Sierra Marine Parts Catalog
Standard Toggle Switches
� Non-corrosive plastic construction
� Brass blade terminals, silver contacts
� 15/32" L x 15/32"-32 mounting stem
Rated: 20 amps @12 VDC
*TG4002252
*TG4004252
*TG4005252
*TG4003252
ON-OFF SPST
ON-OFF-ON SPDT
MOM ON-OFF-MOM ON SPDT
MOM ON-OFF SPST
**TG40490
*TG4016252
*TG4046252
*TG40492
*TG4045252
ON-OFF-MOM ON
MOM ON-OFF-MOM ON
ON(1)-OFF-ON(1&2)
ON-OFF-ON DPDT
SPDT
DPDT
DPDT
Illuminated Toggle Switches
� Non-corrosive plastic construction
� Illuminates white when panel lights are ON, changes to red when switch is ON
� Brass blade terminals, silver contacts
� 15/32" L x 15/32"-32 mounting stem
Rated: 20 amps @12 VDC
**TG40060
**TG40070
**TG40080
**TG40090
*TG40062
*TG40072
*TG40082
*TG40092
ON-OFF SPST
ON-OFF-ON SPDT
MOM ON-OFF SPST
MOM ON-OFF-MOM ON SPDT
Tip Lit Toggle Switches
� Lights through tip of handle
� Non-corrosive plastic construction
� Illuminates white when panel lights are ON, changes to red when switch is ON
� Brass blade terminals, silver contacts
� 15/32" L x 15/32"-32 mounting stem
Rated: 20 amps @12 VDC
**TG40310
**TG40300
**TG40320
*TG40312
*TG40302
*TG40322
MOM ON-OFF SPST
ON-OFF SPST
ON-OFF-ON SPDT
**TG19520
**TG19530
**TG40330
**TG40340
*TG19522
*TG19532
*TG40332
*TG40342
MOM ON-OFF-MOM ON DPDT
ON-OFF-ON DPDT
MOM ON-OFF-MOM ON SPDT
ON-OFF-MOM ON SPDT
Weather Resistant Toggle Switch
ON-OFF-ON SPDT
� IIluminates red in "on 1" position
� Illuminated white in "off" or "on 2" position
� O-ring seal in bushing seals out moisture and dirt
� Can be wired for independent or dependent illumination
**TG40010
Rated: 20 amps @ 12 VDC
*TG40012
41
*BULK - 100 pcs. per carton
**CLAMSHELL
