Mercury/Mariner Outboard

MERCURY/MARINER OUTBOARD APPLICATION CHARTS
2.53.5 Horsepower Mercury/Mariner
2.5 3.5 Horsepower
2.5 HP 1990 & Newer
3 HP 1990 1992
3.3 HP 1993 & Newer
Pin Drive
Length (ft/m) Propeller Size Matl Blades Style Quicksilver P/N OEM P/N Hub System
All Purpose 7.4 X 6 RH Plastic 3 Black Diamond 48-8M0081592 48-815083A01 Pin Drive
All Purpose 7.4 X 7 RH Plastic 3 Black Diamond 48-8M0081591 48-815083A02 Pin Drive
46 Horsepower Mercury/Mariner
4 6 Horspower
4 5 HP 2Stroke 1987 & Newer
4, 5, 6 HP Stroke 1999 & Newer
12 Tooth Spline
Length (ft/m) Propeller Size Matl Blades Style Quicksilver P/N OEM P/N Hub System
All Purpose 7.8 X 9 RH AL 3 Black Diamond 48-8M0081239 48-812950A03 Rubber Bushing
All Purpose 7.8 X 8 RH AL 3 Black Diamond QA3184R 48-812950A02(2) Rubber Bushing
All Purpose 7.8 X 7 RH AL 3 Black Diamond QA3182R 48-812949A02(1) Rubber Bushing
All Purpose 7.9 X 6 RH AL 3 Black Diamond 48-8M0081238 48-812951A02 Rubber Bushing
(1) Standard with 4 Hp, 2-Stroke and FourStroke
(2) Standard with 5 and 6 Hp FourStroke
Mercury 75 (7.5HP) and 110 (9.8HP)
Mercury 75 (7.5HP) and 110(9.8) 19681984
8 Spline
1968 thru 1978 Thrust Hub 86665A 1 Spacer 11-64075A 1 Nut 11-46335 Washer 12-27025
1972 thru 1978 Nut 1164075A1
Length Current MPH Propeller Size Material Blades Style Quicksilver P/N OEM P/N
To 15' Up to 20 9 X 9 RH AL 2 Black Diamond 48-47922A10 48-47922A10
15-17 12-18 8-3/8 X 8 RH AL 3 Black Diamond N.L.A. N.L.A.
17 and up 10-16 8 3/4 X 7RH AL 3 Black Diamond N.L.A. N.L.A.
8 Horsepower Mercury/Mariner
8 HP 197684 Mariner
Pin Drive
Length (ft/m)
Current MPH/KPH Propeller Size Matl Blades Style Quicksilver P/N OEM P/N Hub System
14-18 / 4.2-5.5 to 15 / to 24 8 X 7 RH AL 3 Black Diamond QA3178R 82764 Rubber Bushing
8/9.9 Horsepower (4Stroke) Mercury/Mariner
8/9.9 (4Stroke) 2005 and newer
Std. gearcase only (Not Bigfoot)
12 Tooth Spline
Length (ft/m)
Current MPH/KPH Propeller Size Material Blades Style Quicksilver P/N OEM P/N Hub System
Kicker 8.7 x 5 RH Alum 4 Black Diamond QA2148R 48-812954A10 Rubber Bushing
16 + / 4.8 + to 12 / to 19 8.9 x 6.5 RH Alum 3 Black Diamond QA2150R 48-897610A10 Rubber Bushing
14-17 / 4.2-5.2 8-17 / 14-27 8.9 x 7.5 RH Alum 3 Black Diamond QA2154R 48-897614A10(1) Rubber Bushing
13-16 / 3.9-4.8 12-21 / 19-34 8.9 x 8.5 RH Alum 3 Black Diamond QA2158R 48-897618A10(2) Rubber Bushing
12-16 / 3.6-4.8 16-24 / 26-39 8.9 x 9.5 RH Alum 3 Black Diamond QA2160R 48-897620A10 Rubber Bushing
(1) Standard with 8 Hp FourStroke
(2) Standard with 9.9 Hp FourStroke
MERCURY/MARINER OUTBOARD APPLICATION CHARTS
14
