Sierra Marine Parts Catalog
SHIELDS SANITATION HOSE
Shields Sanitation Hose is kink resistant and
flexible. It has an EPDM tube and cover, it is
wire reinforced and has two fabric plies. This
sanitation hose is resistant to toilet chemicals,
odor permeation, ozone, salt water and heat.
This hose is primarily used for toilet to holding
tank, holding tank pump out, and maximum
resistance to odor permeation.
Bulk Pack
Dist. Pkg.
Burst
Wt.
50' (15.2m)
12 1/2' (3.8m)
25" (7.6mm)
I.D.
mm
O.D.
Ply
Pressure
"C"
Coil Code #
Length Code #
Coil Code #
1 /16"
16-101-1000
16-101-1004
1"
25
2
200#
38
--
5
1 1/2"
1 55/64"
16-101-1120
16-101-1124
16-101-1125
38
2
150#
55
SHIELDS POLY X SANITATION HOSE
Shields Poly X Sanitation Hose has a lifetime warranty against odor permeation.
This ultimate sanitation hose combines the flexibility of a rubber hose with the
permeation resistance of polyurethane. Poly X can easily be slipped over most
fittings and the polyurethane cover is extremely abrasion resistant. This hose
has a glossy cover for easy clean up. This hose is primarily used for head to
holding tank and holding tank pump out.
The tube is made of smooth, white NBR and is chemical and detergent resistant.
The cover is comprised of smooth polyurethane and has a glossy cover. It is
heat, weather, ozone and abrasion resistant.
vac
Wt
50' (15.2m)
12 1/2' (3.8m)
10' (3.1m)
I.D.
mm
O.D.
mm
Ply
Rating
"C"
Code #
Code #
Code #
16-105-0340
16-105-0344
16-105-0343
3/4"
19
1 7/16"
2
38
1 21/64"
16-105-1000
16-105-1004
16-105-1003BX
1"
25
33.7
2
28
46
1 1/2"
1 27/32"
16-105-1120
16-105-1124
16-105-1123BX
38
46.8
2
28
66
SHIELDS SANITATION HOSE FITTINGS
Fiberglass reinforced nylon fittings designed to fit Series 101, Series 105 and Series 144
and 148 hoses without heating or special tools. For use in sanitation systems, deck drain
systems and water tank fill. Fittings are durable, chemical and fuel resistant, will not rust or
cause electrolysis.
Bulk
Blister Pack
Style
Code #
Code #
Hose I.D.
mm
Thread
N800-0340
Straight Male
--
/4"
19.1
/4" MP
3
3
N800-1000
Straight Male
--
1"
25.4
1" MP
N800-1180
Straight Male
--
1 1/8"
28.6
1" MP
N800-1140
Straight Male
--
1 1/4"
31.8
1 1/4" MP
N800-1120
Straight Male
18-800-1120
1 1/2"
38.1
1 1/2" MP
N801-1120
Straight Female
18-801-1120
1 1/2"
38.1
1 1/2" FP
N802-1120
90 Degree Male
18-802-1120
1 1/2"
38.1
1 1/2" MP
N803-1120
90 Degree Female
18-803-1120
1 1/2"
38.1
1 1/2" FP
N806-1120
Hose Tee
18-806-1120
1 1/2"
38.1
N/A
85
