Parts for Mercury Marine Model 1500 150 HP Bottom Cowl & Shift Linkage
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 2115-3919 | COWL, BOTTOM (1 required per assembly) UNITED STATES 3751849 AND BELOW AUSTRALIA 8013389 AND BELOW CANADA 7024372 AND BELOW |
 |
|
2115-3919 - BOTTOM COWL,NLA [ More info ] Unavailable |
| #1 | 2115-5269 | COWL, BOTTOM (1 required per assembly) UNITED STATES 3751850 THRU 4602011 AUSTRALIA 8013390 THRU 8034895 CANADA 7024373 THRU 7093097 |
|
2115-5269 - BOTTOM COWL [ More info ] Unavailable |
|
|
2115-6462 - BOTTOM COWL [ More info ] Unavailable |
|
|
2115-7719A 1 - BOTTOM COWL [ More info ] Unavailable |
|
|
|
2115-8963A 1 - BOTTOM COWL,NLA [ More info ] Unavailable |
| #1 | 2115-6462 | COWL, BOTTOM (1 required per assembly) UNITED STATES 4602012 AND UP CANADA 7093038 AND UP |
| #2 | 52862A 2 | DRIP TRAY ASSEMBLY, BOTTOM COWL (1 required per assembly) |
|
|
52862A 2 - DRIP TRAY ASSY,NLA [ More info ] Unavailable |
| #3 | 37940 | PAD, SOUND - DRIP TRAY (1 required per assembly) |
|
|
37940 - Sound Pad, NLA [ More info ] Unavailable |
| #4 | 10-48408 | SCREW, DRIP TRAY TO BOTTOM COWL (1/2") (4 required per assembly) |
  |
|
10-48408 - Screw - Priced Individually [ More info ]
|
| #5 | 32-34395A 1 | HOSE, DRIP TRAY TO BOTTOM COWL (8") (1 required per assembly) |
|
32-34395A 1 - Hose [ More info ] Unavailable |
|
  |
32-99127109 - TUBING-57 INCH [ More info ] Unavailable |
|
  |
32-830756109 - Hose, 57 Inch [ More info ] Unavailable |
|
  |
32-8M0047428 - Hose -57 Inch [ More info ] Unavailable |
|
  |
|
32-8M0108355 - Hose, 57 Inch [ More info ]
|
| #6 | 39616 | BOOT, CONTROL CABLES - BOTTOM COLW (1 required per assembly) |
|
|
39616 - Control Cable Boot, NLA [ More info ] Unavailable |
| #7 | 76369 | SPACER, BOTTOM COWL (COWL FRONT COVER) (1 required per assembly) |
  |
|
76369 - Spacer, NLA [ More info ] Unavailable |
| #8 | 10-48591 | SCREW, SPACER TO BOTTOM COWL (1/2") (2 required per assembly) |
  |
|
10-48591 - Screw - Priced Individually [ More info ]
|
| #9 | 37637 | BOOT, FUEL CONNECTOR - BOTTOM COWL (1 required per assembly) |
|
|
37637 - Fuel Connector Boot, NLA [ More info ] Unavailable |
| #10 | 37445 | SUPPORT, WIRING HARNESS - BOTTOM COWL (1 required per assembly) |
|
|
37445 - Support, NLA [ More info ]
|
| #11 | 10-37990 | SCREW, SUPPORT TO BOTTOM COWL (1 3/4") (1 required per assembly) UNITED STATES 4121434 AND BELOW AUSTRALIA 8028039 AND BELOW CANADA 7048782 AND BELOW |
|
10-37990 - Screw, NLA [ More info ] Unavailable |
|
  |
|
10-69029 - Screw, NLA [ More info ]
|
| #11 | 10-31471 | SCREW, SUPPORT TO BOTTOM COWL (3 1/4") (1 required per assembly) UNITED STATES 4121434 AND BELOW AUSTRALIA 8028039 AND BELOW CANADA 7048782 AND BELOW |
|
|
10-31471 - Screw [ More info ]
|
|
|
10-88488 - Screw, NLA [ More info ]
|
| #12 | 11-46887 | NUT, SUPPORT SCREW (2 required per assembly) UNITED STATES 4121434 AND BELOW AUSTRALIA 8028039 AND BELOW CANADA 7048782 AND BELOW |
|
11-46887 - Nut, (1/4-28) [ More info ] Unavailable |
|
  |
|
11-20184 - Nut, (1/4-28x7/32) [ More info ]
|
| #11 | 10-69029 | SCREW, SUPPORT TO BOTTOM COWL (1 3/4") (2 required per assembly) UNITED STATES 4121435 AND UP AUSTRALIA 8028040 AND UP CANADA 7048783 AND UP |
| #14 | 52889 | NOZZLE, TELL TALE HOSE TO BOTTOM COWL (1 required per assembly) |
  |
|
52889 - Nozzle, NLA [ More info ]
|
| #16 | 22-25885 | ELBOW, TELL TALE HOSE TO EXHAUST COVER (1 required per assembly) |
|
22-25885 - Elbow - Priced Individually [ More info ] Unavailable |
|
|
22-99664 - Elbow [ More info ] Unavailable |
|
|
22-99664 1 - Elbow [ More info ] Unavailable |
|
  |
|
22-99664 2 - Elbow [ More info ]
|
| #17 | 60304A15 | SHIFT SHAFT ASSEMBLY, UPPER (SHORT SHAFT) (1 required per assembly) UNITED STATES 4403387 THRU 4602011 |
|
60304A15 - SHAFT ASSY [ More info ] Unavailable |
|
|
60304A33 - Shift Shaft Assembly [ More info ] Unavailable |
|
|
60304A45 - SHAFT ASSY [ More info ] Unavailable |
|
|
|
60304A55 - Shaft Assembly, NLA [ More info ] Unavailable |
| #17 | 60304A16 | SHIFT SHAFT ASSEMBLY, UPPER (LONG SHAFT) (1 required per assembly) UNITED STATES 4403387 THRU 4602011 |
|
60304A16 - SHAFT ASSY [ More info ] Unavailable |
|
|
60304A34 - Shift Shaft [ More info ] Unavailable |
|
|
60304A44 - SHAFT ASSY [ More info ] Unavailable |
|
  |
|
60304A54 - Upper Shift Shaft Assembly [ More info ] Unavailable |
| #18 | 23-26600 | BUSHING, SHIFT SHAFT (1 required per assembly) UNITED STATES 4403387 THRU 4602011 |
|
|
23-26600 - Bushing, NLA [ More info ]
|
| #19 | 55692 | COUPLING, SHIFT SHAFT (1 required per assembly) UNITED STATES 4403387 THRU 4602011 |
|
55692 - Coupling , Priced Individually [ More info ] Unavailable |
|
  |
|
93960A 1 - Coupling Assembly [ More info ]
|
| #17 | 60304A45 | SHIFT SHAFT ASSEMBLY, UPPER (SHORT SHAFT) (1 required per assembly) UNITED STATES 4602012 AND UP CANADA 7093038 AND UP |
| #17 | 60304A44 | SHIFT SHAFT ASSEMBLY, UPPER (LONG SHAFT) (1 required per assembly) UNITED STATES 4602012 AND UP CANADA 7093038 AND UP |
| #20 | 48047A 1 | LINK ROD ASSEMBLY (1 required per assembly) |
|
|
48047A 1 - Link Assembly [ More info ]
|
  |
|
73402 - Link, NLA [ More info ]
|
| #21 | 12-35462 | WASHER, LINK ROD (2 required per assembly) |
  |
|
12-35462 - Washer, (.2656 X .625 X .0625) Stainless Steel [ More info ]
|
| #22 | 11-35045 | NUT, LINK ROD (1 required per assembly) |
  |
11-35045 - Nut (1/4-28) [ More info ] Unavailable |
|
  |
|
11-826709109 - Nut, (.250-28) Stainless Steel [ More info ]
|
| #23 | 13-29720 | WASHER, WAVE - LINK ROD (1 required per assembly) |
  |
|
13-29720 - Wave Washer - Priced Individually [ More info ]
|
| #24 | 52732 | BRACKET, ANCHOR - CONTROL CABLES (1 required per assembly) |
|
|
52732 - Control Cables Anchor Bracket [ More info ]
|
|
52732A 4 - Bracket [ More info ] Unavailable |
|
|
|
52732A 6 - Bracket Kit, NLA [ More info ] Unavailable |
| #25 | 39519 | CAP, BARREL RETAINER - ANCHOR BRACKET (1 required per assembly) |
  |
|
39519 - Cup [ More info ]
|
| #26 | 39618 | LEVER, NYLON - SHIFT CABLE LOCKING (1 required per assembly) |
  |
39618 - Shift Cable Locking Lever, Nylon [ More info ] Unavailable |
|
  |
|
87609A 1 - Lever Kit [ More info ]
|
  |
|
65799T - Locking Lever to Cover Link, Old Style [ More info ]
|
| #27 | 17-47175 | PIN, LOCKING LEVER AND COVER FASTENING (3 required per assembly) |
|
|
17-47175 - Pin - Priced Individually [ More info ]
|
| #28 | 39667 | COVER, NYLON - SHIFT CABLE (1 required per assembly) |
|
|
39667 - Shift cable Cover, Nylon, NLA [ More info ] Unavailable |
| #29 | 65799 | LINK, LOCKING LEVER TO COVER (1 required per assembly) |
|
|
65799 - Lever to Cover Link [ More info ]
|
| #30 | 10-24234 | SCREW, ANCHOR BRACKET TO CYLINDER BLOCK (1") (3 required per assembly) |
|
10-24234 - Screw - Priced Individually [ More info ] Unavailable |
|
  |
|
10-35386 - Screw - Priced Individually [ More info ]
|
| #31 | 24-20099 | SPRING, LINK ROD TO GUIDE BLOCK (1 required per assembly) |
  |
|
24-20099 - Spring - Priced Individually [ More info ]
|
| #32 | 37896 | GUIDE BLOCK, LINK ROD (1 required per assembly) |
  |
|
|
| #33 | 52100 | WEAR PLATE, LINK ROD (1 required per assembly) |
  |
|
52100 - Wear Plate [ More info ]
|
| #34 | 38279 | LATCH, CONTROL CABLE FASTENING - ANCHOR BRACKET (1 required per assembly) |
|
38279 - Latch [ More info ] Unavailable |
|
  |
|
8M0036768 - Latch [ More info ]
|
