Sierra Marine Parts Catalog
SHIELDS SUPER PvC
SANITATION HOSE
Shields Super PVC Sanitation Hose is
smooth off white PVC with a vinyl helix.
It contains an anti-fungus /bacterial
agent to inhibit odor causing growth. It
is resistant to mild chemicals, saltwater,
and permeation. This hose is primarily
used for toilet to holding tank (self
draining lines) and holding tank pump
Bulk Pack
Dist. Pkg.
out. It has a five year limited warranty.
Bend
vac
Wt.
100' (30.5m)
50' (15.2m)
I.D.
mm
Radius
mm
Rating
"C"
Coil Code #
R/O Ctn. Code #
Do not use ethylene glycol based
16-144-1000
16-144-1006
1"
25.4
3
76.2
28
27
anti-freeze in hose. CAUTION - Do
1 1/2"
16-144-1120
16-144-1126
38.1
5
127.3
28
40
not use for potable water.
WARNING: Lines containing raw sewage should be plumbed to be self-draining.
SHIELDS vAC EXTRA HEAvY DUTY
- INDUSTRIAL GRADE
Shields Vac Extra Heavy Duty/Commercial
Grade Hose has a smooth cover and clear
FDA formula PVC with a white vinyl helix.
It is rated for full vacuum and is resistant
to mild chemicals and saltwater. This hose
is primarily used for bilge pump intake and
discharge, potable water tank fill, drains
(sinks, shower, and scupper), livewell
intake and drain, and sanitation (intake,
vent and pump out). This hose is utilized
for below the waterline connections.
Do not use ethylene glycol based
antifreeze in hose. Do not use in
pressurized water systems.
Bulk Pack
Dist. Pkg.
Bend
vac
Wt.
100' (30.5m)
50' (15.2m)
10' (3.1m)
I.D.
mm
Radius
mm
Rating
"C"
Coil Code #
R/O Ctn. Code #
Length Code #
/8"
16-146-0580
16-146-0586
15.9
3
76.2
28
15
--
5
/4"
16-146-0340
16-146-0346
19.1
3
76.2
28
16
--
3
16-146-1000
16-146-1006
1"
25.4
3
76.2
28
27
--
1 1/8"
16-146-1180
16-146-1186
28.6
4
101.6
28
25
--
1 1/4"
16-146-1140
16-146-1146
31.8
3
76.2
28
30
--
1 1/2"
16-146-1120
16-146-1126
38.1
4
101.6
28
40
--
16-146-2000
16-146-2003
2"
50.8
5
127.0
28
57
--
2 1/2"
16-146-2120
16-146-2123
63.5
7
177.8
28
74
--
16-146-3000
16-146-3003
3"
76.2
9
228.6
28
94
--
86
