Parts for Mercury Marine 1150 Hydraulic Pump & Control Panel

Revise Search: All Models > 1150 > 3525441 - 4855152 (USA) > Hydraulic Pump & Control Panel

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#	55642A 7	CONTROL PANEL ASSEMBLY, COMPLETE (1 required per assembly)
		55642A 7 - Panel Assembly [ More info ] Unavailable
		55642A13 - Control Panel Assembly [ More info ] Unavailable
#1	45060A 7	PUMP ASSEMBLY, Hydraulic (1 required per assembly)
		45060A 7 - OB BULTN 82-8 [ More info ] Unavailable
#3	10-28634	SCREW, (.375-16), FILLER (1 required per assembly)
		10-28634 - Drain Screw ONLY, Priced Individually [ More info ] Unavailable
		10-79953 - Drain Screw ONLY, Priced Individually [ More info ] Unavailable
		10-79953A 2 - Drain Screw Kit [ More info ] Unavailable
		10-79953Q 2 - Screw Kit - Priced Individually [ More info ] Unavailable
		10-79953Q04 - Screw Kit - Priced Individually [ More info ] $7.49 10+ In Stock.
		18-2244 - Plug Kit, 10-79953A2 [ More info ] $3.79 10+ In Stock.
		10-79953K04 - Drain Screw - Priced Individually [ More info ] $8.19 6 In Stock.
#4	12-20260	WASHER, SEALING (1 required per assembly)
		12-20260 - Sealing Washer [ More info ] Unavailable
		12-19183 - Washer (3/8 Inch Screw) [ More info ] Unavailable
		12-19183 2 - Washer - Priced Individually [ More info ] Unavailable
		12-19183 3 - Seal -Blue - Priced Individually [ More info ] Unavailable
		12-8M0187157 - SEAL-BLUE, Sold Individually [ More info ] $1.49 10+ In Stock.
		18-2945-9 - Gasket 12-19183 2-Pack [ More info ] $2.41 10+ In Stock.
		12-19183Q02 - Seals, Pack of 4 (yes this is actually a pack of 4) [ More info ] $6.69 10+ In Stock.
		12-19183K02 - Seal, Pack of 4 [ More info ] $7.29 6 In Stock.
		12-02108-1 - Drain Gasket (1 piece) [ More info ] $1.20 $0.85 10+ In Stock.
#5	10-38257	SCREW, VENT (1 required per assembly)
		10-38257 - Screw, NLA [ More info ] Unavailable
		10-62269 - Screw, NLA [ More info ] Unavailable
#6	37-55901	DECAL, INSTRUCTION (1 required per assembly)
		37-55901 - DECAL,NLA [ More info ] Unavailable
#7	32979	LEAD, Battery (POSITIVE) (1 required per assembly)
		32979 - Battery Lea, NLA [ More info ] Unavailable
#8	32988	LEAD, Battery (NEGATIVE) (1 required per assembly)
		32988 - Battery Lea, NLA [ More info ] Unavailable
#9	45336	PLATE, MANIFOLD (1 required per assembly)
		45336 - Plate [ More info ] $32.80 8 In Stock.
#10	45197A 2	VALVE ASSEMBLY, Control (1 required per assembly)
		45197A 2 - Valve Assembly, NLA [ More info ] Unavailable
#11	25-45254	O-RING, CONTROL VALVE TO MANIFOLD PLATE (3/4" O.D.) (1 required per assembly)
		25-45254 - O-Ring, Control Valve (3/4 O.d.) [ More info ] $1.99 10+ In Stock.
#12	25-21720	O-RING, CONTROL VALVE TO MANIFOLD PLATE (1/2" O.D.) (1 required per assembly)
		25-21720 - O-Ring - Priced Individually [ More info ] Unavailable
		25-48171 - O-Ring - Priced Individually [ More info ] $1.70 8 In Stock.
		18-7168-9 - O-Ring (PK5) 202893, 25-48171 [ More info ] $5.64 Available to Order: Shipping delay up to 10 days.
#13	25-45253	O-RING, CONTROL VALVE TO MANIFOLD PLATE (5/8" O.D.) (2 required per assembly)
		25-45253 - O-Ring, Control Valve (5/8 O.D.) [ More info ] $1.60 Available to Order: Shipping delay up to 10 days.
		18-7165-9 - O-Ring (PK5) , 0304174 [ More info ] $10.38 Available to Order: Shipping delay up to 10 days.
#14	10-56500	SCREW, (.250-28 x 1.250) (4 required per assembly)
		10-56500 - Screw, NLA [ More info ] $2.89 $1.63 10+ In Stock.
#15	13-26992	LOCKWASHER, (.250) Stainless Steel (4 required per assembly)
		13-26992 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#16	22-38609	PLUG, CONTROL VALVE (3/8-24") (2 required per assembly)
		22-38609 - Plug [ More info ] $18.59 Available to Order: Shipping delay up to 10 days.
#17	22-46008	PLUG, CONTROL VALVE (1/2-20") (2 required per assembly)
		22-46008 - Plug [ More info ] $4.49 $3.60 10+ In Stock.
#18	45325	HARNESS ASSEMBLY (1 required per assembly)
		45325 - Connector [ More info ] Unavailable
		45325A 1 - Connector Assembly, NLA [ More info ] $31.99 $27.09 10+ In Stock.
#19	45559	TERMINAL BLOCK, HYDRAULIC PUMP (1 required per assembly)
		45559 - Terminal Block [ More info ] $1.99 $1.68 6 In Stock.
#20	10-35519	SCREW, (#10-16 x .500) (2 required per assembly)
		10-35519 - Screw, NLA [ More info ] $1.80 $1.52 10+ In Stock.
#21	10-30663	SCREW, (#10-16 x .380) (2 required per assembly)
		10-30663 - Screw Note: Priced Individually [ More info ] Unavailable
		10-62568 - Screw - Priced Individually [ More info ] $1.10 $0.88 10+ In Stock.
#22	45377	BRACKET, MOUNTING - HYDRAULIC PUMP TO BOAT (2 required per assembly)
		45377 - Bracket [ More info ] Unavailable
		45377T - Bracket, NLA [ More info ] $6.99 $5.91 10 In Stock.
#23	10-24234	SCREW, (.312-18 x 1.00) (4 required per assembly)
		10-24234 - Screw - Priced Individually [ More info ] Unavailable
		10-35386 - Screw - Priced Individually [ More info ] $1.10 7 In Stock.
#24	13-39107	LOCKWASHER, (.312-24) (4 required per assembly)
		13-39107 - LockWasher - Priced Individually [ More info ] $1.50 10+ In Stock.
#25	11-21908	NUT, (.312-18) Cad Plated (4 required per assembly)
		11-21908 - Nut (5/16x18) [ More info ] $3.19 10+ In Stock.
#26	10-28009	BOLT, HYDRAULIC PUMP TO BOAT (3-1/4") (2 required per assembly)
		10-28009 - Screw, NLA [ More info ] Unavailable
		10-68298 - Screw, NLA [ More info ] $8.76 $7.42 10+ In Stock.
#27	11-35304	NUT, HYDRAULIC PUMP BOLT (2 required per assembly)
		11-35304 - Nut, Mounting Bracket Bolt [ More info ] Unavailable
#28	25661	SOLENOID (1 required per assembly)
		25661 - Solenoid [ More info ] Unavailable
		25661 1 - Solenoid [ More info ] Unavailable
		25661T 1 - Solenoid [ More info ] $69.49 Available to Order: Shipping delay up to 10 days.
		18-5836 - Solenoid 25661-1 [ More info ] $41.75 1 In Stock.
		SW661 - Solenoid, 25661-1, Arco [ More info ] $40.22 $40.21 In Stock
#29	13-26996	LOCKWASHER, (#10) Stainless Steel (2 required per assembly)
		13-26996 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#30	11-20645	NUT, (#10) (2 required per assembly)
		11-20645 - Nut,(10X32) [ More info ] $0.21 6 In Stock.
		11-68219 - Nut (#10-32) [ More info ] $2.99 10+ In Stock.
#31	13-26993	LOCKWASHER, (.312) (2 required per assembly)
		13-26993 - LockWasher - Priced Individually [ More info ] $0.80 10+ In Stock.
		138M0204647 - LOCKWASHER, Priced Individually [ More info ] $1.80 Available to Order: Shipping delay up to 10 days.
#32	11-20083	NUT, (5/16-24) (2 required per assembly)
		11-20083 - Nut, Starter Solenoid Terminal (5/16X24) [ More info ] $1.22 10+ In Stock.
		11-22053 - Nut (5/16x24) [ More info ] $0.20 10+ In Stock.
#33	46265	BOOT, RUBBER (2 required per assembly)
		46265 - Boot [ More info ] $4.19 $3.36 5 In Stock.
#34	45321	BRACKET, MOUNTING - STARTER SOLENOID (1 required per assembly)
		45321 - Bracket [ More info ] Unavailable
		73343 - Bracket [ More info ] Unavailable
		74407 - Bracket [ More info ] Unavailable
		74407T - Bracket, NLA [ More info ] $14.00 $11.86 1 In Stock.
#35	10-21140	SCREW, (.250-28 x .50) (2 required per assembly)
		10-21140 - Screw, NLA [ More info ] $1.36 $1.16 10+ In Stock.
#37	10-34290	SCREW, (.250-20 x .625) (2 required per assembly)
		10-34290 - Screw [ More info ] $0.78 $0.66 10+ In Stock.
#39	11-21825	NUT, (.250-28) (2 required per assembly)
		11-21825 - Nut, (1/4x28) [ More info ] $1.70 10+ In Stock.
#40	13-27660	LOCKWASHER (1 required per assembly)
		13-27660 - LockWasher, NLA [ More info ] Unavailable
#41A	49342	BUMPER, RUBBER (1 required per assembly)
		49342 - Bumper, NLA [ More info ] $3.00 $2.54 1 In Stock.
#42	55642A 1	PANEL, CONTROL (1 required per assembly)
		55642A 1 - Panel Assembly [ More info ] $48.99 1 In Stock.
		55642A17 - Control Panel Assembly [ More info ] $49.99 $42.33 2 In Stock.
#43	16-55422	STUD, (#10-32 x 2.00), CONTROL PANEL TO BOAT (4 required per assembly)
		16-55422 - Stud - Priced Individually [ More info ] $6.79 10+ In Stock.
#44	12-24676	WASHER, (.200 x .440 x .032) (4 required per assembly)
		12-24676 - Washer, (.200 X .440 X .032) [ More info ] $1.50 10+ In Stock.
#45	11-27164	NUT AND LOCKWASHER, (#10-32) (4 required per assembly)
		11-27164 - Nut And Lockwasher (#10-32) [ More info ] $1.00 1 In Stock.
#46	55738A 1	SWITCH ASSEMBLY, PUSH BOTTON - CONTROL PANEL (3 required per assembly)
		55738A 1 - Switch Assembly [ More info ] $27.31 1 In Stock.
#47	48078	WIRE, Jumper, PUSH BOTTON SWITCH (RED - 3-1/4") (1 required per assembly)
		48078 - Jumper Wire, NLA [ More info ] Unavailable
#47	53107	WIRE, Jumper (3.00 Inches), PUSH BOTTON SWITCH (PURPLE) (1 required per assembly)
		53107 - Jumper Wire [ More info ] $1.79 $1.51 2 In Stock.
#48	55641	RETAINER, PUSH BOTTON SWITCH (4 required per assembly)
		55641 - Retainer, NLA [ More info ] $11.70 3 In Stock.
#49	10-62568	SCREW, (#10-16 x .375) (1 required per assembly)
#50	45341 20	HARNESS ASSEMBLY, CONTROL PANEL (20 FEET) (1 required per assembly)
		45341 20 - Harness 20 FT [ More info ] Unavailable
		84-79282 20 - Harness [ More info ] Unavailable
		84-87394A20 - Harness Assembly [ More info ] $170.49 Available to Order: Shipping delay up to 10 days.
#51	33865	BINDER, NYLON - CONTROL PANEL HARNESS (1 required per assembly)
		33865 - Binder, NLA [ More info ] $2.14 $1.82 3 In Stock.
#52	54-46770	CLAMP, HARNESS FASTENING (1 required per assembly)
		54-46770 - Clamp [ More info ] Unavailable
		95814 - Strap [ More info ] $8.19 Available to Order: Shipping delay up to 10 days.
#53	10-29227	SCREW, (#8-32 x 0.50) (1 required per assembly)
		10-29227 - Screw [ More info ] $3.39 $0.69 10+ In Stock.
#54	11-34388	NUT (1 required per assembly)
		11-34388 - Nut [ More info ] Unavailable
