Sierra Marine Parts Catalog
SHIELDSAUST-C
Now double the ozone resistance required by SAEJ2006
Shieldsaust � C Hose has a black synthetic rubber tube and cover. It is reinforced with double wire helix imbedded
between plies of synthetic cord and is abrasion resistant. It is resistant to exhaust fumes, ozone, mild chemicals,
antifreeze, and saltwater. This hose is primarily used for wet exhaust connections with significant bends, engine
intake and scupper lines. The temperature ranges from -20�F to + 200�F continuous, +250�F intermittent. The hose
now has double the ozone resistance required by SAEJ2006. This hose meets SAE J2006 Type R2 standards.
50' (15.2m)
12 1/2' (3.8m)
6 1/4' (1.9m)
Wt.
Coil
Length
Length
I.D.
mm
O.D.
Ply
"C"
Code #
Code #
Code #
/4"
1 1/8"
16-252-0340
16-252-0344
16-252-0341
19
2
27
3
1 11/32"
16-252-1000
16-252-1004
16-252-1001
1"
25
2
33
1 1/4"
16-252-1140
16-252-1144
16-252-1141
32
1 39/64"
2
45
1 1/2"
1 15/16"
16-252-1120
16-252-1124
16-252-1121
38
2
70
1 5/8"
2 3/32"
16-252-1580
16-252-1584
16-252-1581
42
2
80
1 3/4"
2 7/32"
16-252-1340
16-252-1344
16-252-1341
45
2
85
1 7/8"
2 21/64"
16-252-1780
16-252-1784
16-252-1781
48
2
91
2 7/16"
16-252-2000
16-252-2004
16-252-2001
2"
51
2
95
2 1/8"
2 9/16"
16-252-2184
54
2
100
--
--
2 1/4"
2 23/32"
16-252-2140
16-252-2144
16-252-2141
58
2
107
2 3/8"
2 51/64"
16-252-2380
16-252-2384
16-252-2381
60
2
110
2 1/2"
2 59/64"
16-252-2120
16-252-2124
16-252-2121
63
2
115
2 3/4"
3 3/16"
16-252-2340
16-252-2344
16-252-2341
70
2
126
2 7/8"
3 5/16"
16-252-2780
16-252-2784
16-252-2781
73
2
137
3 7/16"
16-252-3000
16-252-3004
16-252-3001
76
2
143
3"
3 1/8"
3 19/32"
16-252-3180
16-252-3184
16-252-3181
80
2
150
3 1/2"
4 1/16"
16-252-3120
16-252-3124
16-252-3121
90
2
200
4 9/16"
16-252-4000
16-252-4004
16-252-4001
4"
102
2
231
4 1/8"
4 11/16"
16-252-4184
16-252-4181
105
2
238
--
4 1/2"
5 1/8"
16-252-4124
16-252-4121
114
2
278
--
5 9/16"
16-252-5000
16-252-5004
16-252-5001
5"
127
2
300
6 9/16"
16-252-6000
16-252-6004
16-252-6001
6"
152
2
394
8 11/16"
16-252-8004
16-252-8001
8"
203
2
607
--
This certification provides unbiased,
third party confirmation worldwide that
these Shields hoses meet the highest
s t a n d a r d s o f p r o d u c t i o n q u a l i t y.
Certification ensures the proper level of product
safety and inspires user confidence.
73
