Sierra Marine Parts Catalog: Yamaha

< Previous Page  Next Page >
Figure
Figure
#
Description
Part #
O.E.M. #
Qty.
#
Description
Part #
O.E.M. #
Qty.
Gearcase 50-75 HP 3 Cyl 1979-2003
49
Bolt
--
97395-10070-00
1
1
Housing, Gearcase
--
6J9-45301-02-ek
1
50
Washer
--
92990-10100-00
1
2
plate, Shift rod Cover
--
6e5-45321-00-00
1
51
Washer
--
92990-10100-00
1
3
Bolt, Shift rod Cover
--
97395-06020-00
3
52
Trim Tab
18-6035
6J9-45371-01-00
1
4
Washer
--
90209-06M04-00
3
53
Bolt, Trim Tab
--
90105-10M00-00
1
5
o-ring, plate
--
93210-58677-00
1
54
Gear pinion
--
6G5-45551-01-00
1
6
Shift rod Assembly
--
6G5-44150-01-00
1
55
Nut, pinion
--
90170-16M01-00
1
7
Circlip
--
99001-08600-00
1
56
Shim (0.10mm)
--
6G5-45567-01-10
Ar
8
Bearing, Needle
--
90250-08M07-00
1
Shim (0.12mm)
--
6G5-45567-01-12
Ar
9
Sleeve, Drive Shaft
--
6G5-45536-01-00
1
Shim (0.15mm)
--
6G5-45567-01-15
Ar
10
Washer
--
90209-33M13-00
1
Shim (0.18mm)
--
6G5-45567-01-30
Ar
11
Spring, Compression
--
90501-05M64-00
Ar
Shim (0.30mm)
--
6G5-45567-01-40
Ar
12
Collar
--
90387-33M00-00
1
Shim (0.40mm)
--
6G5-45567-01-50
Ar
13
Washer
--
90209-33M13-00
1
Shim (0.50mm)
--
6G5-45567-01-10
Ar
14
Washer
--
90209-33M12-00
1
57
Bearing, Forward Gear
--
93332-00V3-00
1
15
Drive Shaft (long)
--
6G5-45501-01-00
1
58
Bearing, Needle
--
93315-425V3-00
2
Drive Shaft (x-long)
--
6G5-45501-21-00
1
59
Gear, Forward
--
6G5-45631-00-00
1
16
Key, Impeller
--
90280-04M05-00
1
60
Shifter
--
6e5-45641-01-00
1
17
o-ring, Housing
--
93210-54534-00
1
61
Ball, Detent
--
93507-32031-00
1
18
Bearing, Tapered
--
93341-930U0-00
1
62
Ball, Detent
--
93507-32031-00
1
19
Shim (0.10mm)
--
6e5-45587-01-10
Ar
63
Slide, Shift
--
6e5-45634-01-00
1
Shim (0.12mm)
--
6e5-45587-01-12
Ar
64
Ball, Detent
--
93503-16010-00
1
Shim (0.15mm)
--
6e5-45587-01-15
Ar
65
Ball, Detent
--
93503-16010-00
1
Shim (0.18mm)
--
6e5-45587- 01-18
Ar
66
Ball, Detent
--
93511-32027-00
1
Shim (0.30mm)
--
6e5-45587-01-30
Ar
67
Spring, Compression
--
90501-16M37-00
1
Shim (0.40mm)
--
6e5-45587-01-40
Ar
68
Ball, Detent
--
93511-32027-00
1
Shim (0.50mm)
--
6e5-45587-01-50
Ar
69
Clutch, Dog
--
6e5-45633-01-00
1
20
Bearing, Needle
--
93315-430V5-00
1
70
Cross pin, Clutch
--
90250-08M07-00
1
21
Housing, Bearing
--
6e5-45331-00-94
1
71
retainer, Cross pin
--
6e5-45633-01-00
1
22
Bolt, Bearing Housing
--
97395-08025-00
4
72
Shaft, propeller
--
6J9-45611-01-00
1
23
Washer
--
92990-08600-00
4
73
Washer, Thrust
--
90201-30M92-00
1
24
Seal, Drive Shaft
18-0265
93101-28M16-00
2
74
Gear, reverse
--
6G5-45571-02-00
1
25
Cover, oil Seal
--
6e5-45344-00-00
1
75
Shim (0.10mm)
--
6G5-45577-02-10
Ar
26
Gasket, Wear plate
18-0244
6e5-44315-A0-00
1
Shim (0.12mm)
--
6G5-45577-02-12
Ar
27
Wear plate
18-3345
6G5-44323-00-00
1
Shim (0.15mm)
--
6G5-45577-02-15
Ar
28
Impeller
18-3071
6e5-44352-00-00
1
Shim (0.18mm)
--
6G5-45577-02-18
Ar
29
Insert, Water pump
--
6e5-44322-00-00
1
Shim (0.30mm)
--
6G5-45577-02-30
Ar
30
o-ring, Water pump
18-7485
93210-86M38-00
1
Shim (0.40mm)
--
6G5-45577-02-40
Ar
31
o-ring, Water pump
18-7483
93210-37M67-00
1
Shim (0.50mm)
--
6G5-45577-02-50
Ar
32
pin, Water pump Housing
--
93606-12019-00
2
76
Washer, Thrust
--
6G5-45576-00-00
1
33
Housing, Water pump
18-3170
6e5-44311-00-00
1
77
Bearing, reverse Gear
--
93306-209U0-00
1
34
Damper, Water Seal
--
6e5-44365-00-00
1
78
o-ring, Bearing Housing
18-0275
93210-97M55-00
1
35
Cover, pump Housing
--
6e5-44312-00-00
1
79
Bearing Housing Assembly
--
6J9-45332-00-94
1
36
Bolt, Water pump
--
97080-08045-00
4
80
Key, Bearing Housing
--
90282-04010-00
1
37
Washer
--
90209-08M02-00
4
81
Bearing, Needle
--
93315-430U8-00
1
38
Nipple, Hose
--
6e5-45378-00-00
1
82
Seal, prop Shaft
18-0266
93101-30M17-00
2
39
Drain,plug Lower
18-2374
688-45341-00-00
1
83
Washer, Tab
--
9G5-45383-01-00
1
40
Gasket, Drain plugs
--
90430-08020-00
2
84
Nut, Cover
--
6G5-45384-00-00
1
41
Drain plug Upper
--
90340-08M04-00
1
85
Washer, Thrust
--
6e5-45987-00-00
1
42
Gasket, Drain plugs
--
90430-08020-00
2
86
Spacer, prop
18-4274
688-45997-01-00
1
43
pin, Locating
--
93608-12M05-00
2
87
Washer, prop
--
92990-18200-00
1
44
Cover, Water Inlet (port)
--
6J9-45214-00-00
1
88
Nut, prop
18-3726
90171-18M04-00
1
45
Cover, Water Inlet (Stbd)
--
6J9-45215-00-00
1
89
pin, Cotter
18-3735
91490-40030-00
1
46
Screw, Water Inlet
--
90142-05M04-00
1
90
Gear Housing Seal Kit
18-2794-1
6G5-W0001-21-00
1
47
Nut, Water Inlet
--
90185-05002-00
1
91
Water pump repair Kit
18-3311
6G5-W0078-00-00
1
48
Bolt
--
97395-10070-00
1
Ar
As required
465
