Yamaha Outboard (Cont.)

T2560 Horsepower Yamaha
T25 All Years
40 HP 1984 and Newer
F40 4Stroke 1999 and Newer
48 HP 19952000
50 HP (Excluding T50) 1984 & Newer
F50 4Stroke 1999 and Newer
55 HP 197695
60 HP 197691
F60 4Stroke 2002 and Newer
13 Tooth Spline
Length (ft/m) Current MPH/KPH Propeller Size Matl Blades Style Quicksilver P/N OEM P/N Hub System
House/Work to 16 / to 26 12 1/2 X 8 RH AL 3 Black Diamond QA2060X (1)
18+ / 5.5+ 16-20 / 26-32 12 1/4 X 9 RH AL 3 Black Diamond QA2062X 663-45956-01-EL (1)
17+ / 5.2+ 20-23 / 32-37 11 1/4 X 10 RH AL 3 Black Diamond QA2064X 6H5-45952-00-EL (1)
16-19 / 4.8-5.8 22-29 / 36-47 12 X 10 1/2 RH AL 3 Black Diamond QA2066X (1)
16-18 / 4.8-5.5 23-30 / 37-48 10 7/8 X 11 RH AL 3 Black Diamond QA2070X 663-45947-02-EL (1)
15-17 / 4.5-5.2 30-31 / 48-50 10 5/8 X 12 RH AL 3 Black Diamond QA2074X 6H5-45958-00-EL (1)
14-17 / 4.2-5.2 31-35 / 50-56 10 3/8 X 13 RH AL 3 Black Diamond QA2078X 6H5-45943-00-EL (1)
14-16 / 4.2-4.8 35-38 / 56-61 10 1/4 X 14 RH AL 3 Black Diamond QA2082X 663-45958-01-EL (1)
13-15 / 3.9-4.5 38-42 / 61-68 10 1/8 X 15 RH AL 3 Black Diamond QA2084X (1)
15-17 / 4.5-5.2 30-31 / 48-50 10.6 X 12 RH AL 4 Nemesis 48-8M8027511 (1)
14-17 / 4.2-5.2 31-35 / 50-56 10.3X 13 RH AL 4 Nemesis 48-8M8027512 (1)
14-16 / 4.2-4.8 35-38 / 56-61 10.1 X 14 RH AL 4 Nemesis 48-8M8027513 (1)
13-15 / 3.9-4.5 38-42 / 61-68 10.1 X 15 RH AL 4 Nemesis 48-8M8027514 (1)
to 14 / to 4.2 45-48 / 73-77 10 X 17 RH AL 3 Black Diamond QA2088X 663-45949-01-EL (1)
15-17 / 4.5-5.2 30-31 / 48-50 11 X 12 RH SS 3 Silverado QS5164X 663-45970-60-98 (1)
14-17 / 4.2-5.2 31-35 / 50-56 10 1/2 X 13 RH SS 3 Silverado QS5166X 663-45974-60-98 (1)
14-16 / 4.2-4.8 35-38 / 56-61 10 3/8 X 14 RH SS 3 Silverado QS5168X 663-45930-00-98 (1)
13-15 / 3.9-4.5 38-42 / 61-68 10 1/4 X 15 RH SS 3 Silverado QS5170X 663-45976-00-98 (1)
(1) Flo-Torq Reflex Propeller-All required hardware included
T50130 Horsepower Yamaha
T50 HP 4Stroke 1996 and Newer
60 HP 1992 and Newer
T60 HP 4Stroke 2003 and Newer
70 HP 1984 and Newer
75 HP 19942000
F75 4Stroke 2003 and Newer
80 HP 1977, 2000 and Newer
F80 HP 4Stroke 1999 and Newer
85 HP 199197
90 HP 1984 and Newer
F90 HP 4Stroke 2003 and Newer
F100 HP 4Stroke 2000 and Newer
115 HP 1984 and Newer
F115 HP 4Stroke 2000 and Newer
130 HP 1984 and Newer
15 Tooth Spline
Length (ft/m)
Current MPH/KPH Propeller Size Matl Blades Style Quicksilver P/N OEM P/N Hub System
House/Work to 14 / to 23 14 X 9 RH AL 3 Black Diamond QA2026X (1)
Pontoon/Work to 19 / to 31 14 X 10 RH AL 3 Black Diamond QA2028X (1)
Pontoon to 19 / to 31 14 X 10 RH AL 3 Black Diamond QA2828X (1)(2)
23'+ / 7.0+ to 21 / to 34 14 X 11 RH AL 3 Black Diamond QA2030X 6E5-45954-00-EL (1)
Pontoon to 21 / to 34 14 X 11 RH AL 3 Black Diamond QA2830X (1)(2)
20'+ / 6.1+ 19-27 / 31-44 14 X 13 RH AL 3 Black Diamond QA2032X 6E5-45949-00-EL (1)
Pontoon 19-27 / 31-44 14 X 13 RH AL 3 Black Diamond QA2832X (1)(2)
18-20 / 5.5-6.1 25-32 / 40-52 13 3/4 X 15 RH AL 3 Black Diamond QA2034X 6E5-45947-00-EL (1)
17-19 / 5.2-5.8 30-38 / 48-61 13 1/4 X 17 RH AL 3 Black Diamond QA2036X 6E5-45945-01-EL (1)
YAMAHA OUTBOARD APPLICATION CHARTS
