Yamaha Outboard

YAMAHA OUTBOARD APPLICATION CHARTS
69.9 Horsepower Yamaha
6 HP 1986 and Newer
8 HP 1986 and Newer
F6, F8 4Stroke 2001 and Newer
F9.9 4Stroke 2008 and Newer
7 Tooth Spline and Through Hub Exhaust
Length (ft/m) Current MPH/KPH Propeller Size Matl Blades Style Quicksilver P/N OEM P/N Hub System
14-17 / 4.2-5.2 8-17/ 14-27 8.5 X 7 RH AL 3 Black Diamond QA3804R Rubber Bushing
13-16 / 3.9-4.8 12-21 / 19-34 8.5 X 8 RH AL 3 Black Diamond QA3806R Rubber Bushing
8 Horsepower Yamaha
8 HP 197683
Pin Drive
Length (ft/m) Current MPH/KPH Propeller Size Matl Blades Style Quicksilver P/N OEM P/N Hub System
14-18 / 4.3-5.5 to 15 / to 24 8.25 X 7 RH AL 3 Black Diamond QA3178R Rubber Bushing
9.920 Horsepower Yamaha
9.9 HP 2Stroke 1984 and Newer
F9.9 4Stroke 20002007
15 HP 2Stroke 1984 and Newer
F15 4Stroke 2000 and Newer
F20 4Stroke All Years
8 Tooth Spline
Length (ft/m) Current MPH/KPH Propeller Size Matl Blades Style Quicksilver P/N OEM P/N Hub System
14-20 / 4.3-6.1 16-19 / 26-31 9 1/4 X 8 RH AL 3 Black Diamond QA3902R 683-45947-00-EL Rubber Bushing
14-19 / 4.3-5.8 19-24 / 31-39 9 1/4 X 9 RH AL 3 Black Diamond QA3906R 683-45945-00-EL Rubber Bushing
14-16 / 4.3-4.8 23-27 / 37-44 9 1/4 X 10 RH AL 3 Black Diamond QA3914R 683-45943-00-EL Rubber Bushing
to 14 / to 4.2 24+ / 39+ 9 1/4 x 11RH AL 3 Black Diamond QA3920R 683-45941-00-EL Rubber Bushing
1528 Horsepower Yamaha
15 HP 197683
W15 197683
20 HP 197678
25 HP 197779
28 HP 197678
Pin Drive
Length (ft/m)
Current MPH/KPH Propeller Size Matl Blades Style Quicksilver P/N OEM P/N Hub System
12-16 / 3.6-4.8 20-28 / 32-45 9 X 10 RH AL 3 Black Diamond QA3150R 651-45947-00-36 Rubber Bushing
12-14 / 3.6-4.3 25-32 / 40-52 9 1/4 X 11 RH AL 3 Black Diamond QA3152R 653-45941-01-36 Rubber Bushing
2030 Horsepower Yamaha
20 HP 199697
25 HP 1980 and Newer
F25 4Stroke 2000 and Newer
30 HP 1979 and Newer
F30 4Stroke 2001 and Newer
10 Tooth Spline
Length (ft/m)
Current MPH/KPH Propeller Size Matl Blades Style Quicksilver P/N OEM P/N Hub System
15-17 / 4.5-5.2 18-26 / 29-42 9 7/8 X 10 1/2 RH AL 3 Black Diamond QA3808R 664-45945-00-EL Rubber Bushing
14-16 / 4.3-4.8 19-28 / 31-45 9 7/8 X 11 1/4 RH AL 3 Black Diamond QA3810R 664-45947-01-EL Rubber Bushing
13-16 / 3.9-4.8 20-30 / 32-48 9 7/8 X 12 RH AL 3 Black Diamond QA3812R 664-45954-00-EL Rubber Bushing
to 15 / to 4.5 24-32 / 39-52 9 7/8 X 13 RH AL 3 Black Diamond QA3814R 664-45949-02-EL Rubber Bushing
YAMAHA OUTBOARD APPLICATION CHARTS
Quicksilver Propeller Guide
27
