Sierra Marine Parts Catalog: Internal Engine Components
CHEVY V-8
305/5.0L (Right Hand Rotation)
2 Piece Rear Seal
18-1266 ➁
HEAD GASKET SET
-- CONTAINS --
Description
Part #
Head Gasket
2BBL Carb Mounting Gasket
4BBL Carb Mounting Gasket
4BBL Carb Mounting Gasket
Intake Manifold Gasket
Valve Cover Gasket (2)
Valve Stem Seals (8)
Valve Stem Seals (16)
Distributor Mounting Gasket
CHEVY V-8 305/5.0L GEN II
1 Piece Rear Seal
18-1267 ➁
SHORT BLOCK GASKET SET
HEAD GASKET SET
-- CONTAINS --
Description
Part #
-- CONTAINS --
Description
Part #
Oil Pan Gasket
Head Gasket
Oil Drain Screw Gasket
2BBL Carb Mounting Gasket
Oil Filter Gasket
4BBL Carb Mounting Gasket
Forward Crankshaft Seal
4BBL Carb Mounting Gasket
Rear Crankshaft Seal
Intake Manifold Gasket Set
Rear Main Bearing Gasket
Valve Cover Gasket (2)
Water Pump Mounting Gasket
Valve Stem Seals (8)
Water Pump Plate Gasket
NSS
Valve Stem Seals (16)
Fuel Pump Plate Gasket
Distributor Mounting Gasket
Fuel Pump Mounting Gasket
CHEVY V-8
305/5.0L GEN II (Right Hand Rotation)
1 Piece Rear Seal
18-1263 ➀
SHORT BLOCK GASKET SET
18-1267 ➁
-- CONTAINS --
HEAD GASKET SET
Description
Part #
-- CONTAINS --
Description
Part #
Oil Drain Screw Gasket
Head Gasket
Oil Filter Gasket
2BBL Carb Mounting Gasket
Forward Crankshaft Seal
4BBL Carb Mounting Gasket
Rear Main Bearing Gasket
4BBL Carb Mounting Gasket
Water Pump Mounting Gasket
Intake Manifold Gasket Set
Water Pump Backing Plate Gasket 18-0893
Valve Cover Gasket (2)
Water Pump Plate Gasket
NSS
Valve Stem Seals (8)
Fuel Pump Plate Gasket
Valve Stem Seals (16)
Fuel Pump Mounting Gasket
Distributor Mounting Gasket
Timing Chain Cover Gasket
572
➀ Does not include oil pan gasket
➁ Does not include intake and/or exhaust maniflold gaskets
NSS Not Sold Separately
