Helms & Helm Fittings

132
®
HYDRAULIC HELMS:
HELM
SEAL KIT
HELM
PART
PART
DESCRIPTION
NUMBER      NUMBER
BAYSTAR 1.1 - FRONT MOUNT
HH4311-3           HP6032
BAYSTAR 1.4 - FRONT MOUNT
HH4314-3           HP6032
BAYSTAR 1.4 - SPORT TILT*
HH4315-3           HP6032
BAYSTAR 1.4 - SPORT PLUS TILT*
HH4316-3           HP6032
BAYSTAR PLUS 1.4 - FRONT MOUNT
HH4514-3           HP6032
BAYSTAR PLUS 1.4 - SPORT TILT*
HH4513-3           HP6032
BayStar Plus Helms offer superior overall performance to
BayStar due to an enhanced internal design.
For extra heavy duty/commercial vessels,
SeaStar Solutions' Capilano steering system
offers extremely rugged and reliable 'variable
flow' rear-mount helms and heavy duty brass
cylinders with stainless steel and bronze
mounting hardware.
*
2
H-20 and H-30 helms produced in 1978 and earlier use
Seal Kit #HS-01. 1979-date H-20 and H-30 helms use Seal Kit
*3
H-40 helms produced in 1978 and earlier use Seal Kit #HS-
03. 1979-date H-40 Helms use Seal Kit # HS-04.
BAYSTAR HELMS
CAPILANO HELMS
HYNAUTIC HELMS
HELM
SEAL KIT
HELM
PART
PART
DESCRIPTION
NUMBER      NUMBER
CAPILANO 1250V
CAPILANO 1275V
  HS5161
HELM
SEAL KIT
HELM
PART
PART
DESCRIPTION
NUMBER NUMBER
HYNAUTIC H-20 (3/4” SHAFT)
HYNAUTIC H-20 (3/4” SHAFT)
HYNAUTIC H-20 (1” SHAFT)
HYNAUTIC H-40 (3/4” SHAFT)
H-42-02       HS-03/HS-04*3
HYNAUTIC H-40 (1” SHAFT)
HYNAUTIC H-40 (3/4” SHAFT)
H-41-02       HS-03/HS-04*3
HYNAUTIC H-40 (1” SHAFT)
SEAL KITS FOR
HYNAUTIC RESERVOIRS:
RS-01: R-4/R-04, R-10, R-13, R-14 models.
SEAL KITS FOR OBSOLETE HYNAUTIC HELMS:
HS-05: H-50 series helms.
HS-06: H-60 series helms.
HS-08: H-80 series helms, before date code 8000.
HS-09: H-80 series helms, after date code 8000.
HS-10: H-100 & H-200 series helm pumps.
BayStar hydraulic steering is
brought to you by the
manufacturers of SeaStar®, the
most trusted name in pleasure
boat steering. BayStar allows you
to install all of the safety, reliability
and comfort of hydraulic steering
onto your boats rated to a MAXIMUM
of 150 HP. Combine this with a superior design rigid ISO quality
control, finest materials and precision manufacturing—BayStar
continues the tradition of bringing comfort and safety to boating.
* Refer to page 32-33 for additional tilt steering information.
