-1	CLAMP SCREW (2 required per assembly)
		F474073-1 - Screw - Stern [ More info ] Unavailable
		FA628073 - Screw Assembly, NLA [ More info ] Unavailable
#37	F8538	SPRING PIN (2 required per assembly)
		17-F8538 - Spring Pin, NLA [ More info ] $0.22 $0.18 10+ In Stock.
#38	F178208	RETAINING RING (2 required per assembly)
		53-F178208 - Ring - Retaining, NLA [ More info ] $1.50 $1.28 4 In Stock.
#39	F1710	PLAIN WASHER (2 required per assembly)
		12-F1710 - Washer, NLA [ More info ] Unavailable
#40	FA178962	SHOCK ABSORBER W/BUSHING (2 required per assembly)
		FA178962 - 55FS631962 [ More info ] Unavailable
		55-FS631962 - Shock Absorber, NLA [ More info ] Unavailable
		FS719962 - Shock Absorber [ More info ] $316.00 $267.65 1 In Stock.
#41	F178362	BEARING (2 required per assembly)
		F178362 - 23F449362 [ More info ] Unavailable
		23-F449362 - Bushing [ More info ] $9.89 3 In Stock.
#42	F1528	WELCH PLUG (1 required per assembly)
		19-F1528 - Plug, NLA [ More info ] $1.25 $1.06 8 In Stock.
#43	FA85019	KINGPIN (1 required per assembly) W/ILLUS. 42
		FA85019 - FS85019, NLA [ More info ] Unavailable
		FS85019 - Kingpin Assembly -For 20" long shaft engines only [ More info ] $12.99 $11.00 9 In Stock.
#44	F1669	(1 required per assembly) LOCK NUT
		11-F1669 - Nut (#6-32) [ More info ] $2.50 10+ In Stock.
		11-8M0207777 - NUT-SS [ More info ] Unavailable
#45	F369349	REVERSE LOCK
		F369349 - Reverse Lock, NLA [ More info ] $55.00 $46.58 10+ In Stock.
#46	F85300	REVERSE LOCK SPRING (1 required per assembly)
		24-F85300 - Spring, Reverse Lock, NLA [ More info ] $7.78 $6.59 10+ In Stock.
#47	F438169	BEARING (2 required per assembly)
		23-F438169 - Bushing [ More info ] Unavailable
		23-819493 - Bushing, NLA [ More info ] $2.39 10+ In Stock.
#48	F178632	SHAFT, SHOCK MOUNT LOWER (1 required per assembly)
		F178632 - Shaft,NLA [ More info ] Unavailable
#49	F523274	GREASE FITTING (1 required per assembly)
		22-F523274 - Grease Fitting, NLA [ More info ] $9.44 4 In Stock.
#50	F9052	PLUG (1 required per assembly)
		19-F9052 - Plug, NLA [ More info ] Unavailable
#51	F1711	SPRING BOWED WASHER (2 required per assembly)
		13-F1711 - Washer -bowed, NLA [ More info ] Unavailable
#52	F511125-2	TUBE, STEERING SUPPORT (1 required per assembly)
		F511125-2 - TUBE-STEERING [ More info ] Unavailable
		32-818066A 3 - Steering Tube Assembly [ More info ] Unavailable
#53	F178889	SHAFT, SHOCK MOUNT UPPER (1 required per assembly)
		F178889 - Shaft, NLA [ More info ] Unavailable
#54	F213274	GREASE FITTING (3 required per assembly)
		22-F213274 - Grease Fitting [ More info ] Unavailable
#55	F316599	SEAL, STEERING SUPPORT TUBE (1 required per assembly)
		25-F316599 - O Ring, Steering Tube [ More info ] $1.39 5 In Stock.
		25-48462 - O-ring, (.614 X .070) [ More info ] $1.80 4 In Stock.
#56	F84286-1	FRICTION WASHER (4 required per assembly)
		12-F84286-1 - Friction Washer, NLA [ More info ] $3.25 10+ In Stock.
#57	F529390	DECAL, REVERSE LOCK - USA (1 required per assembly)
		F529390 - F529390 - DECAL-REV LOCK [ More info ] Unavailable Replaced by -F529390-1
#58	F84011	WASHER (1 required per assembly)
		12-F84011 - Washer, NLA [ More info ] Unavailable
#59	817783A 5	SWIVEL BRACKET (1 required per assembly) W/ILLUS. 47 AND 54 ORIGINAL FORCE P/N A 369072-1
		817783A 5 - Swivel Bracket Kit, NLA [ More info ] Unavailable
#60	F369510	LINK REVERSE LOCK
		F369510 - LINK,NLA [ More info ] $34.99 $29.63 1 In Stock.
#61	F177350	REVERSE LOCK PIN (1 required per assembly)
		F177350 - Pin, Reverse Lock, NLA [ More info ] Unavailable
#62	F1744	SPRING PIN (1 required per assembly)
		17-F1744 - Pin, Spring [ More info ] Unavailable
		17-25319 - Pin, (.125 X 0.75 Inches) [ More info ] $5.09 10+ In Stock.
#63	F523280	NUT, STEERING SUPPORT TUBE (1 required per assembly)
		11-F523280 - Nut, Steering Support Tube,NLA [ More info ] Unavailable
#64	F9018	CAP (1 required per assembly)
		19-F9018 - Cap, NLA [ More info ] Unavailable
#65	FA438113	STERN BRACKET LOCK BAR (1 required per assembly) W/ILLUS. 66, 67 AND 68
		FA438113 - Bar Kit - Lock, NLA [ More info ] $53.33 $45.17 8 In Stock.
#66	F286461	SPRING, LOCK BAR HANDLE (1 required per assembly)
		24-F286461 - Spring, Lock Bar Handle [ More info ] $9.69 10+ In Stock.
#67	F433114	HANDLE, LOCK BAR (1 required per assembly)
		F433114 - Handle - Lock Bar [ More info ] Unavailable
		816517 - Lock Bar Handle [ More info ] $17.99 6 In Stock.
#69	F85037-1	STERN BRACKET PIVOT BOLT (1 required per assembly)
		10-F85037-1 - Bolt -Special, NLA [ More info ] $32.60 $27.61 10+ In Stock.
#70	F483884	BEARING (1 required per assembly)
		23-F483884 - Bearing, NLA [ More info ] $1.67 $1.42 10+ In Stock.
#71	F369364	REVERSE LOCK ARM (1 required per assembly)
		F369364 - Reverse Lock Arm [ More info ] $15.55 10+ In Stock.
#72	F1836	SPRING PIN (1 required per assembly)
		17-F1836 - Pin, Spring [ More info ] $4.30 10+ In Stock.
#73	F1014	COTTER PIN (1 required per assembly)
		F1014 - Cotter Pin - Priced Individually [ More info ] Unavailable
		18-26953 - Cotter Pin - Priced Individually [ More info ] $4.19 8 In Stock.
#74	F8094	PLAIN WASHER (1 required per assembly)
		F8094 - Washer SS [ More info ] $1.29 5 In Stock.
		12-40023 16 - Washer - Priced Individually [ More info ] $1.17 2 In Stock.
		128M0214930 - WASHER Note: Must be ordered in multiples of 5 [ More info ] $1.00 1 In Stock.
#75	F197813	BEARING (2 required per assembly)
		23-F197813 - Bushing -nyLiner [ More info ] Unavailable
		23-26856 - Bushing [ More info ] $4.19 Available to Order: Shipping delay up to 10 days.
#76	F369827	HANDLE AND SHAFT (1 required per assembly)
		F369827 - Handle and Shaft [ More info ] Unavailable
		817946A 2 - Lever Kit - Short [ More info ] $66.42 $56.26 3 In Stock.
#77	F1912	HEX HD SCREW, 10 - 24 X 1/2 (4 required per assembly)
		10-F1912 - Screw, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#78	F85779-1	BAFFLE, AIR INTAKE (1 required per assembly)
		F85779-1 - FK692779, NLA [ More info ] Unavailable
		FK692779 - Baffle Assembly, NLA [ More info ] Unavailable
#79	F1703	SPRING LOCKWASHER (2 required per assembly)
		F1703 - LockWasher - Priced Individually [ More info ] $0.30 3 In Stock.
		13-35048 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#80	F1871	HEX HD SCREW, 3/8 - 16 X 3/4 (4 required per assembly)
		F1871 - Screw [ More info ] Unavailable
		10-98261 - Screw [ More info ] $1.20 5 In Stock.
#81	F2030	HEX HD M. SCREW, 1/4 - 20 X 1-1/4 (6 required per assembly)
		10-F2030 - Screw -ss [ More info ] $3.39 10+ In Stock.
#82	F85606	KINGPIN CAP (1 required per assembly)
		F85606 - FK85606, NLA [ More info ] Unavailable
		FK85606 - Kingpin Cap Kit, NLA [ More info ] Unavailable
#83	A 85135 3	LEG COVER FRONT (1 required per assembly) W/ILLUS. 81
#84	F1822	HEX BOLT, 5/16 - 18 X 7/8 (4 required per assembly)
		10-F1822 - Screw -ss [ More info ] Unavailable
		10-28782 - Screw - Priced Individually [ More info ] $2.99 10+ In Stock.
#85	F8096	SPRING LOCKWASHER (4 required per assembly)
		F8096 - LockWasher - Priced Individually [ More info ] Unavailable
		13-53166 - LockWasher - Priced Individually [ More info ] $1.80 10+ In Stock.
#86	F85704	COUPLER, GEAR SHIFT ROD (1 required per assembly)
		F85704 - Gear Shift Rod Coupler [ More info ] Unavailable
#87	F438346	SHOCK MOUNT LOWER (1 required per assembly)
		F438346 - Lower Shock Mount [ More info ] $73.32 9 In Stock.
		803714T - Shock Mount [ More info ] $73.32 $62.11 10+ In Stock.
#88	F85615	GEAR SHIFT ROD UPPER (1 required per assembly)
		F85615 - F856151 [ More info ] Unavailable
		F85615-1 - Shift Rod, NLA [ More info ] Unavailable
#89	F85965	SHOCK MOUNT UPPER (2 required per assembly)
		F85965 - Shock Mount [ More info ] $89.99 $76.21 1 In Stock.
#90	F2108	LOCK NUT (2 required per assembly)
		11-F2108 - Nut (5/16-18) NLA [ More info ] $1.38 $1.17 10+ In Stock.
#91	F1987	PLAIN WASHER (1 required per assembly)
		F1987 - Washer - Priced Individually [ More info ] $0.25 10+ In Stock.
		12-34437 - Washer (5/16 In. I.d.) [ More info ] $2.89 Available to Order: Shipping delay up to 10 days.
#92	FA85355-1	WASHER (2 required per assembly) W/ILLUS. 93
		FA85355-1 - WASHER KIT,NLA [ More info ] Unavailable
#93	F2014	PLAIN WASHER (2 required per assembly)
		F2014 - Washer [ More info ] $0.49 3 In Stock.
		12-34931 - Washer, (.406 X .734 X .063 - Stainless Steel) [ More info ] $2.59 10+ In Stock.
#94	F439736	SEAL, EXHAUST TUBE (1 required per assembly)
		25-F439736 - Seal, NLA [ More info ] $22.99 10+ In Stock.
